DJI DC Power Cable
Connect the 14.4V accessory power port on the power hub or the port above the pan motor of
Ronin 2 to the DC-in port on the video transmitter for power supply from Ronin 2.
When connecting to the port above the pan motor of Ronin 2, the Control mode of the video
transmission system is not available.

Activation

Activation is required when using the video transmitter for the first time. Power on the video
transmitter and connect it to the computer using a USB-C cable. Open DJI Assistant 2 (Ronin
Series), log in with a DJI account, click the corresponding device icon, and follow the instructions
onscreen to activate the device.
Download DJI Assistant 2 from: https://www.dji.com/transmission/downloads

Linking

The video transmitter must be linked to the receiver device before use. The video transmission
system of the video transmitter offers Control mode and Broadcast mode, which use different
linking methods. Refer to the following section for instructions and linking status indicator
descriptions.
Control Mode
1. Power on the video transmitter. Press and hold the menu dial on the video transmitter until the
linking status indicator blinks red and green alternately, indicating that it is ready to link.
2. Using DJI Video Receiver:
Power on the video receiver. Press the dial to enter the Connect menu, turn the dial to select
Control in the menu, and press the dial to confirm. Select to set the video receiver to Control
©
