Summary of Contents for Technogym Excite Top 700

  • Page 1 Technical information 700 version software 700 IFI version software User manual...

  • Page 2: Table Of Contents

    Contents Manufacturer and equipment identification ..........3 Description of the equipment ..............5 Technical data ..................13 Accessories ....................15 Safety labels and devices ................. 16 Place of installation .................. 18 Unpacking ....................19 Moving the equipment ................0 Levelling ....................1 Electrical connection (700 version) ............

  • Page 3: Manufacturer And Equipment Identification

    Manufacturer and equipment identification 07081001 A - Manufacturer’s name and address E - CE Mark B - Description of product F - Tells you to consult the User manual C - Electrical specifications and type of fuses G - Serial number and date of manufacture H - Certification mark for the USA and Canada (700 version) D - Equipment classification...
  • Page 4 Manufacturer and equipment identification Equipment with codes DA77M... are intended for medical use and have been designed and built for use in outpatient clinics, hospitals, clinics and sport centres, for muscular therapy and rehabilitation. Equipment with codes DA77M... can be used by or close to children, invalids, disabled persons or people with evident physical problems only under close supervision of a doctor or a qualified professional.

  • Page 5: Description Of The Equipment

    Description of the equipment Control panel Handgrips Seat Front platforms Rear platforms Reading stand Tray TGS key reader 0708100 Control panel: controls all available functions, from setting up workout programs to viewing messages and related workout information.
  • Page 6 Description of the equipment Control panel Handgrips Seat Front platforms Rear platforms Reading stand Tray TGS key reader 07081003 Handgrips: they must be gripped to perform the exercise.
  • Page 7 Description of the equipment Control panel Handgrips Seat IFI Version Front platforms Rear platforms Reading stand Tray TGS key reader 07081004 Seat: adjustable longitudinally and can easily be removed in order to use the equipment standing up or with a wheelchair for disabled persons.
  • Page 8 Description of the equipment Control panel Handgrips Seat Front platforms Rear platforms Reading stand Tray TGS key reader 07081005 Front platforms: the user places his feet here whilst exercising.
  • Page 9 Description of the equipment Control panel Handgrips Seat Front platforms Rear platforms Reading stand Tray TGS key reader IFI Version 07081006 Rear platforms: the wheels of a disabled person’s wheelchair are placed here; the user stands here to also perform the exercise standing up.
  • Page 10 Description of the equipment Control panel Handgrips Seat Front platforms Rear platforms Reading stand Tray TGS key reader Reading stand: for standing magazines or books on.
  • Page 11 Description of the equipment Control panel Handgrips Seat Front platforms Rear platforms Reading stand Tray TGS key reader 07081008 Tray: for standing the water bottle or other useful items on during the workout.
  • Page 12 Description of the equipment Control panel Handgrips Seat Front platforms Rear platforms Reading stand Tray TGS key reader TGS key reader: for the TGS key (optional).

  • Page 13: Technical Data

    Technical data Top 700 Europe-Asia USA-Canada Power supply 100÷240 Vac ±10% 50/60 Hz 100÷240 Vac ±10% 50/60 Hz Braking power 25÷1000 W ±10 25÷1000 W ±10 100 VA max 100 VA max Mains power input (160 VA max with Visio) (160 VA max with Visio) Fuses 2 x 3.15A (F)
  • Page 14 Technical data 780 mm 1881 mm 706 mm 1544 mm (30") (74") (28") (60") 1491 mm 1491 mm (59") (59") 07081010 105 kg (232 lb) 150 kg (331 lb) 130 kg (287 lb)

  • Page 15: Accessories

    Accessories The equipment’s standard outfit comprises: A Set of wrenches B User manual C Warranty certificate D CEE Power Supply cable with SH socket (700 version) E CEE Power Supply cable (extension) (700 version) F Cloth for cleaning G 10A German-type adapter (700 version) H Two replacement fuses ( x 3.15A (F) (700 version) 07081011...

  • Page 16: Safety Labels And Devices

    Safety labels and devices 0708101 A Fixed guard: guards against access to the inside of the equipment. B Beep: warns the user when the equipment is switched on, when the exercise starts or if the heart rate is high. C Main switch: turns the equipment’s power on and off (700 version). D Fuses: they protect the equipment’s electrical parts (700 version).
  • Page 17 Safety labels and devices arning Please read the adhesive labels on the equipment, which provide information about possible risks and hazards. In the 700 version: E The label affixed to the frame above the front platform states the electrical specifications. F The label, which can be affixed close to the main switch, states safety indications.

  • Page 18: Place Of Installation

    Place of installation To ensure that exercising with the equipment is easy, safe and effective, the place where it is used should comply with certain specific requirements; in particular, before choosing the place where the equipment will be installed, please ensure that the following conditions are satisfied: - the temperature is between +10°C and +5°C;...

  • Page 19: Unpacking

    Unpacking The equipment comes fully assembled in a pack, either wrapped in a transparent plastic sheet or in a cardboard pack attached to a pallet. The packed material can be lifted and carried with normal lifting equipment. The instructions are printed directly on the pack.

  • Page 20: Moving The Equipment

    Moving the equipment To move the equipment from the packing pallet to the floor, lift as shown in 07081014 the picture and then slide it on to the floor. This must be done by at least two people. arning Lift the equipment by holding onto the frame and not the levers or the control panel.

  • Page 21: Levelling

    Levelling The equipment is levelled by adjusting the two front feet: - screw the foot (A) in or out until the frame is in a stable position; - tighten up the lock nut (B) after adjusting. 07081016...

  • Page 22: Electrical Connection (700 Version)

    Electrical connection (700 version) Before connecting the equipment to the mains power supply, ensure that the electrical system specifications comply to binding regulations. Check the mains power supply specifications on the equipment identification label. anger The wall socket must be located in a place where the plugging and unplugging can be done easily and safely.
  • Page 23 Electrical connection (700 version) anger The power supply socket must be grounded . If not, a ground connection must be installed by a qualified electrician before connecting the equipment to the electricity mains. The product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock.
  • Page 24 Connection to another device The equipment can be connected to an audio/video reception device such as the Cardio Theater. Besides, if the equipment has not TV, it can be connected to a network of devices conforming to the CSAFE protocol. arning The devices connected must comply with international standards.
  • Page 25 Connection to another device Each TV can be connected to many compatible audio/video equipment (e.g. DVD, Playstation, VCR and earphones): A RCA audio inputs (red connector for the right input and white connector for the left input) B RCA video input (yellow connector) C earphones jack.

  • Page 26: Adjusting The Levers Play

    Adjusting the levers play To adjust the handgrips levers play: - remove the cap (A); - use a wrench to adjust the screw (B); - once the adjustment is complete return the cap (A) in its seating. 07081018...

  • Page 27: Routine Maintenance

    The safety of the equipment is assured only on the condition that it is carefully inspected every two weeks for any signs of damage and/or wear. The routine maintenance, adjustment and lubrication jobs must be performed by the Technogym Technical Support Service. For maintenance actions not described in this manual, call in the Technogym Technical Support Service.

  • Page 28: Changing The Fuses (700 Version)

    Changing the fuses (700 version) arning The fuses must be changed by the Technogym Technical Support Service. anger Before changing the fuses, switch the equipment off by switching the switch to 0 and unplug the power cable plug from the wall socket.

  • Page 29: Recharging The Battery (700 Sp Version)

    Recharging the battery (700 SP version) The 700 SP version has to be kept moving to keep it turned on. If, when you stop moving, the control panel switches off without warning, the battery will have to be recharged. arning Do not use the equipment while the battery is recharging.

  • Page 30: Troubleshooting

    Installation problems with the power supply cable (700 version). Check the connection. Burnt-out fuses (700 version). To replace the blown fuse with a spare (3.15A (F) contact Technogym Technical Support Service. The control panel connector has been accidentally disconnected. Contact the Technogym Technical Support Service.
  • Page 31 Data incorrect or unreliable Blocked key on keypad. with equipment running If the problem persists, contact the Technogym Technical Support Service. Equipment next to source of radio interference (e.g. electrical domestic appliances). Move the equipment to another place or move the domestic appliances.

  • Page 32: Technical Assistance

    47035 Gambettola (Forlì) ITALY tel: 0547 650650 fax: 0547 650150 email: service@technogym.com When you contact the Technogym Technical Support Service you must give the following information: - model, - date of purchase, - serial number, - precise description of the problem.

  • Page 33: Storage

    Storage If a long period of non-use is expected, you are advised to store the equipment in the following way: - in a clean dry place, with a dust cover; - at a room temperature between -10°C and 70°C and relative humidity between 0% and 90%. For better storage, use the original packing materials.

  • Page 34: Switching On And Off

    Switching on and off To turn the 700 version of the equipment on, switch the switch to the “I” position (on). To turn the 700 SP version on, begin moving. When switched on, a beep sounds and all the control panel LEDs light up. After a quick system check (reset), the equipment is ready for use.
  • Page 35 Switching on and off To turn the 700 version of the equipment off, switch the main switch to the “0” position (off). If the equipment isn’t going to be used for a long time, as well as turning it off you should also pull the plug out of the wall socket.

  • Page 36: Monitoring The Heart Rate

    Monitoring the heart rate The equipment is able to measure heart rate trends with a chest band with a heart rate transmitter (Polar T31). There must be no more than one transmitter in the reception range: otherwise the receiver may receive different signals at the same time and give incorrect heart readings.
  • Page 37 Monitoring the heart rate The following table shows the optimum heart rate levels in relation to age and the goal to be achieved. Theoretical maximum heart rate (100%) is calculated on the basis of age using the formula: 0 - age. 0507036 Area reserved for competitive athlete’s workouts (requiring Aerobic zone primarily using fats as energy source (keep...
  • Page 38 Monitoring the heart rate To read the graph, simply find your age on the horizontal axis and scan up the vertical until you reach the 60%, 70% and 90% values. Aerobic exercise performed at a heart rate between 60% and 70% mainly burns fat as an energy source. When doing aerobic exercise at a heart rate of 70% to 90% the cardiocirculatory component prevails.

  • Page 39: Using The Equipment

    Using the equipment The exercise can be performed standing up on the rear platforms; or sitting down, with your feet resting on one of the front platforms. Disabled persons can remove the seat and bring the wheelchair on the rear platform.
  • Page 40 Using the equipment anger Before sitting down make sure the seat is properly locked. Do not sit down in the seat, if it is not properly locked. IFI Version cont.
  • Page 41 Using the equipment To adjust the length of the handgrips levers push the knob (A) upwards, adjust the lever, then push the knob (A) downwards again to block the lever. To adjust the height of the handgrips lift or lower the block (B) with the lever (C). 0708105 cont.
  • Page 42 Using the equipment To adjust the seat, pull the lever under the seat and move the seat forward or backwards. 0708103 To remove the seat, pull the lever under the seat and move the seat backwards until it comes out of its seating. In this way the exercise can be performed standing up or a wheelchair can be inserted.
  • Page 43 Using the equipment IFI Version To adjust the seat, use the lever under the seat and move the seat forward or backwards. To remove the seat, pull the lever under the seat and move the seat backwards until it comes out of its seating. In this way the exercise can be performed standing up or a wheelchair can be inserted.
