dji Video Transmitter User Manual page 13

A or Control B and press the dial again to confirm. The display screen shows Linking and the
linking status indicator blinks red and green alternately, indicating the device is linking.
Using High-Bright Remote Monitor:
Power on the remote monitor. Tap
Select Control Mode, set the monitor as Control Monitor A or Control Monitor B, and tap Link
to Control Monitor A/B to enter linking status.
3. When linking is complete, the linking status indicator turns solid green.
Broadcast Mode
1. Power on the video transmitter. Press the menu dial on the video transmitter, turn the dial to
select Broadcast in the menu, enable Broadcast mode, and select channel.
2. Using DJI Video Receiver:
Power on the video receiver. Press the dial to enter the Connect menu, turn the dial to select
Broadcast in the menu, and then press the dial to confirm. Wait for the search results to be
complete and select a device to connect.
Using High-Bright Remote Monitor:
Power on the remote monitor. Tap
Select Broadcast Mode and the monitor will automatically search for nearby devices with
Broadcast mode enabled. Tap a device to monitor and the live view from the corresponding
device will display on the remote monitor. Tap the camera number on the right side of the
screen to refresh the live view or switch between the monitored devices.
Linking Status Indicator
Linking Status Indicator
Solid red
Blinks red and green alternately
Solid green
Blinks red
©
8
2023 DJI All Rights Reserved.
to enter System Menu and then Connection Settings.
to enter System Menu and then Connection Settings.
Description
Device started, not connected.
Linking.
Successfully linked in Control mode. Wireless video
transmission is normal.
Broadcast mode enabled.
Device malfunction. Contact DJI Support.
