Programming
Parameter International
default parameter
value
22-85 Speed at 1500 RPM
Design Point [RPM]
See Note 3
22-86 Speed at 50 Hz
Design Point [Hz]
24-04 Fire Mode 50 Hz
Max Reference
Table 5.1 International/North American Default Parameter Settings

5.5 Parameter Menu Structure

Establishing the correct programming for applications
often requires setting functions in several related
parameters. These parameter settings provide the
frequency converter with system details it needs to
operate properly. System details may include such things
as input and output signal types, programming terminals,
minimum and maximum signal ranges, custom displays,
automatic restart, and other features.
•
See the LCP display to view detailed parameter
programming and setting options
•
Press [Info] in any menu location to view
additional details for that function
•
Press and hold [Main Menu] to enter a parameter
number for direct access to that parameter
•
Details for common application set ups are
provided in 6 Application Examples
VLT ® AQUA Drive D-Frame
Operating Instructions
North American
default parameter
value
1800 RPM
60 Hz
60 Hz
®
