CHAPTER 6– CONFIGURATIONS
For MultiLoad II+ Firmware, select FCM COM. For RCU II+ Firmware, select RCU:
3)
If screen displays "00-OK" (or "I/O Board Com: OK" for the RCU II), the I/O board is communicating
4)
with the MultiLoad II or RCU II.
If the I/O board is not communicating the message "00-ERR" appears (or "I/O Board Com: ERR" for
5)
the RCU II).
If 00-ERR (or "I/O Board Com: ERR") appears, verify the communication parameters for Com0
6)
within the Communication Setup Menu. This menu is located under the Configuration Menu. The
Com0 communication settings required for the I/O board are .57.6 (K Baud), None (Parity), 8 Data
(bits), 1 Stop (bit), Single, and I/O Board (type of serial device). This is correctly set in the factory
when an RCU II is assembled, but it is possible for the settings to be updated by the installer.
49
MultiLoad III/RCU III Hardware - Explosion Proof (EX) Installation Guide
MultiLoad II+ Firmware
004 FCM COM DIAGNOSTICS
00-Ok
Exit
RCU II+ Firmware
RCU I/O DIAGNOSTICS
I/O Board Com: Ok
Timeouts: 000000000
[1]Output 0 - OFF
[2]Output 1 - OFF
[3]Output 2 - OFF
[4]Output 3 - OFF
Exit
F/W Rev: 040
Com Lost: 000000000
Input 4 – OFF
Input 5 – OFF
Input 6 – OFF
Input 7 – OFF
Counter 4 - 00000
Counter 5 - 00000
W&M Key – OFF
Clear
