ICON Health & Fitness NordicTrack S50 User Manual
  1. Manuals
  2. Brands
  3. ICON Health & Fitness Manuals
  4. Treadmill
  5. NordicTrack S50
  6. User manual

ICON Health & Fitness NordicTrack S50 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Model No. NETL15819.0
Serial No.
Write the serial number in the space
above for reference.
Serial
Number
Decal
CUSTOMER SERVICE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 4, Westgate Court
Silkwood Park
OSSETT
WF5 9TT
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Save this
manual for future reference.
USER'S MANUAL
iconeurope.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NordicTrack S50 and is the answer not in the manual?

Questions and answers

patrick
May 6, 2025

how to factory reset nordictrack S50 treadmill

0
1 comments:
Mr. Anderson
May 18, 2025

To factory reset the NordicTrack S50 treadmill:

1. Locate the small reset opening on the back edge of the console.
2. Insert a bent paper clip into the opening and press and hold the reset button inside.
3. While holding the reset button, have a second person turn the power switch to the ON position.
4. Continue holding the reset button until the console turns on.
5. When the reset is complete, the console will turn off and then back on.
6. If it does not restart, turn the treadmill off and then on again using the power switch.

This answer is automatically generated

0

Related Manuals for ICON Health & Fitness NordicTrack S50

Summary of Contents for ICON Health & Fitness NordicTrack S50

  • Page 1 Model No. NETL15819.0 Serial No. Write the serial number in the space USER’S MANUAL above for reference. Serial Number Decal CUSTOMER SERVICE UNITED KINGDOM Call: 0330 123 1045 From Ireland: 053 92 36102 Website: iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. Unit 4, Westgate Court Silkwood Park OSSETT...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 19. When a person is walking on the treadmill, 24. When folding or moving the treadmill, make the noise level of the treadmill will increase. sure that the storage latch is holding the frame securely in the storage position. Do 20.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new NORDICTRACK manual. To help us assist you, note the product model ® S 50 treadmill. The S 50 treadmill provides an impres- number and serial number before contacting us. The sive selection of features designed to make your model number and the location of the serial number workouts at home more effective and enjoyable.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • Assembly requires two persons. • To identify small parts, see page 6. • Place all parts in a cleared area and remove the • Assembly requires the following tools: packing materials. Do not dispose of the packing the included hex keys materials until you finish all assembly steps.
  • Page 8 2. Make sure that the power cord is unplugged. Remove the tie securing the Upright Wire (81) to the front of the Base (6). Next, identify the Right Upright (90). Have a second person hold the Right Upright near the Base (6).
  • Page 9 4. Hold the Right Upright (90) against the Base (6). Make sure not to pinch the Upright Wire (81). Attach the Right Upright (90) with two 3/8" x 2 3/8" Screws (7), a 3/8" x 1 1/4" Screw (63), a 3/8" x 1 3/4" Screw (62), and four 3/8" Star Washers (13) as shown;...
  • Page 10 6. If there are four screws (E) preattached inside the Right and Left Handrails (84, 85), remove and discard the screws (only one side is shown). Identify the Right Handrail (84). Attach the Right Handrail (84) to the Right Upright (90) with two 5/16" x 3" Screws (28) and two 5/16"...
  • Page 11 8. IMPORTANT: To avoid damaging the Pulse Crossbar (23), do not use power tools and do not overtighten the #10 x 1 1/4" Screws (9). Orient the Pulse Crossbar (23) as shown. Attach the Pulse Crossbar to the Handrails (84, 85) with four #10 x 1 1/4"...
  • Page 12 10. Set the console assembly (G) on the Right and Left Handrails (84, 85). Make sure that no wires are pinched. Insert the excess Upright Wire (81) into the Right Upright (90). Attach the console assembly (G) with four 1/4" x 1/2"...
  • Page 13 12. Orient the Upright Crossbar (93) as shown. Carefully slide the Upright Crossbar (93) between the Left and Right Uprights (89, 90). Attach the Upright Crossbar (93) with the four 5/16" x 3/4" Screws (8) that you removed in step 5 and four 5/16" Star Washers (11); start all four Screws, and then tighten them.
  • Page 14 14. Raise the Frame (56) to the upright position. Have a second person hold the Frame until step 16 is completed. Remove the two 5/16" x 3/4" Screws (8) from the Latch Crossbar (41). Orient the Latch Crossbar (41) as shown. Make sure that the “This side toward belt”...
  • Page 15 16. Remove the 5/16" Nut (34) and the 5/16" x 2" Bolt (31) from the bracket on the Latch Crossbar (41). Align the upper end of the Storage Latch (26) with the bracket on the Latch Crossbar (41), and insert the 5/16" x 2" Bolt (31) through the bracket and the Storage Latch.

  • Page 16: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO PLUG IN THE POWER CORD Follow the steps below to plug in the power cord. This product must be earthed. If it should malfunc- 1. Plug the indicated end of the power cord into the tion or break down, earthing provides a path of least socket on the treadmill.
  • Page 17 CONSOLE DIAGRAM FEATURES OF THE CONSOLE In addition, the console features a selection of workouts. Each workout automatically controls the The advanced treadmill console offers a selection of speed and incline of the treadmill as it guides you features designed to make your workouts more effec- through an effective exercise session.
  • Page 18 HOW TO TURN ON THE POWER HOW TO USE THE TOUCH SCREEN IMPORTANT: If the treadmill has been exposed to The console features a tablet with a full-color touch cold temperatures, allow it to warm to room tem- screen. The following information will help you become perature before you turn on the power.
  • Page 19 HOW TO SET UP THE CONSOLE 6. Calibrate the incline system. Before using the treadmill for the first time, set up the First, touch your name in the upper-left corner. console. Next, select the settings main menu. Then, select the maintenance section, touch the Calibrate 1.
  • Page 20 HOW TO USE THE MANUAL MODE To stop the walking belt, press the Stop button or tap the middle of the screen. To restart the walking 1. Insert the key into the console. belt, press the Start button. 4. Change the incline of the treadmill as desired. See HOW TO TURN ON THE POWER on page 18.
  • Page 21 To measure your heart rate, stand on the foot • Your pace rails and hold the contacts with your palms for • The speed of the walking belt approximately ten seconds; avoid moving your hands. When your pulse is detected, your heart rate will be shown.
  • Page 22 HOW TO USE A MAP WORKOUT 5. Monitor your progress with the display modes. Note: To use a map workout, the console must be con- See step 5 on page 20. nected to a wireless network (see HOW TO USE THE 6.
  • Page 23 HOW TO USE A DISTANCE OR TIME WORKOUT The screen will display the elevation and distance statistics for your workout. If desired, you can change the default speed. Note: To use a distance or time workout, the console must be connected to a wireless network (see HOW 4.
  • Page 24 5. Select a distance or time workout that you have HOW TO USE THE WORKOUT SETTINGS SECTION previously added to your schedule on iFit.com. 1. Select the settings main menu. Touch the calendar icon to download a distance or time workout from your schedule. Insert the key into the console (see HOW TO TURN ON THE POWER on page 18).
  • Page 25 HOW TO USE THE EQUIPMENT SETTINGS HOW TO USE THE MAINTENANCE SECTION SECTION 1. Select the settings main menu. 1. Select the settings main menu. See step 1 on page 24. See step 1 on page 24. 2. Select the maintenance section. 2.
  • Page 26 4. Calibrate the incline system of the treadmill. HOW TO USE THE WIRELESS NETWORK MODE Touch the Calibrate Incline button. Then, touch the The console features a wireless network mode that Begin button to calibrate the incline system. The allows you to set up a wireless network connection. treadmill will automatically rise to the maximum incline level, lower to the minimum incline level, 1.
  • Page 27 HOW TO USE THE SOUND SYSTEM To use the keyboard, see HOW TO USE THE TOUCH SCREEN on page 18. To play music or audio books through the console When the console is connected to your wireless sound system while you exercise, plug a 3.5 mm male network, a checkmark will appear next to the wire- to 3.5 mm male audio cable (not included) into the less network name.
  • Page 28 HOW TO ADJUST THE CUSHIONS The treadmill features a cushioning system that reduces the impact as you walk or run on the treadmill. To adjust the cushions, first remove the key from the console and unplug the power cord. You may also need to place the treadmill in the storage position (see HOW TO FOLD THE TREADMILL on page 29).

  • Page 29: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.

  • Page 30: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE c. Check the power switch located on the treadmill frame near the power cord. If the switch protrudes Regular maintenance is important for optimal per- as shown, the switch has tripped. To reset the formance and to reduce wear. Inspect and properly power switch, wait for five minutes and then press tighten all parts each time the treadmill is used.
  • Page 31 SYMPTOM: The displays of the console do not b. If the console does not boot up properly, or function properly if the console freezes and does not respond, reset the console to the factory default settings. a. Remove the key from the console and UNPLUG IMPORTANT: Doing this will erase all the THE POWER CORD.
  • Page 32 SYMPTOM: The walking belt slows when walked on SYMPTOM: The walking belt is not centered between the foot rails a. If an extension cord is needed, use only a 3-conduc- a. IMPORTANT: If the walking belt rubs against tor, 14-gauge (2 mm ) cord that is no longer than the foot rails (D), the walking belt may become 5 ft.

  • Page 33: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 34: Part List

    PART LIST Model No. NETL15819.0 R0619B Key No. Qty. Description Key No. Qty. Description #8 x 5/8" Screw Drive Roller/Pulley #8 x 3/4" Screw Right Inner Base Cover Base Pad 3/8" Plastic Bushing 1/4" x 1/2" Screw 3/8" Washer #10 Star Washer 1/4"...
  • Page 35 Key No. Qty. Description Key No. Qty. Description Reed Switch #8 Nut Magnet Filter Console Frame Motor Isolator Left Inner Base Cover Receptacle 9/32" Bushing Base Pad Spacer Ferrite Clamp – User’s Manual Motor Bushing Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of this manual.

  • Page 36: Exploded Drawing

    EXPLODED DRAWING A Model No. NETL15819.0 R0619B...
  • Page 37 EXPLODED DRAWING B Model No. NETL15819.0 R0619B...
  • Page 38 EXPLODED DRAWING C Model No. NETL15819.0 R0619B...
  • Page 39 EXPLODED DRAWING D Model No. NETL15819.0 R0619B...

  • Page 40: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...

This manual is also suitable for:

Netl15819.0
