MACHINE INSTALLATION MANUAL
EQUIPMENT NECESSARY FOR THE INSTALLATION
• T-handle wrench 2-2.5-3.5-3-5
• Articulated T5 wrench
• Scissors
• Trolley and/or "dolly"
N.B.
• The hardware is located in the backrest box in special bags
PEOPLE NECESSARY FOR THE INSTALLATION
Carried out by Fabrizio Frattini
Approved by Andrea Borghesi
1
RECLINE PERSONAL D9673
Revision 1/1
