Summary of Contents for JUMO TAROS S46 H
- Page 1 JUMO TAROS S46 H Pressure Transmitter Operating Manual 40207100T90Z001K000 V2.01/EN/00705001/2021-10-14...
-
Page 3: Table Of Contents
Contents Contents Safety information..........4 Introduction . -
Page 4: Safety Information
Safety information 1 Safety information General This manual contains information that must be observed in the interest of your own safety and to avoid material damage. This information is supported by symbols which are used in this manual as indicated. Please read this manual before starting up the device. - Page 5 1 Safety information DISPOSAL! At the end of its service life, the device and any batteries present do not belong in the trash! Please en- sure that they are disposed of properly and in an environmentally friendly manner.
-
Page 6: Introduction
The pressure transmitter is used to acquire relative and absolute pressures in liquid and gaseous media. The JUMO TAROS S46 H with analog output signal has been developed specifically for hygienic appli- cations. The pressure transmitter has a pressure measuring cell with a piezoresistive silicon sensor. The pressure is converted into an electrical current or voltage signal and output via various electrical connec- tions. -
Page 7: Identifying The Device Version
Identifying the device version 3 Identifying the device version Nameplate Position The nameplate is laser-etched on the device surface. Table of contents The nameplate shows important information. This includes: Description Designation on the nameplate Example Device type 402071/000 Part no. 00123456 Measuring range 0 to 0.1 bar relative pressure... -
Page 8: Order Details
3 Identifying the device version Order details Basic type 402071 JUMO TAROS S46 H – pressure transmitter Basic type extension None a, b Autoclave-compatible version Relative-pressure version without zero point adjustment Special version Input -1 to 0 bar relative pressure -1 to +0.6 bar relative pressure... - Page 9 Tank connection with grooved union nut DN 25 Tank connection with grooved union nut DN 40 VARIVENT® connection DN 32/25 VARIVENT® connection DN 50/40 JUMO PEKA hygienic process connection Process connection material Stainless steel 1.4404/1.4435 Electrical connection Attached cable, shielded, length of 2 m Round plug M12 ×...
-
Page 10: Accessories
3 Identifying the device version The maximum measuring range that can be used is based on the clamp's pressure stage. Not possible with electrical connection 12 (attached cable). Order code Order example 402071 - 613 - 374,870 Accessories NOTE! The following accessories are not UL-approved. Item Part no. -
Page 11: Mounting
Mounting 4 Mounting General information NOTE! Check that the device is compatible with the measurement medium chapter 8.4 "Environmental in- fluences", Page 21. Mounting site • Ensure that the device is fastened safely and with low vibrations • Avoid direct sunlight •... -
Page 12: Dimensions
4 Mounting Dimensions 4.2.1 Transmitter with electrical connections Attached cable, length of 2 m (standard) Round plug M12 × 1 L (mm) 604, 607, 613, 616, 685, 686, 997 652, 653 Line socket DIN EN 175301-803, form A Terminal head L (mm) M (mm) 604, 607, 613, 616,... -
Page 13: Process Connections
4 Mounting 4.2.2 Process connections Taper socket with union nut DN 25 Taper socket with union nut DN 50 Ø 92 Ø 63 Clamping socket (clamp) DN 25, 32, 40 Clamping socket (clamp) DN 50 Ø 50.5 Ø 64 Tank connection with grooved union nut DN 25 (includ- Tank connection with grooved union nut DN 40 (includ- ing welding socket) ing welding socket) -
Page 14: Important Information For Usage According To Ehedg
4 Mounting JUMO PEKA Ø 36 NOTE! Detailed specifications on the JUMO PEKA process connection system can be found in data sheet 409711. Other process connections upon request! Important information for usage according to EHEDG The following process connections are suitable for usage according to EHEDG: •... -
Page 15: Electrical Connection
Electrical connection 5 Electrical connection Installation notes NOTE! The electrical connection must only be performed by qualified personnel. The electromagnetic compatibility meets standard DIN EN 61326. Do not connect any additional loads to the voltage supply of the device. The device is not suitable for installation in potentially explosive areas. Connection diagram Connection Terminal assignment... -
Page 16: Operation
A suitable magnet is available from JUMO as an accessory (part no. 00736330). This provides a quick and simple way to correct zero point offsets caused by the installation or zero point offsets that have arisen following autoclaving, for example. -
Page 17: Maintenance, Cleaning And Returns
When servicing the transmitter, check its surface temperature and, if necessary, wait until it has cooled. Returns NOTE! In case of abnormalities, please send the device to the manufacturer together with a completed cover note for product returns. You can download a blank copy of this cover note online at: http://produktruecksendung.jumo.info. -
Page 18: Technical Data
Technical data 8 Technical data Mechanical features Materials of parts coming into contact with the pressurized medium Membrane Stainless steel 1.4435 (316 L) O-ring/sealing ring FPM, others available as an optional extra (e.g. EPDM, VMQ) Process connection Stainless steel 1.4404 (316 L) Welding ring Stainless steel 1.4404 (316 L) Materials of other parts... - Page 19 8 Technical data Measuring range Linearity Accuracy at Long- Overload Burst term capabili- pressure 20 °C -20 to -20 to stability +80 °C +100 °C % MSP % MSP % MSP % MSP % MSP per year 0 to 2.5 bar relative pressure 0.15 ≤...
-
Page 20: Electrical Data
8 Technical data Electrical data Voltage supply 2-wire circuit 4 to 20 mA DC 8 to 30 V, nominal voltage DC 24 V 3-wire DC 0 to 10 V DC 11.5 V to 30 V, nominal voltage DC 24 V DC 1 to 5 V DC 10 V to 30 V, nominal voltage DC 24 V DC 1 to 6 V... -
Page 21: Environmental Influences
8 Technical data Environmental influences Admissible temperatures Ambient temperature Medium temperature Storage temperature with MSP ≤ 0.4 bar -20 to +85 °C -20 °C to +125 °C -20 to +100 °C with MSP > 0.4 bar -40 to +85 °C -40 to +125 °C -40 to +100 °C MSP = measuring span... -
Page 22: Approvals And Approval Marks
Clamp DN 50 with Tri-Clamp seals Combifit International B.V. Process connection 685 VARIVENT® DN 32/25 with EPDM O-ring Process connection 686 VARIVENT® DN 50/40 with EPDM O-ring Process connection 997 JUMO PEKA with FKM O-ring Test facility Промтехконтроль Certificate/certification number ЕАЭС N RU Д-DE.PA01.В.80830/21 Inspection basis... -
Page 23: China Rohs
China RoHS 9 China RoHS 3URGXFW JURXS &KLQD ((3 +D]DUGRXV 6XEVWDQFHV ,QIRUPDWLRQ &RPSRQHQW 1DPH +J &G &U 9, 3%'( +RXVLQJ *HKlXVH 3URFHVV FRQQHFWLRQ 3UR]HVVDQVFKOXVV 1XWV 0XWWHU 6FUHZ 6FKUDXEH ^: d 7KLV WDEOH LV SUHSDUHG LQ DFFRUGDQFH ZLWK WKH SURYLVLRQV 6-7 *%7 ,QGLFDWH WKH KD]DUGRXV VXEVWDQFHV LQ DOO KRPRJHQHRXV PDWHULDOV¶... - Page 24 JUMO GmbH & Co. KG JUMO Instrument Co. Ltd. JUMO Process Control, Inc. Street address: JUMO House 6733 Myers Road Moritz-Juchheim-Straße 1 Temple Bank, Riverway East Syracuse, NY 13057, USA 36039 Fulda, Germany Harlow, Essex, CM20 2DY, UK Delivery address:...
