Summary of Contents for Full Spectrum Laser MUSE CORE

  • Page 2: Safety Symbols

    Safety Symbols: Safety Warnings: Red Icons indicate dangerous situations that could result in serious injury or death. ● This product is rated as a Class 4 machine, however the enclosure makes the overall rating of the machine Class 3R. ● Keep the enclosure closed during operation to avoid eye &...

  • Page 3: Safety Stickers

    Safety Stickers: Diagrams: Water Exhaust In/out Power Switch Touchscreen Play/ Pause Button Air Inlet Rotary Port Power Machine Water Water Switch Control USB Port Honeycomb Tray Ethernet Port...
  • Page 4 Remove Zip Ties. 1. Cut open the box. Connect the exhaust ducting to the exhaust.. 3. Pull out the Muse Core. 2. Take out the Honeycomb tray. Connect to the exhaust fan. 4. Carefully remove Box 1 and 2 from the machine.
  • Page 5 Hobby Kit Only Coolbox Only Get a bucket and fill it with two and a half gallons of distilled water. Pull out the water pump and place its plastic fitting on. Locate the two water tubes. Connect the first one to the Water Out fitting on your machine and place the other end inside the bucket.

  • Page 6: Connecting To Internet

    Preparation: Choose your desired material and retrieve the provided billet. To establish a reliable link to RE3, it is recommended to connect the Fiber Galvo to the router. The Muse Core is equipped with an ethernet cable that should be plugged into the ethernet ports of both devices Note: Ethernet port looks the same on all devices 1.

  • Page 7: Touchscreen Interface

    Touchscreen Interface: Home Network ⇨ Wi-Fi The Home screen displays important information such as the device's Enables users to connect to a Wi-Fi network. IP address, the QR Code for RE3, and controls for the laser head. Mobile Version Job History A mobile version of the device is accessible by either scanning The Job History icon provides easy access to previous projects.
  • Page 8 RetinaEngraveV3 (RE3): RE3 can be accessed by entering your machines IP address into your web browser. When loaded RE3 will appear like so. Main Toolbar Workspace Tools Viewing Tools Drawing Tools Orientation Tools Grouping Tools Project List Project Information Gantry Coordinates Cursor Coordinates Rotary Switch Status Indicators...
  • Page 9 Drawing Tools: Grouping Tools: 1. Select: Pointer Group: Group objects Subselect Merge: Union: Combine layers into a single compound layer. Lasso Difference: Combine non-overlapping layers into a Layer single compound layer. 2. Shape: Line. Intersection: Combine overlapping layers into a Rectangle single compound layer.
  • Page 10 Stopping your Laser: Once a project has started, it will run continuously until it is completed. In case of an emergency, there are several options available to stop the laser immediately: 4. E-Stop Button: Located in the lower left corner of the touch screen, pressing this button will cut power to the laser instantly.

  • Page 11: General Maintenance

    General Maintenance: Project Procedure: Connect to Software Create or Import Design Adjust Object Properties By following our maintenance instructions, you can ensure your machine will function at peak performance for a long time. Please keep in mind that the following maintenance schedule can vary depending on machine usage.

  • Page 12: Belt Replacement

    Belt Replacement: X-Belt Replacement: Y-Belt Replacement: Power Off and Unplug Machine. Power Off and Unplug Machine. Locate the Belt Screws. The belt can be found above the adjustment knob. Adjust Locate the Belt Screws. The belt is under the gantry (see below). Adjust the the gantry as necessary to access the screws.

  • Page 13: Lens Replacement

    Air Assist Cone Replacement: Lens Replacement: Please Note: The Air Assist Cone must be replaced when the lens is switched. 1. Disconnect the air hose by gently removing each end. Remove the lens by pushing the back of the lens until you hear a click. Then, simply slide out the old lens.

  • Page 14: Troubleshooting

    Q: What should I do if my laser isn't marking? A: The Muse Core can be focused manually using the provided focusing billet. A: Adjust the laser is in its focal height. If the machine is off by even a few millimeters, it won't engrave.
  • Page 15 The Muse Core and Muse 3D have a Riser option available for individuals looking to engrave taller objects. The riser also has a built in pass through making it possible to engrave longer materials with ease.
