READ AND SAVE THESE INSTRUCTIONS
QUICK ASSEMBLY NOTES:
* Do not wire in fan while house wires are Live. Turn power off at breaker before installation
begins.
* Do not use any controls, wall or remote, other than those provided by Matthews Fan Company.
* Please do not use any electric or battery powered tools in the assembly and installation of this
or any other Matthews Fan Company product.
* Fan should be assembled and mounted by two people.
Irene
60", 52" or 42" CEILING FAN
FAN RATING AC 120V. 60Hz
For Damp Location

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Irene-5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Atlas fan company Irene-5

  • Page 1 Irene 60", 52" or 42" CEILING FAN READ AND SAVE THESE INSTRUCTIONS FAN RATING AC 120V. 60Hz For Damp Location QUICK ASSEMBLY NOTES: * Do not wire in fan while house wires are Live. Turn power off at breaker before installation begins.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Tools and Materials Required..................Package Contents ......................Safety Rules........................Mounting Options......................Hanging the Fan ......................Attaching the Fan Blades....................Make the Electric Connections..................Finishing the Installation....................Programming Your Fan and Operating the Remote Control and Wall Control....Operating Your Fan .......................
  • Page 3: Tools And Materials Required

    2. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: a-1. Blade set (3) (for Irene-3) a-2. Blade set (5) (for Irene-5) Hanger bracket assembly Ball / down rod assembly Coupling cover Fan motor assembly Hand held transmitter+holder+2 mounting screws Wall transmitter incl.
  • Page 4: Safety Rules

    3. SAFETY RULES 1. To reduce the risk of electric shock, insure 8. To avoid personal injury or damage to the fan electricity has been turned off at the circuit and other items, be cautious when working breaker or fuse box before beginning. around or cleaning the fan.
  • Page 5: Mounting Options

    4. MOUNTING OPTIONS If there isn't an existing UL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Outlet box Secure the outlet box directly to the building structure. Use appropriate fasteners and building materials.
  • Page 6: Hanging The Fan

    (Fig. 5A) when attaching your fan blades. The inner holes are for 3 blades. (for Irene-3) Figure 5 The outer holes are for 5 blades. (for Irene-5) 6. HANGING THE FAN Before touching a screw driver thoroughly read these instructions.
  • Page 7 4. Loosen the two set screws and remove the hitch pin and lock pin from the central Supply wires shaft/top coupling of the motor assembly. Doing so will allow the down rod to enter the central shaft. (Fig. 8) Downrod 5.
  • Page 8: Make The Electric Connections

    7. MAKE THE ELECTRIC Outlet box CONNECTIONS White ("AC IN N") Green or bare Black ("AC IN L") NOTE: Your fan has included as standard copper (ground) equipment two types of controls: a hand held Ground (green) remote control and a wall mounted wall control. Black (motor) (Connect to ground wire You may use both as long as the dip switches...
  • Page 9 B. Wall mount remote control SUPPLY CIRCUIT a. Fan wire connection Ground 1. Connect the fan supply (black) wire to the black Conductor household supply wire (Conductor cable between ceiling and wall outlet box). (Fig. 11) Ceiling 2. Connect the neutral fan (white) wire to the white Outlet Box neutral household wire.
  • Page 10: Finishing The Installation

    8. FINISHING THE INSTALLATION Outlet box 1. Tuck connections neatly into ceiling outlet box. Hanger 2. Slide the canopy up to hanger bracket and bracket place the key hole on the canopy over the screw on the hanger bracket, turn canopy until it locks Screws in place at the narrow section of the key holes.
  • Page 11: Programming Your Fan And Operating The Remote Control And Wall Control

    9. PROGRAMMING YOUR FAN AND OPERATING THE REMOTE CONTROL AND WALL CONTROL Before programming takes place, fan must be fully assembled and mounted to the ceiling with blades attached. You must also choose which control you will be using for programming the fan, the remote or the wall control.
  • Page 12: Operating Your Fan

    NOTE: If the self calibration test failed, turn the AC power off; restore power and process the self calibration test again. NOTE: During self calibration test, the remote and the wall control are non-functional. NOTE: The learning frequency function and self calibration test will continue to retain the last set frequency and calibration set even when the AC power is shut off.
  • Page 13: Care Of Your Fan

    11. CARE OF YOUR FAN Here are some suggestions to help you maintain your fan 1. Because of the fan's natural movement, some connections may become loose. Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. (It is not necessary to remove fan from ceiling.) 2.
  • Page 14 INSTRUCTIONS ON HOW TO PROGRAM MULTIPLE FANS ON SINGLE CIRCUIT BREAKER. 1. Turn the power off at the breaker/service box. 2. Hang all fans by convenience cable located in top of motor to hook in ceiling bracket. This will allow you to easily access the leads from house and the leads of the fan.
  • Page 15 LIMITED LIFETIME WARRANTY MATTHEWS-GERBAR, LTD. DBA MATTHEWS FAN COMPANY LIFETIME LIMITED WARRANTY. warranted by Matthews-Gerbar, Ltd. to the original user against defects in workmanship or materials under normal use and inside or outside damp location installation for: Motors: Lifetime of original purchaser: Labor &...
