Headphone Out Connector (J8)

Part Description
3.5 mm stereo jack
Stereo headphones

JTAG Connector (P1)

The connector provides access to the JTAG signals of the ADSP-21489
P1
processor. The standalone debug agent requires two connectors,
. Pin 3 is missing to provide keying. Pin 3 in the mating connector
ZP1
must have a plug.
page 1-19.
Remove the standalone debug agent when an emulator is used with the
EZ-Board. Follow the installation instructions provided in
Installation" on page

Expansion Interface II Connector (P2)

is a board-to-board connector providing signals for the DAI and DPI
P2
interfaces and GPIO signals of the processor. The connector is located on
the right edge of the board.
face II" on page 1-20.
contact Samtec.
Part Description
60-position 0.1", SMT header
60-position 0.1", SMT socket
ADSP-21489 EZ-Board Evaluation System Manual
ADSP-21489 EZ-Board Hardware Reference
Manufacturer
CUI
Mating Headphones (shipped with the EZ-Board)
KOSS
For more information, see "JTAG Interface" on
1-5, using as the JTAG connection point.
P1
For more information, see "Expansion Inter-
For availability and pricing of the connectors,
Manufacturer
SAMTEC
Mating Connector
SAMTEC
Part Number
SJ1-3525NG
151225 UR5
and
P1
"EZ-Board
Part Number
TSSH-130-01-L-DV-A
SSW-130-22-F-D-VS
2-27
