Parts List And Exploded View - ESAB ARC250i Instruction Manual

Parts List and Exploded view

No. Part No
1 0800550001
2 0800550002
3 0800550003
4 0800550004
5 0800550005
6 0800550006
7 0800550007
8 0800550008
9 0800550009
10 0800550010
11 0800550011
12 0800550012
13 0800550013
14 0800550014
15 0800550015
16 0800550016
17 0800550017
18 0800550018
19 0800550019
20 0800550020
21 0800550021
22 0800550022
23 0800550023
24 0800550024
25 0800550025
26 0800550026
27 0800550027
28 0800550028
29 0800550029
30 0800550030
31 0800550031
32 0800550032
33 0800550033
34 0800550034
Description
handle
cover
filter capacitor
capacitor busbar
inverter PCB board
pressure plate
Heat sink
right upper fixed board
block switch
switch support
power cord
cable fixed head
right bottom fixed board
fan
back bottom panel
rectifier PCB board
positive busbar
protection ear
rectifier board fixed plate
foot
Front plate
Front plastic panel
Euro type quick connector
welding mode select switch
potentiometer knob
overheat indicate light
digital display
potentiometer
reactor
power PCB board
radiator connection plate
mounting panel
left bottom fixed board
main control PCB board
QTY
1
1
1
2
1
2
2
2
1
2
1
1
2
1
1
1
1
1
1
4
1
1
2
1
2
1
1
1
1
1
1
1
2
1
