- Page 1 Breakout Panel Resource Guide includes: XCP-955 XCP-32-DB9 XCP-16-DB9-T XCP-48-RJ45 XCP-48-TELCO XCP-40-DB9 XCP-40-RJ11 XCP-24 XCP-24-USOC XCP-ADAM-MC LIT000061000 July 2006 Rev E...
-
Page 3: Table Of Contents
Contents Breakout Panel Introduction ... 1 XCP-955 - 8800303674 ... 3 XCP-32-DB9 - 9000-7810-000 ... 7 XCP-16-DB9-T - 9000-7837-000 ... 9 XCP-48-RJ45 - 9000-7809-000 ... 11 XCP-48-Telco - 9000-7822-000 ... 13 XCP-40-DB9 - 9000-7515-000 ... 19 XCP-40-RJ11 - 9000-7494-000 ... 21 XCP-24 - 9000-7559-000 ... -
Page 5: Breakout Panel Introduction
Breakout Panels provide a convenient way of expanding the port capacity of an ADAM intercom system. Currently, there are seven breakout panels for use with the AIO cards: XCP-32-DB9, XCP-16-DB9-T,XCP-48-RJ45, XCP-48-Telco, XCP-40- DB9, XCP-40-RJ11, XCP-955, XCP-24, and the XCP-24-USOC. Installation Requirements •... - Page 6 Breakout Panel Introduction To install the AIO-16 card for the first time, do the following: Gently insert the AIO-16 card into the appropriate ADAM slot. Lightly tighten down the AIO-16 card. Carefully attach the backcard (MDR or SCSI,) to the AIO-16 card from the back of the ADAM. Verify it is properly seated against the AIO-16 card and is sitting firmly in the system.
-
Page 7: Xcp-955 - 8800303674
RTS SYSTEMS XCP-955 DATA The XCP-955 is the 25-port RJ-11 breakout panel with SCSI connector for the ADAM. Specifications Dimensions: 18.98” (482mm) L x 1.69” (43mm) H x 0.55” (104mm) D Weight: 1.6 lb (.725 kg) AUDIO DESTINATION AUDIO SOURCE RJ-12 Connector Pin 1 Pin 2... - Page 8 XCP-955 8800303674 Telco Backcard - Telco Connector - J26 Number Port Function Audio From Matrix + Audio From Matrix - Audio From Matrix + Audio From Matrix - Audio From Matrix + Audio From Matrix - Audio From Matrix + Audio From Matrix - Audio From Matrix + Audio From Matrix -...
- Page 9 Specifications Telco Backcard - Telco Connector - J27 Number Port Function Audio To Matrix - Audio To Matrix + Audio To Matrix - Audio To Matrix + Audio To Matrix - Audio To Matrix + Audio To Matrix - Audio To Matrix + Audio To Matrix - Audio To Matrix + Audio To Matrix -...
- Page 10 XCP-955 8800303674...
-
Page 11: Xcp-32-Db9 - 9000-7810-000
NOTE: When using the 32-port DB-9 breakout panel, you MUST use the MDR backcard for both the AIO-16 and Cronus. CHAPTER 3 XCP-32-DB9 9000-7810-000 TELEX COMMUNICATIONS, INC. MADE IN U.S.A. J400 9-pin Male D-sub Pin 1 Keypanel Data + Pin 2... - Page 12 XCP-32-DB9 9000-7810-000 MDR Connector Number Port Function Data + Data - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Data + Data - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Data + Data -...
-
Page 13: Xcp-16-Db9-T - 9000-7837-000
MADE IN U.S.A. 91007837-000 REV A 91007837-000 REV A The XCP-16-DB9-T is the newly created 16-port DB9 breakout panel with MDR connector and an audio transformer for the Cronus and AIO-16. It allows you to expand the number of DB-9 serial ports in the Intercom system. -
Page 14: Pin
XCP-16-DB9-T 9000-7837-000 MDR Connector Number Port Audio From Matrix - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix -... -
Page 15: Pin 1
MUST use the MDR backcard for both the AIO-16 and Cronus. The arrows represent the MDR to RJ-45 connection responsibility CHAPTER 5 XCP-48-RJ45 9000-7809-000 TELEX COMMUNICATIONS, INC. MADE IN U.S.A. RJ-45 Pin 1 Pin 2 Keypanel Data - Pin 3... -
Page 16: Audio From Matrix
XCP-48-RJ45 9000-7809-000 MDR Connector Number Port Audio To Matrix - Audio From Matrix + Audio From Matrix - Data + Data - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Data + Data - Audio To Matrix + Audio To Matrix -... -
Page 17: Xcp-48-Telco - 9000-7822-000
Telco Connector (J1 - J6) J100 XCP48-TELCO The XCP-48-Telco is the newly created breakout panel with MDR connector for the AIO-16 and Cronus. It combines the audio to matrix, audio from matrix, and data pairs. It then routes them on individual Telco connectors. It allows you to connect to 48 ports on the Intercom system. - Page 18 XCP-48-Telco 9000-7822-000 MDR Connector Number Port Data + Data - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Data + Data + Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Data + Data +...
- Page 19 XCP-48-Telco 9000-7822-000 Telco Connector - J1, J4 Number Port Audio to Matrix + Audio to Matrix - Audio to Matrix + Audio to Matrix - Audio to Matrix + Audio to Matrix - Audio to Matrix + Audio to Matrix - Audio to Matrix + Audio to Matrix - Audio to Matrix +...
- Page 20 XCP-48-Telco 9000-7822-000 Telco Connector - J2, J5 Number Port Audio from Matrix - Audio from Matrix + Audio from Matrix - Audio from Matrix + Audio from Matrix - Audio from Matrix + Audio from Matrix - Audio from Matrix + Audio from Matrix - Audio from Matrix + Audio from Matrix -...
- Page 21 XCP-48-Telco 9000-7822-000 Telco Connector - J3, J6 Number Port Data + Data - Data + Data - Data + Data - Data + Data - Data + Data - Data + Data - Function...
- Page 22 XCP-48-Telco 9000-7822-000...
-
Page 23: Xcp-40-Db9 - 9000-7515-000
J21 J22 J23 J24 J29 J30 J31 J32 CHAPTER 7 XCP-40-DB9 9000-7515-000 J33 J34 J35 J36 J37 J38 J39 J40 Telex Communications, Inc. Made in U.S.A. 9-pin Male D-sub Pin 1 Keypanel Data + Pin 2 Keypanel Data - Pin 3... - Page 24 XCP-40-DB9 9000-7515-000 SCSI Connector - J1, J2, J3, J4, J5 Number Port Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Audio To Matrix + Audio To Matrix -...
-
Page 25: Xcp-40-Rj11 - 9000-7494-000
J17 J18 J19 J20 J13 J14 J15 J16 J21 J22 J23 J24 J29 J30 J31 J32 XCP-40-RJ11 9000-7494-000 J33 J34 J35 Telex Communications, Inc. Made in U.S.A. J37 J38 J39 J40 RJ-12 Connector Pin 1 Keypanel Data - Pin 2... - Page 26 XCP-40-RJ11 9000-7494-000 SCSI Connector - J1, J2, J3, J4, J5 Number Port Audio To Matrix - Audio From Matrix + Audio From Matrix - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Audio To Matrix + Audio To Matrix - Audio From Matrix +...
-
Page 27: Specifications
SCSI Connector (J4 - J6) Telco Connector (J1 - J3) Figure 4. The XCP-24 Breakout Panel allows for the expansion of the ADAM frame using TELCO connectors. When using the XCP-24 breakout panel, you must use the SCSI backcard with the AIO-16 card. Specifications Dimensions: 18.98”... - Page 28 XCP-24 9000-7559-000 SCSI Connector - J1, J2, J3, J4, J5 Number Port Audio From Matrix - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Audio To Matrix +...
- Page 29 XCP-24 9000-7559-000 Telco Backcard - Telco Connector - J1 Number Port Audio To Matrix + Audio To Matrix - Audio To Matrix + Audio To Matrix - Audio To Matrix + Audio To Matrix - Audio To Matrix + Audio To Matrix - Audio To Matrix + Audio To Matrix - Telco Backcard - Telco Connector - J2...
- Page 30 XCP-24 9000-7559-000 Telco Backcard - Telco Connector - J2 Number Port Audio From Matrix + Audio From Matrix - Audio From Matrix + Audio From Matrix - Telco Backcard - Telco Connector - J3 Number Port Data + 25-33 Data - 9-16 9-16 Data +...
-
Page 31: Xcp-24-Usoc - 9000-7559-001
Telco Connector (J1 - J3) The XCP-24-USOC Breakout Panel allows for the expansion of the ADAM frame using Telco connectors. When using the XCP-24-USOC breakout panel, you MUST use the SCSI backcard with the AIO-16 card Specifications Dimensions: 18.98” (482mm) W x 1.69” (43mm) H x.354” (9mm) D Weight: 1 lb. - Page 32 XCP-24-USOC 9000-7559-001 SCSI Connector - J4, J5, J6 Number Port Audio From Matrix - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Audio To Matrix + Audio To Matrix - Audio From Matrix + Audio From Matrix - Audio To Matrix + Audio To Matrix -...
- Page 33 Specifications Telco Connector - J1 Number Port Function Audio From Matrix - Audio From Matrix + Data - Data + Telco Connector Port 9-16 17-24...
- Page 34 XCP-24-USOC 9000-7559-001...
-
Page 35: Xcp-Adam-Mc - 9002-7514-100
XCP-ADAM-MC UIO/PAP/ AZedit #1 General Trunking Purpose System The XCP-ADAM-MC Breakout Panel affords the ADAM more connections to frame accessories without losing the connections to AZedit, and the ability to Trunk systems. Specifications Dimensions: 18.98” (482mm) W x 1.69” (43mm) H x.472” (12mm) D Weight: 1 lb. - Page 36 XCP-ADAM-MC 9002-7514-100 AZedit #1 68-pin J-1 of Master XCP-ADAM- Controller Trunking System 68-pin J-2 of Master XCP- Controller ADAM-MC UIO-256/PAP/LCP 68-pin J-3 of Master XCP- Controller ADAM-MC Assignment RS485 TX/ RS232C RX RS232C TX RS422 TX- Ground Ground RS422 TX+ RS485 TX/ Controller Assignment...
- Page 37 XCP-ADAM-MC 9002-7514-100 General Purpose / Bus Exp. J-6 of 68-pin Master XCP-ADAM- Controller General Purpose / Bus Exp. J-7 of 68-pin Master XCP-ADAM- Controller General Purpose / Bus Exp. J-8 of 68-pin Master XCP-ADAM- Controller Assignment 68-pin Master Controller RS485 TX/ Ground Not Used Not Used...
- Page 38 XCP-ADAM-MC 9002-7514-100 General Purpose Assignment MI (0) MI (1) MI (2) MI (3) MI (4) MI (5) MI (6) MI (7) Ground Ground Ground Ground Ground MO (0) MO (1) MO (2) MO (3) MO (4) MO (5) MO (6) MO (7) Ground Ground...
