6. USB-C Port
Connect to the DJI Assistant 2 (Ronin Series) software using a USB-C cable for device
activation and firmware updates. Connect headphones with a built-in mic for voice calls. It is
required to set the Type-C function on the transmitter before use. Refer to the Menu section
for more information.
7. HDMI Port (Type A)
Receives the video source input signal.
8. DC-in Port
Supplies power to the video transmitter using the provided power cable. Voltage 6-18 V and
max current 2 A.
9. M4 Screw Holes
To mount the battery adapter or other adapters for expansion.
10. Power Output Port
Supplies power to an external device.
11. Air Vent
12. Air Intake
DO NOT cover the air vent, air intake, or both sides of the battery adapter if mounted. Otherwise,
the performance of the device may be affected due to overheating.
13. Power Button
Press once to power on. Press and hold to power off.
14. Display Screen
Displays the device status and menu.
15. Menu Dial
Turn or press the dial to select or confirm settings in the menu.
16. Back Button
Press to return to the previous screen of the menu.
17. 3/8"-16 Screw Hole
18. 1/4"-20 Screw Holes
19. External Power Input Port
Mount the battery adapter and compatible battery to supply power to the video transmitter.
©
