  • Page 1: User Manual

    AIO-16 16-Channel Input/Output Card User Manual 9350-7726-000 July 2007 Rev H...
  • Page 2 PROPRIETARY NOTICE The product information and design disclosed herein were originated by and are the property of Telex Communications, Inc. Telex reserves all patent, proprietary design, manufacturing, reproduction, use and sales rights thereto, and to any article disclosed therein, except to the extent rights are expressly granted to others.

  • Page 3: Table Of Contents

    Firmware through AZedit ... 15 Chapter 3 AIO-16 Ports, DBX Linking, and Interconnects ... 17 AIO-16 Ports ... 17 ADAM AIO-16 DBX Link Mapping ... 36 High Density Wiring ... 36 Appendix A Breakout Panel Guide ... 39 Introduction ... 39 Installation ...

  • Page 5: Introduction

    Description Installed directly into the ADAM™ Matrix Intercom system, the AIO-16 card gives 16 ports of audio IN and OUT for each card installed (up to 17 cards) in the system. This doubles the amount of audio ports available from its predecessor the AIO-8.

  • Page 6: Features

    AIO-16 must use an existing XCP-40-RJ12, XCP-24 (Telco) or XCP-40-DB-9 breakout panel with the SCSI backcard. When the AIO-16 card is inserted into the system, it automatically figures the backcard configuration and the protocols being used. Along with the existing breakout panels, four new panels (DB-9, Telco, RJ-45, and DB-9-T) have been specially made to integrate with the new MDR backcard.
  • Page 7 SWT01 LED2 SB01 AIO-16 card top and bottom FIGURE 2.
  • Page 8 Optional AIO-16 LED Front Card (part number 9000-7726-001). FIGURE 3. RED LEDs CB RX task running CB TX task running Poll Panel 16 task running Poll Panel 15 task running Poll Panel 14 task running Poll Panel 13 task running...

  • Page 9: Specifications

    = 22 dBu bandwidth = 50 Hz to 20 kHz Connections - 4-wire balanced audio. Optional RS-485 data is available to communicate with keypanels. AIO-16 can be plugged into either a SCSI backcard or MDR backcard. SCSI Backcard (9000-7726-002) Backward compatibility to existing AIO-8 breakout panels.
  • Page 10 Lightly tighten down the AIO-16 card. Carefully attach the backcard (MDR or SCSI, see Figure 4 ) to the AIO-16 card from the back of the ADAM. Verify that it is properly seated against the AIO-16 card and is sitting firmly in the system.

  • Page 11: Power Supply Specifications

    Power Supply Specifications Output Output Output Output Rating Rating Rating Rating Adjustment Adjustment Adjustment The new ADAM power supply showing the top and the adjustment pots (lower picture. FIGURE 5. Adjustment...

  • Page 13: Chapter 2 Aio-16 And Azedit

    Select the Allow Intercom Resizing in ONLINE Mode checkbox. NOTE: You must use the Intercom Sizing Wizard if you are changing the number of frames, the number of ports, or the Intercom Setup options in your system. CHAPTER 2 AIO-16 and AZedit...
  • Page 14 To access the Intercom Sizing Wizard, do the following: Open AZedit. From the Options menu, select Intercom Configuration. A Warning appears. Click OK. Click Intercom Sizing Wizard. The Intercom Sizing Wizard begins. In ONLINE mode, the wizard will automatically determine your intercom system size, and then will walk you through to get more specific information to configure your system.

  • Page 15: I/O Card Status Screen

    Select your system from the list, then click Next. The Wizard will walk you through the rest of the setup. When you are finished, click Finish. I/O Card Status Screen To Open the I/O Card Status screen, do the following: In AZedit, from the Status menu, select I/O Cards.
  • Page 16 For example, 1:011 indicates the card is in Frame 1 and in slot 11. Ports display the ports that are designated to that slot. Ports Column This column shows the first half of the sixteen ports on an AIO-16. Ports display the ports that are designated to that slot. Ports Column This column shows the second half of the sixteen ports on an AIO-16.

  • Page 17: Download Aio-16 Firmware Through Azedit

    Click Begin Download. The download begins. When the download is finished, click OK. The AIO-16 firmware download is complete. This takes a minute or two to occur. Verify the version upgrade in the I/O Card Version Information window is correct.
  • Page 18 WARNING!: Do NOT power down the frame or pull the AIO-16 card(s) from the frame until you have verified the new version information from AZedit. If the card loses power while reprogramming the on-board flash memory, the card may become unbootable, and may need to have its flash chips reprogrammed.

  • Page 19: Ports, Dbx Linking, And Interconnects

    AIO-8 cards, the 16 channels had to be divided into two separate groups of eight channels per card (a bottom group and a top group). For example, if you have an AIO-16 card in slot one of an ADAM frame, the bottom group of eight channels will have ports 1-8 assigned to them, while the top group of eight channels will have ports 137-144 assigned to them, see below.
  • Page 20 Essentially, the port numbering is static, in that the port numbers used do not change whether you are using an AIO-8 or an AIO-16 card. Rather, it is a question of whether the ports shall or shall not exist. ADAM frame with both AIO-8 and AIO-16 cards.
  • Page 27 1 Frame 272 x 272 AIO-16 DBX Address and Port Locations Matrix Port / DIP Switch Table - ADAM272 Keypanel & TIF Rear DIP Switch Settings (DS-4 through DS-7) Matrix System U= Up Frame AIO Card D= Down & AIO...
  • Page 28 2 Frame Non-Redundant 512 x 512 AIO-16 DBX Address and Port Locations Matrix Port / DIP Switch Table - ADAM512 Matrix System Keypanel & TIF Rear DIP Switch Settings (DS-4 through DS-7) Frame AIO Card U= Up & AIO Number...
  • Page 29 2 Frame Non-Redundant 512 x 512 (cont.) AIO-16 DBX Address and Port Locations Matrix Port / DIP Switch Table - ADAM512 Matrix System Keypanel & TIF Rear DIP Switch Settings (DS-4 through DS-7) Frame AIO Card U= Up & AIO...
  • Page 30 2 Frame Redundant 480 x 480 AIO-16 DBX Address and Port Locations Matrix Port / DIP Switch Table - ADAM480 Matrix System Keypanel & TIF Rear DIP Switch Settings (DS-4 through DS-7) Frame AIO Card U= Up & AIO Number...
  • Page 31 2 Frame Redundant 480 x 480 (cont.) AIO-16 DBX Address and Port Locations Matrix Port / DIP Switch Table - ADAM480 Matrix System Keypanel & TIF Rear DIP Switch Settings (DS-4 through DS-7) Frame AIO Card U= Up & AIO...
  • Page 32 3 Frame Redundant 624 x 624 AIO-16 DBX Address and Port Locations Matrix Port / DIP Switch Table - ADAM 624 Matrix System Keypanel & TIF Rear DIP Switch Settings (DS-4 through DS-7) Frame AIO Card U= Up & AIO...
  • Page 33 2-3A 2-4A 2-5A 2-6A DBX Slots, Frame 2 2-11A 2-12A 2-13A 2-14A 2-15A 2-16A 2-17A 2-1B 2-2B 2-3B 2-4B 2-5B 2-6B Part of DBX Above 2-11B 2-12B 2-13B 2-14B 2-15B 2-16B 2-17B * DENOTES CLOCK CARD POSITIONS 3-1A 3-2A 3-3A 3-4A 3-5A 3-6A...
  • Page 34 3-13B 3-14B 3-15B 3-16B 3-17B 4 Frame Non-Redundant 896 x 896 AIO-16 DBX Address and Port Locations Matrix Port / DIP Switch Table - ADAM 896 Matrix System Keypanel & TIF Rear DIP Switch Settings (DS-4 through DS-7) Frame AIO Card U= Up &...
  • Page 35 1-16A 1-17A 1-1B 1-2B 1-3B 1-4B 1-5B 1-6B 1-7B Part of DBX Above 1-11B 1-12B 1-13B 1-14B 1-15B 1-16B 1-17B * DENOTES CLOCK CARD POSITIONS 2-1A 2-2A 2-3A 2-4A 2-5A 2-6A 2-7A DBX Slots, Frame 2 2-11A 2-12A 2-13A 2-14A 2-15A 2-16A 2-17A...
  • Page 36 Part of DBX Above 2-11B 2-12B 2-13B 2-14B 2-15B 2-16B 2-17B * DENOTES CLOCK CARD POSITIONS 3-1A 3-2A 3-3A 3-4A 3-5A 3-6A 3-7A DBX Slots, Frame 3 3-11A 3-12A 3-13A 3-14A 3-15A 3-16A 3-17A 3-1B 3-2B 3-3B 3-4B 3-5B 3-6B 3-7B Part of DBX Above 3-11B...
  • Page 37 * DENOTES CLOCK CARD POSITIONS 4-1A 4-2A 4-3A 4-4A 4-5A 4-6A 3-7A DBX Slots, Frame 4 4-11A 4-12A 4-13A 4-14A 4-15A 4-16A 4-17A 4-1B 4-2B 4-3B 4-4B 4-5B 4-6B 4-7B Part of DBX Above 4-11B 4-12B 4-13B 4-14B 4-15B 4-16B 4-17B * DENOTES CLOCK CARD POSITIONS...

  • Page 38: Adam Aio-16 Dbx Link Mapping

    ADAM AIO-16 DBX Link Mapping High Density Wiring...

  • Page 41: Breakout Panel Guide

    Introduction Breakout Panels provide a convenient way of expanding the port capacity of an ADAM intercom system. Currently there are nine breakout panels for use with breakout panels: XCP-32-DB9, XCP-16-DB9-T, XCP- 48-RJ45, XCP-Telco, XCP-40-DB9, XCP-40-RJ11, XCP-24, XCP-24-USCO, XCP-ADAM-MC, XCP-954and XCP-955. Installation Requirements •...

  • Page 43: Xcp-32-Db9 - 9000-7810-000

    The XCP-32-DB9 is the newly created 32-port DB9 breakout panel with MDR connector for the ADAM with an AIO-16 card and Cronus. It allows you to expand the number of DB-9 serial ports. The XCP-32-DB9 is backward compatible with the AIO-8 card.
  • Page 44 MDR Connector Number Port Function Data + Data - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Data + Data - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Data + Data -...

  • Page 45: Xcp-16-Db9-T - 9000-7837-000

    91007837-000 REV A The XCP-16-DB9-T is the newly created 16-port DB9 breakout panel with MDR connector and an audio transformer for the Cronus and AIO-16. It allows you to expand the number of DB-9 serial ports in the Intercom system.
  • Page 46 MDR Connector Number Port Audio From Matrix - Data + Data - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Data + Data - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Data +...

  • Page 47: Xcp-48-Rj45 - 9000-7809-000

    18.98” (482mm) W x 1.69” (43mm) H x 2.95” (75mm) D Weight: 3.5 lb. (1.59 kg) NOTE: When using the 48-port RJ-45 breakout panel, you MUST use the MDR backcard for both the AIO-16 and Cronus. The arrows represent the MDR to RJ-45 connection responsibility CHAPTER 9...
  • Page 48 MDR Connector Number Port Audio To Matrix - Audio From Matrix + Audio From Matrix - Data + Data - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Data + Data - Audio To Matrix + Audio To Matrix - Audio From Matrix +...

  • Page 49: Xcp-40-Db9 - 9000-7515-000

    The XCP-40-DB9 breakout panel allows for the expansion of the ADAM frame at 40+, 80+, and 120+. When using the 40- port DB-9 breakout panel, you must use the SCSI backcard with the AIO-16 card. Specifications Dimensions: 19” (482.6mm) W x 3.5” (88.9mm) H x 1.25” (31.75mm) D Weight: 1.95 lb.
  • Page 50 SCSI Connector - J1, J2, J3, J4, J5 Number Port Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Audio To Matrix + Audio To Matrix - Audio From Matrix +...

  • Page 51: Xcp-40-Rj11 - 9000-7494-000

    The XCP-40-RJ-12 Breakout Panel allows for the expansion of the ADAM frame using RJ-12 connectors. When using the 40- port RJ-12 breakout panel, you MUST use the SCSI backcard with the AIO-16 card. Specifications Dimensions: 19” (482.6mm) W x 3.5” (88.9mm) H x 1.25” (31.75mm) D Weight: 1.75 lb.
  • Page 52 SCSI Connector - J1, J2, J3, J4, J5 Number Port Audio To Matrix - Audio From Matrix + Audio From Matrix - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix -...

  • Page 53: 9000-7559-000

    The XCP-24 Breakout Panel allows for the expansion of the ADAM frame using TELCO connectors. When using the XCP-24 breakout panel, you must use the SCSI backcard with the AIO-16 card. Specifications Dimensions: 18.98” (482mm) W x 1.69” (43mm) H x.354” (9mm) D Weight: 1 lb.
  • Page 54 SCSI Connector - J1, J2, J3, J4, J5 Number Port Audio From Matrix - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Audio To Matrix + Audio To Matrix -...
  • Page 55 Telco Backcard - Telco Connector - J1 Number Port Function Audio To Matrix + Audio To Matrix - Audio To Matrix + Audio To Matrix - Audio To Matrix + Audio To Matrix - Audio To Matrix + Audio To Matrix - Audio To Matrix + Audio To Matrix - Telco Backcard - Telco Connector - J2...
  • Page 56 Telco Backcard - Telco Connector - J2 Number Port Audio From Matrix + Audio From Matrix - Audio From Matrix + Audio From Matrix - Telco Backcard - Telco Connector - J3 Number Port Data + 25-33 Data - 9-16 9-16 Data + 34-41...

  • Page 57: Xcp-24-Usoc - 9000-7559-001

    The XCP-24-USOC Breakout Panel allows for the expansion of the ADAM frame using Telco connectors. When using the XCP-24-USOC breakout panel, you MUST use the SCSI backcard with the AIO-16 card Specifications Dimensions: 18.98” (482mm) W x 1.69” (43mm) H x.354” (9mm) D Weight: 1 lb.
  • Page 58 SCSI Connector - J4, J5, J6 Number Port Audio From Matrix - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Audio To Matrix + Audio To Matrix -...
  • Page 59 Telco Connector - J1 Number Port Function Audio From Matrix - Audio From Matrix + Data - Data + Telco Connector Port 9-16 17-24...

  • Page 61: Xcp-Adam-Mc - 9000-7556-000

    XCP-ADAM-MC UIO/PAP/ AZedit #1 General Trunking Purpose System The XCP-ADAM-MC Breakout Panel affords the ADAM more connections to frame accessories without losing the connections to AZedit, and the ability to Trunk systems. Specifications Dimensions: 18.98” (482mm) W x 1.69” (43mm) H x.472” (12mm) D Weight: 1 lb.
  • Page 62 AZedit #1 68-pin J-1 of Master XCP-ADAM- Controller Trunking System 68-pin J-2 of Master XCP- Controller ADAM-MC UIO-256/PAP/LCP 68-pin J-3 of Master XCP- Controller ADAM-MC Assignment RS485 TX/ RS232C RX RS232C TX RS422 TX- Ground Ground RS422 TX+ RS485 TX/ Controller Assignment RS485 TX/...
  • Page 63 General Purpose / Bus Exp. J-6 of 68-pin Master XCP-ADAM- Assignment Controller RS485 TX/ Ground Not Used Not Used Not Used RS485 TX/ Ground Not Used Not Used General Purpose / Bus Exp. J-7 of 68-pin Master XCP-ADAM- Assignment Controller RS485 TX/RX- Ground Not Used...
  • Page 64 General Purpose Assignment MI (0) MI (1) MI (2) MI (3) MI (4) MI (5) MI (6) MI (7) Ground Ground Ground Ground Ground MO (0) MO (1) MO (2) MO (3) MO (4) MO (5) MO (6) MO (7) Ground Ground Ground...

  • Page 65: Xcp-955 8800303674

    RTS SYSTEMS XCP-955 DATA The XCP-955 is the 25-port RJ-11 breakout panel with SCSI connector for the ADAM. Specifications Dimensions: 18.98” (482mm) L x 1.69” (43mm) H x 0.55” (104mm) D Weight: 1.6 lb (.725 kg) AUDIO DESTINATION AUDIO SOURCE RJ-12 Connector Pin 1 Pin 2...
  • Page 66 Telco Backcard - Telco Connector - J26 Number Port Function Audio From Matrix + Audio From Matrix - Audio From Matrix + Audio From Matrix - Audio From Matrix + Audio From Matrix - Audio From Matrix + Audio From Matrix - Audio From Matrix + Audio From Matrix - Audio From Matrix +...
  • Page 67 Telco Backcard - Telco Connector - J27 Number Port Function Audio To Matrix - Audio To Matrix + Audio To Matrix - Audio To Matrix + Audio To Matrix - Audio To Matrix + Audio To Matrix - Audio To Matrix + Audio To Matrix - Audio To Matrix + Audio To Matrix -...
