Summary of Contents for Full Spectrum Laser MUSE TITAN

  • Page 2: Table Of Contents

    Section Review ................10 Section II. Unboxing Your Muse Titan Unboxing Steps .
  • Page 3 Table of Contents Section VIII. Operations Creating a Design ............... . 42 Mouse Control .
  • Page 4: Fire Warning

    Never cut PVC (polyvinyl chloride) under any circumstances!! ● Clean the surrounding area regularly to avoid dust getting into the machine. Materials Below is a small list of materials usable with the Muse Titan. We will include a list of hazardous material as well. Cuts Engraves ✓...
  • Page 5 Fire Warning HARMFUL MATERIALS: WARNING!! TRYING TO CUT THESE ITEMS WILL VOID WARRANTY!! CUT AT YOUR OWN RISK! Material DANGER! Issues PVC (Poly Vinyl Chloride)/Vinyl/ Emits Chlorine gas fumes This material can ruin the optics as well as cause the metal of the Pleather/Most Artificial Leather machine to corrode.
  • Page 6: Introduction

    Introduction Thank you for purchasing your new Muse Titan. Our high quality products will provide years of service simply by following proper usage and upkeep. With proper usage and upkeep your machine will be a key part in any design work.
  • Page 7: Section I. Safety

    Section I. Safety Setup Precautions Follow all safety protocols and procedures before operating any machinery. It is the responsibility of the operator to ensure all safety precautions are correctly followed, and that the machine is properly assembled and in working order. ●...
  • Page 8: Electrical Safety

    In order to prevent access to bare wiring your laser shipped with silicone terminal covers. Please notify Full Spectrum Laser support and immediately cease operations if the covers ever slips and exposes the bare wires.
  • Page 9 Section I. Safety The following diagrams will help you locate all of the machines components. Top View Honeycomb Trays Fig. 1 Pause Button Water Reservoir Front Right View Lid Handles Fig. 2 Front View Rotary Port Touch Screen Fig. 3 Passthrough Cover...
  • Page 10 Section I. Safety Back View Exhaust Flange Air Inlet Passthrough Cover Power On/Off Fig. 4 Power Water Inlet & Outlet Supply (For Optional Chiller) Air Assist & Exhaust Controls Side View Exhaust Flange Ethernet Port Wi-Fi Adapter Air Inlet Cooling Fans Cooling Vents Water Inlet &...
  • Page 11: Section Review

    Section I. Safety Section Review: Do’s: ● Remember to make sure your work area is nice an clean. Always keep an eye on your machine. ● ● Always inspect your machine for damage or breakage before each use. ● Keep your laser system clean. Always keep a fire extinguisher on hand.
  • Page 12: Unboxing Steps

    Section II. Unboxing Fig. 6 WARNING!! The Muse Titan v2 is approximately 200 lbs. At least two people are required to lift and unbox the machine. DO NOT TRY TO LIFT ALONE!! Unboxing Steps Follow these instructions for best results: Prepare Work Space: You will need an open, level work space to place your laser cutter.
  • Page 13 Remove the Foam Packaging from the Top and Sides. Fig. 9 Lift the Machine with your lifting buddy and place it into the Work Area. Fig. 10...
  • Page 14: Checklist

    (Optional) Never operate your laser without a working DANGER! CAUTION! exhaust. Full Spectrum Laser recommends Never use unapproved ducting in the exhaust systems capable of 500 CFM. Keep in exhaust system as it is potentially mind that exhaust systems with high flow rates flammable.
  • Page 15: Section Review

    Section II. Unboxing Section Review: Do’s: ● Remember to Lift Your Box with a partner. Remember to lift with your knees. ● ● Remember to use the lifting strap when lifting the Titan. ● Check your Titan for any damage prior to use. Make sure to check that your machine came with all the items on the checklist.
  • Page 16: Remove Protective Foam

    Section III. Setting Up Your Machine This assembly is a simple process that should take less than half an hour to complete. For simplicity we divided the assembly into seven easy steps. Remove Protective Foam Locate & Remove Zip Ties Connect the Exhaust System Preparing Water Reservoir Assemble the Air Compressor...
  • Page 17 Section III. Setting Up Your Machine 2. Locate and Remove Zipties The machine was secured during shipping with zip ties to hold the laser head assembly and the x-gantry. Remove zip ties before operating your laser cutter for the first time. Fig.
  • Page 18 Secure the free end of the ducting to the exhaust fan. Repeat the ducting and clamping process in the other side of the exhaust fan and plug in the fan into the bottom power plug marked “exhaust” on the back of your Muse Titan machine. (see Fig. 16). Fig. 16 Ventilate Outside or to Fume Extractor: Set the open end outside of a window or to a fume extractor.
  • Page 19: Preparing Water Reservoir

    Section III. Setting Up Your Machine 4. Preparing Water Reservoir The Titan V2 comes with an integrated water cooling system found at the bottom of the right control panel.( Refer to picture below) The water reservoir must be filled with 1 liter (.26 gallon) of distilled water using the funnel provided.
  • Page 20 Fig. 19 Connect to Power: Plug the air compressor power cord into the outlet marked “Air Assist” on the back of your Muse Titan. Your air compressor is now ready for use.
  • Page 21: Connect The Electrical Power

    ● The power inlet is equipped with a fuse to protect the machine from surges or short circuits in case of emergencies. If this fuse ever needs replacement, NOTICE! please contact Full Spectrum Laser technical support.
  • Page 22: Pass-Through

    7. Pass-through Fig. 21 The Muse Titan, along with other Muse models, come with pass-through in the front and back of the machine for projects that may require the use of longer materials,such as signs.All one needs to get the pass-through open is to loosen the twelve screws along the pass-through slot.( see Fig.
  • Page 23: Section Review

    Section III. Setting Up Your Machine Section Review: Do’s: ● Remember to remove all the foam from your machine. Take off all the zip ties. ● ● Make sure to check that your exhaust is properly installed. ● Remember to fill your water reservoir before use. Make sure all your accessories are on and functioning properly before attempting to run your machine.
  • Page 24: Touchscreen Interface

    Section IV. Touchscreen Interface The touchscreen that comes on your Muse allows you to control the basic functions of your laser without needing a computer. Jobs are accessible through the touchscreen once loaded in from the RE3 interface. Home The Home screen contains the device’s IP address, the QR Code for RE3 and controls for the laser head.
  • Page 25: Machine Indicator

    Section IV. Touchscreen Interface Machine Indicator: Lock Indicator: Locked Icon: Indicates the gantry is locked. When locked, the user must move the gantry using JOG controls. Unlocked Icon: Indicates the gantry is unlocked. When unlocked, the user must manually move the gantry Lid Indicator: The Titan’s lid has a magnetic failsafe that disconnects the laser when the lid is open.
  • Page 26: Speed Indicators

    Section IV. Touchscreen Interface Speed Indicators: Your machine has 3 speed setting that can be changed by selecting the icon on the touchscreen or from RE3. Running Icon: The machines default speed and the fastest speed, used for fast movement across the work area Jogging Icon: The second speed, also known as the intermediate speed, used for normal adjustments before running a job Walking Icon: The final and slowest speed, used for small adjustments.
  • Page 27: Section Review

    Section IV. Touchscreen Interface Section Review: Do’s: ● Make sure your Gantry is locked before use. Make sure the lid is closed before use. ● ● Make sure the water system is running. Don’ts: ● Do Not Use Your Machine If The Gantry is Unlocked. Do Not Use Your Machine If The Water System is off.
  • Page 28: Section V. Internet Connection

    Fig. 26 Connect Directly to Computer: Connecting the Muse Titan and the computer should only be done if the previous two options are not possible. The Muse can connect to the computer via ethernet cable. Note: The location of the ethernet port varies on computer models. Some computers may not have an ethernet...
  • Page 29 Muse Titan will link with the software’s IP address Turn On Muse Titan: Turning on your Muse Titan will automatically boot up your Muse Touchscreen interface. Allow 30 seconds or so for the machine and touch screen to boot up.
  • Page 30: Section Review

    Section V. Internet Connection Section Review: Do’s: ● Make sure your machine is connected to the internet before you attempt your first project. Remember to let your machine fully boot up before attempting to enter RE3. ● Don’ts: ● Do Not Take Off The Wi-Fi Dongle. ●...
  • Page 31: Alignment Test

    Section VI. Laser Alignment The laser tube that came pre-installed in your Muse Titan was carefully aligned in our facilities in Nevada. However, it is possible that the mirrors may come out of alignment during shipping. Before running your first job, you will want to check and make sure the mirrors are properly aligned using the following procedure.I f your mirror is out of...
  • Page 32 Section VI. Laser Alignment Position Laser Head to 1st Position: Move the laser head into the left most position. Close The Safety Lid: Safety measures are in place to ensure laser does no fire with the safety lid open. Regardless, never attempt to fire the laser with the safety lid open.
  • Page 33: Mirror Alignment

    Section VI. Mirror Alignment Preparation: Tools: Thermal Paper (included with accessories) 2.5mm Hex Wrench (included with accessories) Make sure to prepare your tools and workspace. Turn on Titan: Allow the machine time to fully boot up. Unlock Driver Motor On the touch screen, press the “Locked” icon. It will enter the “Unlocked” position signifying the gantry motor is disabled.
  • Page 34 Section VI. Mirror Alignment Laser Output to Mirror 1: Align the laser output to Mirror #1 making sure that the beam hits close to the center of the mirror. Open the Safety Lid. Place Thermal Paper On Mirror 1. Make sure to place it firmly over Mirror #1 to create a reference ring. Close Safety Lid: Machine should be unable to fire the laser with the safety lid open.
  • Page 35 Section VI. Mirror Alignment Mirror 1 to Mirror 2: Mirror 1 Mirror 2 Open the Safety Lid. Place Thermal Paper: Take a piece of thermal paper and place it firmly over Mirror #2 to create a reference ring. Close Safety Lid. Test Fire the Laser: Press the Test Fire icon to create a burn mark on the thermal paper.
  • Page 36 Section IV. Test and Adjustment Section VI. Mirror Alignment 2. Mirror Alignment Procedure Mirror 2 to Mirror 3: Since Mirror 3 is located on the laser head assembly, we will have to check the alignment along the X-gantry. We recommend selecting five position to test the alignment and using three of those positions to adjust the red diode. POSITION 1/ POSITION 3/ POSITION 5/...
  • Page 37 Section IV. Test and Adjustment Section VI. Mirror Alignment 2. Mirror Alignment Procedure Mirror 3 to Focus Lens: The focus lens converges the laser beam to a single point. The focus lens does not require manual focusing, however it is important to ensure that the path from mirror #3 to the focal lens is straight throughout the Z-axis. Fig.
  • Page 38 Section IV. Test and Adjustment Section VI. Mirror Alignment 2. Mirror Alignment Procedure 1st Position 2nd Position Fig. 35 Position Laser Head to 1st Position. Manually adjust the laser head assembly so that the z- belt is as high as it goes. Close Safety Lid.
  • Page 39: Section Review

    Section VI. Laser Alignment Section Review: Do’s: ● Before attempting to run a project you should perform the Alignment Test. Remember to adjust the Red Diode after Adjusting Mirror 1 and during the alignment of Mirror 3. ● ● Remember to unlock the gantry before starting the Alignment Test and the Mirror Alignment. ●...
  • Page 40: Section Vii. Autofocus

    Section VII. Autofocus Autofocusing Your Laser: Your laser will focus automatically before each job. However it can be focused manually using the autofocus icon on the Touchscreen or by selecting the auto focus button located under the Jog Control window on RE3. When your machine autofocuses, the z- belt will move the focus lens and air assist cone down until the cone touches the material, then retracts the...
  • Page 41 Section VII. Autofocus Adjusting the Stallguard: If excessive shaking or vibrations are experienced when autofocusing the machine then you may need to adjust the machine’s stallguard. What is the Stallguard? The Stallguard is the component inside the machine that controls the amount of tension the machine will take before stopping.
  • Page 42: Section Review

    Section VII. Autofocus Section Review: Do’s: ● Autofocusing can be done from your Touchscreen and from RE3. If your machine experiences excessive shaking or vibration, then adjust the stall guard value on the Setup page. ● Don’ts: ● Do Not Attempt To Connect To The Setup Page If The Machine Is Off.
  • Page 43: Section Viii. Operations

    Section. VIII Operations This section will guide you through using your Muse Titan. To get started, it is important to understand the meanings of “Vector Cutting” and “Raster Engraving” and their associated file types. Vector Cutting Raster Engraving Vectors use mathematical formulas to create paths Rasters are make of white and colored pixels.
  • Page 44: Mouse Control

    Section. VIII Operations Mouse Controls: Drag ‘n Drop: Click and hold a design file, it will become highlighted letting you know it can then be dragged. Drag it into the workspace and a move prompt will appear below the object showing it can be dropped into the workspace.
  • Page 45: Section Review

    Section. VIII Operations Section Review: Do’s: ● PDF is preferred for Vectors, while JPEG is preferred for Rasters. Remember when preparing your own design to use thicker lines. ● ● Remember that previews are seen in 200 DPI but are imported as 500 DPI. ●...
  • Page 46: Section Ix. Retinaengrave V3

    Section. IX Retina Engrave V3 Starting on RE3 Using your new machine for the first time can seem intimidating but we've worked to make this guide as clear as possible regarding our software. We have broken down the entire process into 7 steps. Connect to Software Create or Import Design Adjust Object Properties...
  • Page 47 Section. IX Retina Engrave V3 Import Design Select the file you wish to engrave via your editing software or an image saved on your computer. It can be place into RE3 using three methods: -It can be imported by going to the File->Import->Image -It can be “dragged”...
  • Page 48 Section. IX Retina Engrave V3 5.Focus Lens Your Titan will auto focus before each project. If you wish to focus beforehand the Titan comes with an autofocus feature in RE3 and on the touchscreen NOTE: The focus distance number set in the RE3 interface is machine relative. It signifies a distance away relative to home, not a distance away from the part.
  • Page 49: Compound Shapes & Objects

    Section. IX Retina Engrave V3 Here is some other information that will be useful when performing your first jobs on RE3. Creating and Manipulating Compound Shapes & Objects These functions are available in the Grouping section of the toolbar (see above). Compound Shapes & Objects Operators can combine and modify shapes and objects to create unique compound shapes and objects with these functions: Union: Subtract:...
  • Page 50: Passes

    Section. IX Retina Engrave V3 Passes: Passes are typically used for different things in rastered material than in vectored. Vector Passes In vectors, multiple passes are done to cut through thicker material. Sometimes, such as when cutting wood, a single cut is not enough therefore we can program multiple passes to ensure we cut through our material.
  • Page 51 Section. IX Retina Engrave V3 Stopping the Laser Once a project has begun, the laser will continue until the project is complete. If for any reason an operator needs to stop the laser immediately, choose one of these options: Open the Lid: The Titan’s access lid is installed with a device that automatically cuts off the laser if opened.
  • Page 52 Power Switch: Flipping the power switch to the off position instantly cuts power from the entire machine. Unplug Power: As a last resort, users can unplug the power cord of the Muse Titan from the electrical outlet. This method may cause damage to your cables.
  • Page 53: Section Review

    Section IX. Retina Engrave V3 Section Review: Do’s: ● Remember there are three methods to importing a file. If one does not seem to be working for you, then try the others. Remember to use the Perimeter and/or Camera Capture options to align your design with your materials. ●...
  • Page 54: Section X. Camera

    Fig. 38 The 3D camera is mounted on the lid of your Muse Titan. When the lid is open the camera can capture your workspace for easy alignment and when the lid is down the camera will watch your projects as they are cut.
  • Page 55 Section X. Camera Functions Our Muse 3D and Muse Titan come with a Vector Tracing feature that allows the user to create their own engraving using an image drawn by hand and uploaded into RE3 to save for future works.
  • Page 56: Camera Calibration

    Camera Calibration Muse Titan can detect the height and position of the material using the camera feature. It is possible, however, that the height and positional accuracy of the calibration can be jarred out of alignment. To check calibration, follow these...
  • Page 57 Section X. Camera Functions Set the Reference Marks. Go to the first corner marked 1 and adjust your laser head until the beam is resting at the very corner of the grid. Select Set Marker and then proceed to the other corners in order. Connect to the Setup Page: Connect to the software’s Setup page using the format: IP address/setup.
  • Page 58 Section X. Camera Functions Checking Calibration: We want to make sure that the calibration was successful by moving our laser to a specific point on the workspace. Autofocus to the Calibration Paper. Perform a New Camera Capture. Zoom in to a spot on RE3. We recommend the corner of one of the tags on the page.
  • Page 59: Section Review

    Section X. Camera Functions Section Review: Do’s: ● Remember the camera capture can only be done when the Lid is open. The Camera Calibration must be done with the Calibration paper. ● ● Vector tracing can only be done after the workspace has been captured with your image. Don’ts: ●...
  • Page 60: Section Xi. Maintenance

    Replacing the Laser Tube This section details how to replace the laser tube on your Muse Titan. Although it should last for hundreds of project hours, the laser tube is considered a consumable and will eventually need to be replaced. Please carefully read all instructions before beginning the replacement procedure as there are several critical steps which must be properly followed to avoid breaking the laser tube.
  • Page 61 Section XI. Maintenance Upon locating the first screw, look down and the second screw will be directly below the first. Find the third and forth screws the same way. Fig. 42 Remove The Four Screws: Use the 3mm Hex key to remove the four M5 bolts that hold the tube. Have another person hold the tube when removing the bolts so it does not fall.
  • Page 62: Setting Up New Tube

    Section XI. Maintenance Remove the last voltage wire. Fig. 46 Disconnect the Water Tubes: Detach the water tubes from their connectors from both ends of the laser tube and drain the water into a bucket. Remember which tubes correspond to each connector for later. We recommend taking a picture or labeling the tubes and connectors if needed.
  • Page 63 Section XI. Maintenance Connect Blue Voltage Wire: Use a screwdriver to connect the blue voltage wire from the uncapped end of the tube, located on the left side of the tube shelf. Fig. 49 Attach the Grounding Wire: Attach the green grounding wire from the upper right corner of the tube shelf. Fig.
  • Page 64: Belt Installation

    Belt Replacement: The belts on your laser system are a consumable item and will eventually stretch beyond a usable length or break. You can contact Full Spectrum Laser support for replacements. Required Parts and Tools ● 2.5mm Hex key (included with accessories)
  • Page 65 Section XI. Maintenance Belt Replacement (Continue): Gantry Belt: Power Off Machine: Wait at least 1 hour for capacitors to discharge. Locate Belt Retaining Screws: The screws for the gantry belt are located behind the laser head assembly. (see below) Fig. 52 Loosen Retaining Screws: Remove the M4 retaining screws and washers so that the old belt can be removed and discarded.
  • Page 66: Focus Lens Replacement

    Section XI. Maintenance Note: This section is for replacing air assist cones and different sized lenses. If you are replacing a lens that has become damaged or broken you just need to slide the new lens Parts: Air Assist Cone and Focus Lens w/ Case (purchased separately) Focus Lens Replacement Gently push the lens and it will click out.
  • Page 67: Limit Sensor Replacement

    Section XI. Maintenance Limit Sensor Replacement: Your Gantry stops before it hits the walls of your machine. That is thanks to the limit sensors located inside your machine. If your machine tries to move past its movement limits or bumps into the walls, you may need to replace the limit sensor. X-axis Limit Sensor: The X-axis Limit sensor is located on the gantry at the right corner of the machine.
  • Page 68 Section XI. Maintenance Before starting a job: Make sure the lens and optics are clean and cleared of debris using an optic lens wipes. Note: This is the only recommended options for cleaning lenses as other options can cause micro scratches in your optics.
  • Page 69: Section Review

    Section XI. Maintenance Section Review: Do’s: ● Remember to follow daily, weekly, and monthly maintenance to ensure a long lasting machine. When installing a new laser tube, make sure all the wires are securely fastened. ● ● If your machine tries to move past its movement limit or bumps into the walls, you may need to replace the limit sensor.
  • Page 70: Section X. Add-Ons

    Section X. Optional Add-ons Water Rerouting Instructions: If you have purchased the optional Water Chiller with your Titan, then it will already come re-routed. This part is only for customers who are buying their chiller separately or wish to convert back to the previous wiring. For Chiller SetUp Proceed to pg.
  • Page 71 Section X. Optional Add-ons Disconnect Fan Tube 1 from the Water Reservoir and Water Tube 1 from the Water Pump. Connect both tubes using the water tube connector. Disconnect Water Tube 2 from the Water Sensor...
  • Page 72 Section X. Optional Add-ons Run Water Tube 2 through the cable opening and into the other side. Connect Water Tube 2 to the water inlet. Connect Water Tube 3 to the water outlet and run though the hole. Connect the other end of tube to the Water Sensor. The Re-routing is done.
  • Page 73 2. Attach Water Tubing to Your Titan: Connect the two (2) silicone tubed from the chiller to the contrasting INLET and OUTLET of the Muse Titan (Remember: In to Out, Out to In). Your laser will not fire if this is installed backwards thanks to the water flow sensor.
  • Page 74: Fume Extractor

    Fume extractors are air purifiers that clean the air through HEPA Filters. Fume extractors do not require outside ventilation. This is a great choice for workshops that do not have the option to ventilate outside. Both extractors and the filters are available on the Full Spectrum Laser Accessories page.
  • Page 75: Section Review

    Section X. Optional Add-ons Section Review: Do’s: ● Make sure to take the water out of the water reservoir before starting to re-route the system. Check the Tubes for holes before plugging them in. ● ● Remember to double check your connections from the external water chiller to the Titan. (In to Out, and Out to In) Don’ts: Do Not Reroute The Water System While The Machine Is Running.
  • Page 76: Warranty

    Warranty Warranty Full Spectrum Laser will replace or repair any defective parts free of charge within the first 30 days. Ground shipping is free with overnight shipping available at extra charge. Full Spectrum Laser will replace or repair any defective part within the warranty period free of charge but shipping charges are the responsibility of the customer.
  • Page 77: Customer Support

    Customer Support For a list of Frequently Asked Question and a series of help guides, visit us at our Help Center We offer a variety of free projects to help you get started, just check out our Free Projects page. For more information on laser engraving, check out our Blog Technical Support:...
