- Page 1 ARTIS LINE WITH UNITY 4.0 Pre-Installation Requirements Line: Artis Equipment Code: DBxxxQ Rev: 1.0 Date: 17-09-2019 Document Code: PIR-00028-EN...
-
Page 3: Table Of Contents
ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 Index GENERAL WARNINGS ..................7 NETWORK DESIGN – CONFIGURATION AND INSTALLATION ......9 INTRODUCTION ......................9 NETWORK DESIGN AND INSTALLATION (BUSINESS-TO-BUSINESS (B2B)) ..9 CONFIGURATION AND INSTALLATION (BUSINESS-TO-BUSINESS (B2B)) ..9 DISPLAY ......................11 RUN ARTIS ........................11 RECLINE ARTIS ...................... - Page 4 ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 5.6.2 Facility / Hotel (Business to Business (B2B)) ............23 FIREWALL / ROUTER RULES FOR ACCESS TO MYWELLNESS CLOUD SERVIC- ES ..........................25 PROXY ........................25 STANDARD TV TECHNICAL SPECIFICATIONS ..........27 INTRODUCTION ......................27 VIRTUAL LAN ......................28 LAN ..........................28 UNITY 4.0 DVB-T / T2 / C / ISDB-Tb VERSION (-T) STANDARD OPTIONS .....29 UNITY 4.0 - VERSION (-A) STANDARD OPTIONS - USA/CANADA......32...
- Page 5 This document contains proprietary information that is covered by copyright. All rights re- served. No part of this document may be circulated, copied, reproduced or translated into another language without the prior written consent of Technogym. Additional information may be included in the After Sales technical documents, available in the official ‘After Sales documents repository’.
- Page 6 ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 Blank page - 6 - PIR-00028-EN - Uncontrolled copy if printed...
-
Page 7: General Warnings
ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 GENERAL WARNINGS This manual includes informative notes with specific meanings: Safety signs classified according to the relative seriousness of the potential hazards: DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. - Page 8 ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 Blank page - 8 - PIR-00028-EN - Uncontrolled copy if printed...
-
Page 9: Network Design - Configuration And Installation
For this purpose, Technogym will send a check list form to the customer a few days before the date set for installation, and will ask the customer to compile the form and send to the Technical Service department. - Page 10 ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 Blank page - 10 - PIR-00028-EN - Uncontrolled copy if printed...
-
Page 11: Display
ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 DISPLAY 3.1 RUN ARTIS The RUN ARTIS (DBKxxQ) is fitted with UNITY 4.0 display. Fig. 1 3.2 RECLINE ARTIS The RECLINE ARTIS (DBDxxQ) is fitted with UNITY 4.0 display. Fig. 2 PIR-00028-EN - Uncontrolled copy if printed - 11 -... -
Page 12: Bike Artis
ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 3.3 BIKE ARTIS The BIKE ARTIS (DBCxxQ) is fitted with UNITY 4.0 display. Fig. 3 3.4 CLIMB ARTIS The CLIMB ARTIS (DBExxQ) is fitted with UNITY 4.0 display. Fig. 4 - 12 - PIR-00028-EN - Uncontrolled copy if printed... -
Page 13: Vario Artis
ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 3.5 VARIO ARTIS The VARIO ARTIS (DBFxxQ) is fitted with UNITY 4.0 display. Fig. 5 3.6 SYNCHRO ARTIS The SYNCHRO ARTIS (DBHxxQ) is fitted with UNITY 4.0 display. Fig. 6 PIR-00028-EN - Uncontrolled copy if printed - 13 -... - Page 14 ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 Blank Page - 14 - PIR-00028-EN - Uncontrolled copy if printed...
-
Page 15: Technical Characteristics And Requirements
ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 TECHNICAL CHARACTERISTICS AND REQUIREMENTS 4.1 TECHNICAL DATA AND POWER REQUIREMENTS 4.1.1 Run Model Code DBK0EQ (200-240V - CE) DBK0AQ (100-240V - UL) Power Supply 200÷240Vac 50/60Hz 100÷240Vac 50/60Hz Max Absorption 10A @ 230 Vac, 50/60 Hz 20A @110 Vac, 50/60 Hz 16 A @230 Vac, 50/60 Hz Motor peak power (*) -
Page 16: Recline - Bike - Climb - Vario - Synchro
ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 4.1.2 Recline - Bike - Climb - Vario - Synchro RECLINE - BIKE - CLIMB - VARIO - SYNCHRO Power Supply 100÷240Vac 50/60Hz Max Absorption (Bike - Recline - 100 W 1 A @110 Vac, 50/60 Hz Vario - Climb) (*) 100 W 1 A @230 Vac, 50/60 Hz Max Absorption (Synchro) (*) -
Page 17: Electrical Connection
ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 4.2 ELECTRICAL CONNECTION Before connecting the product to the mains power supply, ensure that the electrical system speci- fications comply to binding regulations. For Run equipment: Check the specifications of the mains power supply on the product identifica- tion label. -
Page 18: Positioning Of Power Inlet
ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 4.3 POSITIONING OF POWER INLET 4.3.1 Run Artis Fig. 7 - Right front side 4.3.2 Recline Artis Fig. 8 - 18 - PIR-00028-EN - Uncontrolled copy if printed... -
Page 19: Bike Artis
ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 4.3.3 Bike Artis Fig. 9 4.3.4 Climb Artis Fig. 10 - Central front side PIR-00028-EN - Uncontrolled copy if printed - 19 -... -
Page 20: Vario Artis
ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 4.3.5 Vario Artis Fig. 11 4.3.6 Synchro Artis Fig. 12 - 20 - PIR-00028-EN - Uncontrolled copy if printed... -
Page 21: Network Requirements
The equipment support both wireless and wired internet connection. In all situations, where possible, Technogym recommends connection via network cable. In all cases, the network must be installed and configured by the customer before Technogym de- livers the product, in accordance with the technical specifications set out below. -
Page 22: Wireless Guidelines
ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 10, 11, 12. Other channels: 2, 3, 4, 13, 14 might cause interference with Bluetooth signal and it’s best to avoid them. _Avoid in any case to broadcast the same SSID, through 2.4 and 5 GHz, at the same time. -
Page 23: Internet Connection Bandwidth Requirements
ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 5.6 INTERNET CONNECTION BANDWIDTH REQUIREMENTS 5.6.1 Home (Business to Consumer (B2C)) Internet Speed requirements N°1 Equipment 5 Mbps or more for the best audio and video experience: HD quality (up to 1080p) 3 Mbps for viewing medium quality (standard definition video, DVD quality) - Page 24 ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 Fig. 13 - 24 - PIR-00028-EN - Uncontrolled copy if printed...
-
Page 25: Firewall / Router Rules For Access To Mywellness Cloud Services
ISP (Internet service provider). Free access to the Internet must be guaranteed for correct use of the Mywellness Cloud services, and in particular access to the following DNS names must never be disabled. DNS Names mywellness.com technogym.com facebook.com facebook.net fbcdn.net google.com googleapis.com... - Page 26 ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 Blank Page - 26 - PIR-00028-EN - Uncontrolled copy if printed...
-
Page 27: Standard Tv Technical Specifications
ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 STANDARD TV TECHNICAL SPECIFICATIONS 6.1 INTRODUCTION The data useful to antenna installers for checking the suitability of the antenna signal input to the equipment with UNITY 4.0 are detailed below. The readings in the tables below must be taken directly at the antenna input connector on the equipment. -
Page 28: Virtual Lan
ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 Fig. 14 (*): DTMB not supported yet. The code 0WR01388 is officially released when the Artis Line with Unity 4.0 is commercially re- leased in Japan. 6.2 VIRTUAL LAN UNITY 4.0 doesn’t manage the VLANs because it has only one CPU port that manages both In- ternet and IPTV on the same network.Therefore it’s not possible to set a VLAN network on IPTV infrastructure. -
Page 29: Unity 4.0 Dvb-T / T2 / C / Isdb-Tb Version (-T) Standard Options
ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 6.4 UNITY 4.0 DVB-T / T2 / C / ISDB-Tb VERSION (-T) STANDARD OPTIONS NOT ENCRYPTED ▪ Analog TV + FM Radio; ▪ Digital TV DVB-T/ DVB-T2 (mpeg2, H264, HEVC) not encrypted; ▪... - Page 30 ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 INTERNET IPTV (e.g. Netflix) ANDROID APP (FREE) – Compatibility check SUPPORTED ANALOGIC STANDARDS (DVB-T / T2 / C) ▪ PAL B/G , PAL I , SECAM DK , SECAM L , SECAM L1; ▪...
- Page 31 ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 COAX QAM Pro:IDIOM®: ATSC/ QAM-B Pro:IDIOM® UNITY 4.0 VERSION “-T“ + UPGRADE KIT A0000845 CABLE TV: QAM-B (64/256 QAM –ITU J83 Annex B) – Channel spa- cing 6 MHz DIGITAL TV : ATSC (free to air) ANALOG TV: Not available Broadcast System RADIO FM: Not available...
-
Page 32: Unity 4.0 - Version (-A) Standard Options - Usa/Canada
ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 6.5 UNITY 4.0 - VERSION (-A) STANDARD OPTIONS - USA/CANADA NOT ENCRYPTED ▪ Analog TV (e.g. NTSC) + FM Radio; ▪ Digital TV (coax ATSC) not encrypted; ▪ Cable TV (coax QAM-B 64/256) not encrypted; ▪... - Page 33 ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 STANDARD (NOT ENCRYPTED) ATSC/ QAM-B / ANALOG NTSC / IPTV UNITY 4.0 VERSION “-A“ Broadcast System CABLE TV: QAM-B (64/256 QAM –ITU J83 Annex B) – Channel spa- cing 6 MHz DIGITAL TV : ATSC (free to air) ANALOG TV: YES RADIO FM: YES...
- Page 34 ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 COAX QAM Pro:IDIOM®: ATSC/ QAM-B Pro:IDIOM® UNITY 4.0 VERSION “-A“ + UPGRADE KIT A0000845 Broadcast System CABLE TV: QAM-B (64/256 QAM –ITU J83 Annex B) – Channel spa- cing 6 MHz DIGITAL TV : ATSC (free to air) ANALOG TV: Not available RADIO FM: Not available...
-
Page 35: Acknowledgement And Acceptance
ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 ACKNOWLEDGEMENT AND ACCEPTANCE Date: ____________________________________________ Acknowledged and accepted __________________________ PIR-00028-EN - Uncontrolled copy if printed - 35 -... - Page 36 ARTIS LINE with UNITY 4.0 Pre-Installation Requirements Rev. 1.0 Blank page - 36 - PIR-00028-EN - Uncontrolled copy if printed...
- Page 38 TECHNOGYM S.p.A. Via Calcinaro, 2861 - 47521 Cesena (FC) - Operational Headquarters ITALY International Technical Support: TG Branches: +390547650638 / +390547650667 cloudsupport@technogym.com (Cloud Support) sfdcsrvhqit@technogym.com (Equipment Support) TG Distributors: +390547650638 / +390547650667 cloudsupport4distributors@technogym.com support4distributors@technogym.com...
