Summary of Contents for Technogym Recline 700

  • Page 1 & ERVICE MAINTENANCE MANUAL . 2.4...
  • Page 3 The information contained in this document is subject to change without notice. Technogym does not guarantee this documentation in any way. Technogym shall not be held responsible for any errors contained in this manual and declines all liability for accidents or damages resulting from the supply, characteristics or use of this manual.

  • Page 5: Table Of Contents

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 Contents 1. GENERAL NOTICES............................1.1 1.1. I ..............................1.1 NTRODUCTION 1.2. R ............................1.1 ECOMMENDATIONS 1.3. G ...................... 1.2 ENERAL RULES FOR REPAIR PROCEDURES 2. TECHNICAL CHARACTERISTICS........................2.1 2.1. P ............................... 2.1 RODUCT CODES 2.2.
  • Page 6 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 4. ACCESSORIES ..............................4.1 4.1. C ........................4.1 ARDIO THEATER CONNECTION 4.2. PC ..........................4.1 LINK FOR PROGRAMMING 4.3. C ........... 4.2 ABLE FOR EXCHANGING CHANNEL TUNING DATA BETWEEN TWO MACHINES 4.4.
  • Page 7 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 7.3.2. 700iE Touch screen Wellness TV version ..................7.14 7.3.3. 500i and 500i SP versions........................7.15 7.4. D ......................7.16 ISASSEMBLING THE CARDIO RECEIVER 7.5. D ........................7.19 ISASSEMBLING THE HANDLEBAR 7.6. D .....................
  • Page 8 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 9.2.14. Enable custom messages ........................9.11 9.2.15. Resetting parameters to default values ....................9.12 9.2.16. Format P&P............................9.12 9.2.17. SN ...............................9.12 9.3. S ........................9.13 ERVICE MENU CONFIGURATION 9.3.1. Time and date.............................9.14 9.3.1.1. Hour ....................................9.15 9.3.1.2.
  • Page 9 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 10.3.7. Checking the display ..........................10.3 10.3.8. Checking the wiring and connections ....................10.4 11. APPENDIX................................11.1 11.1. U SW ............................11.1 PDATING THE 11.2. H – ...................... 11.2 ARDWARE SOFTWARE COMPATIBILITY 11.2.1. 500i and 500i SP models........................11.2 11.2.2.
  • Page 10 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 Page intentionally left blank Page vi...

  • Page 11: General Notices

    1. GENERAL NOTICES 1.1. INTRODUCTION This document is reserved for Technogym Service technicians, and is intended to provide authorized personnel with the necessary information to correctly carry out repairs and maintenance. A thorough knowledge of the technical information contained in this manual is essential for completing the professional training of the operator.

  • Page 12: General Rules For Repair Procedures

    . Always mark any parts or positions which may be confused with each other at the time of reassembly. 2. Use original Technogym spare parts and lubricants of the recommended brands. . Use special tools where specified. Consult the Tec hnical Newsletters, which may contain more up-to-date information on adjustments and maintenance than those contained in this manual.

  • Page 13: Technical Characteristics

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 2. TECHNICAL CHARACTERISTICS 2.1. PRODUCT CODES The machine codes take into account all the possible variants and options available for the products. The machine code, which does not include the Serial Number, consists of 16 alphanumeric characters arranged as follows: Characters description key to values...
  • Page 14 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 Characters description key to values IT = Italian DE = German FR = French US = American English 14,15 Language NL = Dutch BR = Portuguese JP = Japanese UK = British English ES = Spanish I = Italy E = standard international...

  • Page 15: Available Versions

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 2.2. AVAILABLE VERSIONS There machine is available in 2 versions: • Recline 500: mains operated machine; • Recline 500SP: self-powered machine; • Recline 700: mains operated machine; • Recline 700SP: self-powered machine;...

  • Page 16: Product Characteristics

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 2.3. PRODUCT CHARACTERISTICS ERSION – 700 30-500 Watt 40-500 Watt 30-500 Watt 40-500 Watt Power Hand sensor Touch sensor CSafe Cardio receiver Quick start Goal Quick start 6 profiles Training programs Goal Training Zone Weight Loss...

  • Page 17: Electrical Characteristics

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 2.5. ELECTRICAL CHARACTERISTICS ERSION - 700 Mains voltage 90 - 260 VAC 50 - 60 Hz Frequency Consumption 50 VA Fuses F 3.15 A 2.6. AMBIENT SPECIFICATIONS Operating from 5° to 35° C Temperature Storage from -10°...

  • Page 18: Wiring Diagram

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 2.8. WIRING DIAGRAM 2.8.1. MODEL 2.8.1.1. Powered version RECEIVER CSAFE BOARD CBQ-28 CBQ-13 386 BOARD DISPLAY BOARD CBQ-32 KEYBOARD BOARD DISPLAY CB-4 CB-3 POWER BRAKE ENTRY CB-0 BRAKE CB-51 BOARD MODULE SPEED Patch conn.

  • Page 19: Cordless Version

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 2.8.1.2. Cordless version RECEIVER CBQ-28 CSAFE BOARD CBQ-13 386 BOARD DISPLAY BOARD CBQ-32 KEYBOARD BOARD DISPLAY CB-4 CB-3 BRAKE BATTERY CB-52 CB-51 BRAKE BOARD Patch Patch SPEED conn. conn. SENSOR ALTERNATOR BATTERY CHARGER INPUT Page 2.7...

  • Page 20: Model - Arm Board

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 2.8.2. – ARM MODEL BOARD 2.8.2.1. Powered version RECEIVER CSAFE BOARD CU83 CBQ-13 DISPLAY BOARD ARM CBQ-32 KEYBOARD READER DISPLAY CB-4 CB-3 POWER BRAKE ENTRY CB-0 CB-51 BRAKE BOARD MODULE SPEED Patch SENSOR conn.

  • Page 21: Cordless Version

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 2.8.2.2. Cordless version RECEIVER CU83 CSAFE BOARD CBQ-13 DISPLAY BOARD ARM CBQ-32 KEYBOARD READER DISPLAY CB-4 CB-3 BRAKE BATTERY CB-52 CB-51 BRAKE BOARD Patch Patch SPEED conn. conn. SENSOR ALTERNATOR BATTERY CHARGER INPUT Page 2.9...

  • Page 22: Model

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 2.8.3. MODEL 2.8.3.1. Powered version RECEIVER RIGHT CSAFE SENSOR BOARD HAND CBQ-28 SENSOR CB-30 CBQ-13 BOARD FLEX CABLE LEFT SENSOR CBQ-25-1-R1 CNY-1 CNX-1 BOARD RIGHT 386 BOARD CNY-2 CNX-2 RIGHT RIGHT CBQ-26-R3 CBQ-26-R1 TOUCH SENSOR...

  • Page 23: Cordless Version

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 2.8.3.2. Cordless version RECEIVER RIGHT CSAFE SENSOR BARD HAND CBQ-28 SENSOR CB-30 CBQ-13 BOARD FLEX CABLE LEFT SENSOR CBQ-25-1-R1 CNY-1 CNX-1 BOARD RIGHT 386 BOARD CNY-2 CNX-2 RIGHT RIGHT CBQ-26-R3 CBQ-26-R1 TOUCH SENSOR CNY-3 CNX-3...

  • Page 24: Model - Arm Board

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 2.8.4. – ARM MODEL BOARD 2.8.4.1. Powered version RECEIVER RIGHT CSAFE SENSOR BOARD HAND CU83 SENSOR CB-30 CBQ-13 BOARD FLEX CABLE LEFT SENSOR CBQ-25-1-R1 CNY-1 CNX-1 READER RIGHT DISPLAY BOARD ARM CNY-2 CNX-2 RIGHT...

  • Page 25: Cordless Version

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 2.8.4.2. Cordless version RECEIVER RIGHT CSAFE SENSOR BARD HAND CU83 SENSOR CB-30 CBQ-13 BOARD FLEX CABLE LEFT SENSOR CBQ-25-1-R1 CNY-1 CNX-1 READER RIGHT DISPLAY BOARD ARM CNX-2 CNY-2 RIGHT RIGHT CBQ-26-R3 CBQ-26-R1 TOUCH SENSOR CNY-3...

  • Page 26: Wellness Tv Version

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 2.8.5. ELLNESS VERSION 2.8.5.1. NCB Touch screen version Antenna CONNECTORS inlet PANEL AUX INPUT BOARD DISPLAY CSAFE BOARD CB-9 CB-18 BOARD BOARD CBQ-13 CBQ-32 RIGHT SENSOR RECEIVER HAND SENSOR CB-30 CBQ-28 CN11 BOARD TUNER...

  • Page 27: Ub Touch Screen Version

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 2.8.5.2. UB Touch screen version Antenna CONNECTORS CSAFE intel S-Video CVBS Left Right PANEL AUX INPUT BOARD CB-18 DISPLAY BOARD CU124 CU99 BOARD CB-9 RECEIVER CBQ-32 RIGHT CU83 SENSOR HAND SENSOR CB-30 BOARD FLEX CABLE...

  • Page 28: Cables

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 2.9. CABLES CB-0: High voltage cable Power entry module – Brake board Power entry Signal Color Brake board module Line White Neutral Black Earth Green CB-3: Cable connecting upper and lower assemblies Brake board –...
  • Page 29 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 CB-9: Inlet DVD video cable Connectors board – AUX input board Connectors Signal Color AUX input board board Color Left audio IN White Shield Right audio IN Shield Video IN Yellow Shield Commutation White...
  • Page 30 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 CB-52: Alternator cable Brake board – Alternator – Battery – Inlet for battery charging Brake board Signal Color Alternator Battery Battery charging inlet V+ voltage from Faston alternator V- voltage from Black Faston alternator...
  • Page 31 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 CBQ-26-R2: Touch sensor cable – Hand sensor Patch connectors - Patch connectors Patch connector Signal Color Patch connector CNY-1 CNY-2 CNY-3 CNX-1 CNX-2 CNX-3 Out pulse Flat cable Power supply+5 Vdc Flat cable Reference Flat cable...
  • Page 32 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 CV-302: LCD inverter power supply cable Display board – LCD Inverter CPU board Signal Color LCD Inverter Black Supply voltage +3.3 Vdc Black Black Supply voltage +12 Vdc Orange FLEX CABLE: Hand sensor board cable Hand sensor board –...

  • Page 33: Principles Of Operation

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 3. PRINCIPLES OF OPERATION 3.1. BLOCK DIAGRAM The machine block diagram is illustrated in the figure below: Antenna inlet (W TV only) CONNECTORS PANEL DISPLAY CSAFE BOARD RIGHT CARDIO SENSORS RECEIVER HAND SENSOR DISPLAY BOARD...

  • Page 34: Display Boards

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 3.1.1. ISPLAY BOARDS 3.1.1.1. 500i and 500i SP models The display comprises the following circuit boards: • 386 B OARD This is the circuit board which comprises the CPU, a 386 microprocessor, its logic circuits and a FLASH EPROM containing the operating program for the machine.

  • Page 35: Arm And 500I Sp Arm Models

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 3.1.1.2. 500i ARM and 500i SP ARM models The display comprises the following circuit boards: • DISPLAY BOARD This is the heart of the display: this is the circuit board which comprises the CPU, an ARM microprocessor, its logic circuits and a FLASH EPROM containing the operating program for the machine moreover, acts as the interconnection hub for all the components of the display and serves as the point of connection with the electrical box.

  • Page 36: Arm And 700I Sp Arm Models

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 > distributes to the display the voltages received from the brake board; > exchanges, via the RS-485 serial link to the brake board, the commands for controlling the brake; > controls the LEDs and the 7-segment displays which provide feedback about the exercise session.

  • Page 37: 700Ie Version (Wellness

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 if ON the +5 Vdc power supply from the LED1 yellow Brake board correctly reaches the board. if ON the +12 Vdc power supply from the LED2 green Brake board correctly reaches the board. 3.1.1.5.

  • Page 38: 700Ie Ub Version (Wellness

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 • CPU B OARD This is the heart of the display: it is the circuit board which incorporates the CPU, a microprocessor, its control logic, the FLASH EPROM containing the operating program of the machine, and the tuner for the audio and video channels.
  • Page 39 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 > Acts as the interconnection hub for all the components of the display, and serves as the point of connection with the brake board. It includes connectors for the following: Cardio receiver; Hand sensor board;...

  • Page 40: Csafe Board

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 • EADPHONE JACK The machine display has two jacks for connecting headphones. The two jacks are connected in parallel to a stereo output of the CPU board. In addition to the audio signals, the connector also includes a sense signal for routing the output to either the headphones or external speakers, if the latter are installed.

  • Page 41: Brake

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 - commands determining the resistance that is required of the brake; - brake error messages; - the commands for modifying the circuit board configuration parameters; - the commands for viewing the errors logged by the circuit board. •...

  • Page 42: Alternator

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 3.1.11. A LTERNATOR Only for 500i SP and 700i SP versions. The alternator consists of a stator winding whose rotor is put into rotation by the movement of the edals, generating the voltage necessary for the machine’s operation. Depending on the rate of pedaling and the resulting speed of rotation, it generates an alternating voltage which ranges from approximately 15-17 VAC at about 30-35 RPM to over 40 VAC for higher pedaling speeds.

  • Page 43: Brake Control

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 3.2. BRAKE CONTROL 3.2.1. ECHANICS The movement of the pedals puts the brake into rotation by means of a belt. The speed sensor (only on mains operated models) attached to the frame detects the heads of the screws which secure the disk to the flywheel, and generates a signal proportional to the speed.
  • Page 44 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 When the brake interface board receives the signal to generate resistance, the green LED illuminates. The electromagnetic field produced by the winding and the rotation of the disk will induce eddy currents in the disk itself, giving rise to a force which tends to brake its motion.

  • Page 45: The Signals Involved

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 brake bo rd interrupts the supply of cur rent to the brake and sends an error message to the display board which displays the “THE EQUIPMENT IS BLOCKED” message. 3.2.3. HE SIG NALS INVOLVED machine uses the following control signals: •...
  • Page 46 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 Page intentionally left blank Page 3.14...

  • Page 47: Accessories

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 4. ACCESSORIES 4.1. CARDIO THEATER CONNECTION The machine can be connected to the CardioTheater by means of the RJ45 connector on the CSafe board. The CardioTheater unit must be provided with a power cable having the following pin-out: RJ45 Connector Signal +5 Vdc Ground...
  • Page 48 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 When programming the machine sometimes it is necessary to fit plug into the free RJ-45 port on the back of the display, to avoid any type of interference during the operation. The wiring diagram of the RJ-45 plug is as follows: Programming cable and plug can be ordered using the code H0002534AA.

  • Page 49: Monitor Plug For Csafe Port

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 4.4. MONITOR PLUG FOR CSAFE PORT When the plug code 0WC00639AA is fitted into any one of the CSafe ports on the machine, the corresponding LED should illuminate to indicate the presence of the 5 Vdc supply on the port. During the CSafe port test function, the plug connects the transmit channel directly to the receive channel, thereby producing a positive test outcome if the port is functioning correctly.

  • Page 50: Wellness Tv Upgrade Kit

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 4.5. WELLNESS TV UPGRADE KIT There are upgrade kits available for converting Excite machines from the version with traditional LED display to the version with Wellness TV display. The kit also includes all the cables and connectors required for the input of the antenna signal.

  • Page 51: Installation Procedure

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 4.5.1. NSTALLATION PROCEDURE NOTE: It is always advisable, in any case, to upgrade the brake interface board to the latest SW version. The upgrade kit consists of: (1) External connector board cover plate (cod.
  • Page 52 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 1. Turn off the machine and unplug the mains lead from the wall outlet. 2. Back off the 4 screws a using a Phillips screwdriver. Figure 4.5-2 3. Unplug the connectors indicated in the figure.
  • Page 53 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 7. On the right side, back off the 7 screws c using a 4-mm he x T-wrench. . Position the right pedal at the top and remove the right guard. This operation may be awkward. If in difficulty, perform standard...
  • Page 54 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 16. Turn the machine over on the left side. 17. Back off the 4 screws d using a Phillips screwdriver. 18. Remove the cover e. Figure 4.5-6 Remove c onnector plate f from the front platform.
  • Page 55 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 23. Plug the lower end of cable 8 (CB-18) into union connector 7, previously assembled on connector plate 6. 24. Fix CSafe connector g, if present, to connector plate 6. 25. Snap connector plate 6 into its seat on the platform.
  • Page 56 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 34. Remove cover plate h, backing off the 4 screws i using a Phillips screwdriver. Figure 4.5-11 Insert external connector board 2 along the special guides on cover plate 1, in such a way that the connectors on the board match up with the holes on the cover plate.
  • Page 57 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 41. Assemble the covering removed previously in step 30 onto the WTV display, and secure using the 3 screws l. 42. Connect the following cables to the WTV display: • Cable 8 (CB-18) on connector J1 of the connector board.
  • Page 58 RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 Page intentionally left blank Page 4.12...

  • Page 59: Installation Instructions

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 5. INSTALLATION INSTRUCTIONS 5.1. SPECIFICATIONS AND REQUIREMENTS For correct machine installation, make sure that: 1. The machine is installed on a level surface that is free of vibrations and has sufficient carrying capacity for the combined weight of the machine and user.

  • Page 60: Installation

    RECLINE EXCITE: Service & Maintenance Manual - rev. 2.4 5.3. INSTALLATION To correctly install the machine, proceed as follows: 1. Ensure that the specifications and requirements for installation have been met (see paragraph 5.1. “Specifications and requirements”). 2. Position the machine as specified above, on a level surface that is free of vibrations and has sufficient carrying capacity for the combined weight of the machine and user.
