ICON Health & Fitness NTL89522-INT.1 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Model No. NTL89522-INT.1
Serial No.
Write the serial number in the space
above for reference.
Serial
Number
Decal
MEMBER CARE
UNITED KINGDOM
Website: iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 4, Westgate Court
Silkwood Park
OSSETT
WF5 9TT
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
iFIT Inc.
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Save this
manual for future reference.
USER'S MANUAL
iconeurope.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NTL89522-INT.1 and is the answer not in the manual?

Questions and answers

Related Manuals for ICON Health & Fitness NTL89522-INT.1

Summary of Contents for ICON Health & Fitness NTL89522-INT.1

  • Page 1 Model No. NTL89522-INT.1 Serial No. USER'S MANUAL Write the serial number in the space above for reference. Serial Number Decal MEMBER CARE UNITED KINGDOM Website: iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. Unit 4, Westgate Court Silkwood Park...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. iFIT assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 20. When a person is walking on the treadmill, 26. Do not change the incline of the treadmill by the noise level of the treadmill will increase. placing objects under the treadmill. 21. Keep fingers, hair, and clothing away from 27.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new NORDICTRACK manual. To help us assist you, note the product model ® S25I treadmill. The S25I treadmill provides an impres- number and serial number before contacting us. The sive selection of features designed to make your model number and the location of the serial number workouts at home more effective and enjoyable.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • Assembly requires two persons. • Left parts are marked “L” or “Left” and right parts are marked “R” or “Right.” • Place all parts in a cleared area and remove the packing materials. Do not dispose of the packing •...
  • Page 8 2. Make sure that the power cord is unplugged. Remove the tie securing the Upright Wire (81) to the front of the Base (94). Next, identify the Right Upright (90). Have a second person hold the Right Upright near the Base (94).
  • Page 9 4. Hold the Right Upright (90) against the Base (94). Make sure not to pinch the Upright Wire (81). Attach the Right Upright (90) and a Wheel (25) with two 3/8" x 2 3/8" Screws (7), a 3/8" x 1 1/4" Screw (63), a 3/8"...
  • Page 10 6. Identify the left handrail assembly (E). Attach the left handrail assembly to the Left Upright (89) with two 5/16" x 2 1/2" Screws (28) and two 5/16" Star Washers (11); do not fully tighten the Screws yet. Then, remove and discard the indicated screw (F).
  • Page 11 8. Tighten four #8 x 3/4" Screws (2) into the left and right handrail assemblies (E, G) and into the Left and Right Uprights (89, 90). 9. Set the Console Base (64) facedown on a soft surface to avoid scratching the Console Base. If there are ties (H) securing the Handrail Crossbar (93) to the Console Base, remove the ties.
  • Page 12 10. Identify the Right and Left Trays (27, 36). Attach the Trays (27, 36) to the Console Base (64) with eight #8 x 1/2" Screws (10); do not overtighten the Screws. Then, reattach the Console Frame (18) with the six #8 x 3/4" Screws (2) and the two Console Clamps (92) that you removed in step 9;...
  • Page 13 12. With the help of a second person, hold the con- sole assembly (K) near the Handrails (86) (only one side is shown). Connect the ground wire (J) from the console assembly (K) to the Console Ground Wire (58) on the Handrail Crossbar (93). Next, insert the Upright Wire (81) through the two indicated looped ties (L) on the console assembly (K).
  • Page 14 14. Attach the Handrail Crossbar (93) to the console assembly (K) with four #8 x 5/8" Screws (1); start all four Screws, and then tighten them. Then, firmly tighten the four 5/16" x 3/4" Screws (4). 15. Orient the Upright Crossbar (98) as shown. Carefully slide the Upright Crossbar (98) between the Left and Right Uprights (89, 90).
  • Page 15 16. Insert the Tray (48) from the front of the treadmill and set it on the Upright Crossbar (98) as shown. Attach the Tray (48) with four #8 x 5/8" Screws (1); start all four Screws, and then tighten them. 17.
  • Page 16 18. Remove the 5/16" Nut (34) and the 5/16" x 1 3/4" Bolt (6) from the bracket on the Base (94). Next, orient the Storage Latch (53) as shown. Attach the lower end of the Storage Latch (53) to the bracket on the Base (94) with the 5/16"...
  • Page 17 20. Firmly tighten the four 3/8" x 2 3/8" Screws (7) and the two 3/8" x 1 1/4" Screws (63). Next, tighten the two 3/8" x 1 3/4" Screws (62); the Wheels (25) must turn freely. Next, set the Left Inner Base Cover (99) onto the lower end of the Left Upright (89).

  • Page 18: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO PLUG IN THE POWER CORD Follow the steps below to plug in the power cord. This product must be earthed. If it should malfunc- 1. Plug the indicated end of the power cord (A) into the tion or break down, earthing provides a path of least socket on the treadmill (B).
  • Page 19 CONSOLE DIAGRAM FEATURES OF THE CONSOLE To turn on the power, see page 20. To use the man- ual mode, see page 20. To use an iFIT workout, see page 22. To use a compatible heart rate monitor, The treadmill console offers a selection of features see page 24.
  • Page 20 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
  • Page 21 4. Follow your progress with the display. Scan mode—The console also has a scan mode that will display workout information in a repeating The display can show the following workout cycle. To turn on the scan mode, press the information: Multi-Scan button;...
  • Page 22 5. Turn on the fan if desired. HOW TO USE AN IFIT WORKOUT The fan features several The console offers access to a large and varied library speed settings. Press of iFIT workouts when you download the iFIT app to the fan buttons repeat- your smart device and connect it to the console.
  • Page 23 4. Select an iFIT workout. To pause the workout, simply touch the screen or press the Stop button. To continue the workout, In the iFIT app, touch the buttons at the bottom of press the play icon on the screen, or press the the screen to select either the main menu (Home Start button.
  • Page 24 THE OPTIONAL HEART RATE MONITOR THE SETTINGS MODE Whether your 1. Select the settings mode. goal is to burn fat or to To select the settings mode, press the Settings strengthen your button. The first settings screen will appear in the cardiovascular display.
  • Page 25 Display Test—This screen is intended to be used Demo Mode—The currently selected demo mode by service technicians to identify whether the option will appear in the display. The console display is working correctly. features a demo mode, designed to be used if the treadmill is displayed in a store.

  • Page 26: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.

  • Page 27: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE c. Check the power switch located on the treadmill frame near the power cord. If the switch protrudes Regular maintenance is important for optimal per- as shown (A), the switch has tripped. To reset the formance and to reduce wear. Inspect and properly power switch, wait for five minutes and then press tighten all parts each time the treadmill is used.
  • Page 28 SYMPTOM: The walking belt slows when walked on SYMPTOM: The walking belt is not centered between the foot rails a. If an extension cord is needed, use only a 3-con- a. IMPORTANT: If the walking belt rubs against the ductor, 14-gauge (2 mm ) cord that is no longer foot rails (D), the walking belt may become than 5 ft.

  • Page 29: Exercise Guidelines

    EXERCISE GUIDELINES Aerobic Exercise—If your goal is to strengthen your WARNING: cardiovascular system, you must perform aerobic Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian.

  • Page 30: Part List

    PART LIST Model No. NTL89522-INT.1 R0322B Key No. Qty. Description Key No. Qty. Description #8 x 5/8" Screw 9/32" Plastic Bushing #8 x 3/4" Screw 3/8" Plastic Bushing 5/16" x 2 1/4" Bolt Storage Latch 5/16" x 3/4" Screw Drive Motor...
  • Page 31 Key No. Qty. Description Key No. Qty. Description 3/8" Washer Motor Bushing 5/16" x 1 3/4" Shoulder Bolt #8 Nut #8 x 1/2" Machine Screw Ground Screw – User’s Manual #8 x 1/2" Pan Head Screw Cable Tie Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of this manual.

  • Page 32: Exploded Drawing

    EXPLODED DRAWING A Model No. NTL89522-INT.1 R0322B...
  • Page 33 EXPLODED DRAWING B Model No. NTL89522-INT.1 R0322B...
  • Page 34 EXPLODED DRAWING C Model No. NTL89522-INT.1 R0322B...
  • Page 35 EXPLODED DRAWING D Model No. NTL89522-INT.1 R0322B...

  • Page 36: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
