- Page 1 ShineSEM-X Operation Manual V1.0 SHENZHEN GROWATT NEW ENERGY CO.,LTD 4-13/F,Building A,Sino-German(Europe) Industrial Park, Hangcheng Ave,Bao’an District, Shenzhen, China + 86 755 2747 1942 + 86 755 2747 2131 service@ginverter.com www.ginverter.com...
-
Page 2: Table Of Contents
CONTENT About this manual Manual Description Copyright Notice Applicable personnel Manual usage Product introduction 2.1 Product appearance and and installation internal structure 2.2 Introduction to working principle 2.3 Unpacking 2.4 Installation 2.5 Wiring instructions 2.6 Ring Network Wiring 2.7 Cable Specifications Operation and 3.1 ShineMaster-X operation application... -
Page 3: About This Manual
1.2 Copyright notice The copyright of this user manual is owned by Growatt. No part or all of this user manual may be excerpted, reproduced or transmitted in any form, including information and publications, by any entity or individual without our written permission. Infringement of which will be prosecuted. - Page 4 Steady on: The 4G network is normal. Always off: the network is not connected; The ShineSEM-X is mainly composed of ShineMaster-X, electric meter, air isolating switch, 1S blinks 1 time, off 1 time: Obtained a valid IP , no circuit breaker, and terminal block D.LAN indicator LAN LED...
- Page 5 The ammeter is an optional component, and it is used with the anti-reflux box 3. The ShineSEM-X is located between the inverter, the user load and the grid, and communicates with the inverter through PLC or RS485 .
-
Page 6: Unpacking
ShineSEM-X to the wall, and then install the Hang up the communication box of the smart sub-array, and lock the screws to complete the installation. - Page 7 . This interface is used layer is connected to the GND pin of the RS485 interface of the ShineSEM-X and the for remote monitoring. For details, please refer to Chapter 5.
- Page 8 1. Overall wiring 1. Overall wiring As can be seen from the above figure, the ShineSEM-X is connected to L1, L2, and L3 of As can be seen from the cascading method in the above figure, multiple inverters are the power grid, and then each inverter is also connected to the power grid in sequence, connected to the first-level combiner box, then connected to the second-level combiner and the data is uploaded to the cloud server through PLC communication monitoring.
-
Page 9: Ring Network Wiring
Operation and application 2.7 Ring Network Wiring 3.1 ShineMaster-X operation introduction The ShineSEM-X supports ring network communication, enabling data collection and centralised uploading from multiple ShineSEM-Xs which can be uploaded to the monitoring system or local server. The ring network mode... - Page 10 2. Enter the user name and password, the default login user name: admin, password: admin, click login after filling in, enter the ShineMaster-X system page. Figure 3-3 Schematic diagram of command line input Figure 3- 7 System information bar Figure 3- 4 Schematic diagram of the results of the ipconfig command 3.
- Page 11 Log in to the built-in page, the login account is "admin", the password is "admin", select "Device Monitoring" in the first-level menu, select "Inverter" in the second-level menu, and select "Device Maintenance" in the third-level menu. (1) Select the device to be added, "inverter", "electric meter", "environmental monitor" and "PID device".
- Page 12 , and then click "Query", and the photovoltaic equipment added under the RS 485 channel will be displayed ; Figure 3- 16 Device list The device types are as follows: Inverter GROWATT Inverter Figure 3- 18 Device list SDM one-way meter SDM three-way electric meter CHNT one-way meter ( 3 ) Check the photovoltaic equipment that needs to be deleted, click "Delete", and...
- Page 13 Figure 3- 24 DHCP enabled ( 3 ) After the setting is successful, it needs to be restarted to take effect. Figure 3- 22 Device list ( 4 ) If you need to set ShineMaster- X to a fixed IP during use, you need to perform the following settings: select "Wired Communication"...
-
Page 14: Specification Parameters
(2) Enter the port number of the corresponding server, the domain name of the server, Ring switch Optional such as server-cn.growatt.com/server.growatt.com , and the time interval for data uploading, click Submit, and it will prompt to refresh the interface successfully to check Maximum number of inverter 60PCS whether the modification is successful. -
Page 15: Model Description
4.2 Model description ShineSEM-X (with electric meter) System capacity The model introduction of the ShineSEM-X takes ShineSEM-X-RH as an example: 100KW 300KW 600KW Technical Parameters Input voltage parameter ShineSEM-X-RH 400Vac Rated input voltage/range ① ② ③ 400~540Vac (three specifications) 800Vac... - Page 16 Contact us Growatt New Energy provides customers with comprehensive technical support. Users can contact the nearest Growatt New Energy office or customer service point, or directly contact the company's customer service center. Name: Shenzhen Growatt New Energy Co., Ltd. Address: Building A, Zhongdeou Industrial Park,...
