Handheld Barcode Scanner
N130
User Manual
Xiamen Hanin Electronic Technology Co., Ltd.
ADD: 5F, 8# Building, Aide Airport Industrial Park, Huli District, Xiamen, China
WEB: www.hprt.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N130 and is the answer not in the manual?

Questions and answers

Related Manuals for HPRT N130

Summary of Contents for HPRT N130

  • Page 1 Handheld Barcode Scanner N130 User Manual Xiamen Hanin Electronic Technology Co., Ltd. ADD: 5F, 8# Building, Aide Airport Industrial Park, Huli District, Xiamen, China WEB: www.hprt.com...
  • Page 2 Disclaimer Please read all the contents of the manual carefully before using the products described in this manual to ensure the safe and effective use of the products. After reading, please keep this manual properly for the next time you use it. Do not disassemble or tear the sealed bidding of the scanner on your own, otherwise our company shall not assume the responsibility of warranty or replacement of the scanner.
  • Page 3 Change Record Rev. Date Description 2020.07.15 First edition...

  • Page 4: Table Of Contents

    CONTENT Chapter 1 Introduction ......................... 1 Appearance ............................ 2 Dimension ............................3 Scanner Data Cable Interface Definition ..................4 Interface ............................5 USB Cable Connection......................6 RS-232 Cable Connection ....................... 7 Power on, Power off and Restart ....................8 Maintenance ..........................8 Barcode Read ..........................
  • Page 5 Enable/Disable 2/5-bit Add-On code ................24 UPC-E ............................ 24 Enable/Disable UPC-E ....................24 Transmit check character ..................... 24 Enable/Disable 2/5-bit Add-On code ................25 Convert UPC-E to UPC-A ....................25 System character transmit ................... 25 UPC-E1 ..........................26 Enable/Disable 2/5 Add-On code ................26 UPC-A ...........................
  • Page 6 Standard 25 .......................... 34 Enable/Disable Standard 25 ..................34 ISSN ............................34 ISBN ............................35 Data bit setting ........................35 ISBT 128 ..........................35 Enable/Disable ISBT 128 ....................35 GS1 128 ..........................35 Enable/Disable GS1 128 ....................35 Gs1-128 emulation mode for UCC/EAN composite code ..........35 GS1 DataBar .........................
  • Page 7 Host mode (CDC, HID, BT, COM） ..................44 Trigger mode (Single scanning, scanning continuously, auto sensing) ........ 44 Default parameters (Restore factory settings) ..............44 Decoding timeout（0.1s~9s） .................... 44 Data prefix ..........................45 Data suffix ..........................45 Aiming device (ON/OFF) ...................... 45 Illumination light (ON/OFF) ....................

  • Page 8: Chapter 1 Introduction

    2D image scanner. N130 can read all kinds of 1D barcodes and standard 2D barcodes (various versions of PDF417, QR code, and Data matrix) can easily scan paper, plastic cards, LCD and other barcode printed media. Its fully integrated design makes it easy to embed in a wide range of product applications.

  • Page 9: Appearance

    N130 User Manual Appearance...

  • Page 10: Dimension

    N130 User Manual Dimension Unit: mm...

  • Page 11: Scanner Data Cable Interface Definition

    N130 User Manual Scanner Data Cable Interface Definition Define Input / Output Function USB_DP USB Signal USB_DM USB Signal POWER Ground Wire VBUS POWER Power, +5V POWER Ground Wire RS232 Clear to Send RS232 Request to Send RS232 Receive RS232 Send...

  • Page 12: Interface

    N130 User Manual Interface The scanner must be connected to a Host in actual application, such as PC, POS or any intelligent terminal with USB or RS-232 port. RS-232...

  • Page 13: Usb Cable Connection

    N130 User Manual Connect N130 to Host USB Cable Connection Connect the scanner to a Host through a USB cable with RJ45 and USB connectors: 1) Plug the RJ45 connector into the serial port on the scanner. 2) Plug the USB connector into the USB port on the Host.

  • Page 14: Rs-232 Cable Connection

    N130 User Manual RS-232 Cable Connection Connect the scanner to a Host through an RS-232 cable with RJ45 and RS-232 connectors and a power jack: 1) Plug the RJ45 connector into the serial port on the scanner. 2) Plug the RS-232 connector into the RS-232 port on the Host.

  • Page 15: Power On, Power Off And Restart

    N130 User Manual Power on, Power off and Restart Power on: power on automatically when the scanner is connected to the host. Power off: unplug the data cable. Restart: if the scanner stops responding to input or runs abnormally please re-plug the data cable.

  • Page 16: Use The Setting Barcode

    N130 User Manual Use the Setting Barcode Set the parameter to a special barcode whose barcode type is barcode128. When it scans to a barcode software that matches the setting type of setting, it will automatically enter the setting and does not send the results on the host.

  • Page 17: Chapter 2 Communication Interface

    Serial Interface Serial interface is a common way to connect the scanner to the host (e.g. PC, POS devices). N130 handheld scanner provides RS-232 electrical level interface, which can directly connect to PC’s serial interface.

  • Page 18: Baud Rate

    N130 User Manual Baud Rate The unit of Baud Rate is bps: bits per second, the optional configuration parameter is as below shown: 115200 38400 19200 9600 (Default) 4800 2400 1200...

  • Page 19: Usb Interface

    N130 User Manual USB Interface HID Virtual Keyboard When using USB interface, the scanner can be simulated as a HID-KBW device. In this mode, the scanner would be a virtual keyboard that output the data to the host. HID Virtual Keyboard Setting...
  • Page 20 N130 User Manual Hebrew Portuguese Latin(America) Czech_DEC Brazilian Greek_DEC Canadian (French) Hungarian Polish Slovakian_DEC Swedish Turkish_Q Romanian Russian Turkis_F...
  • Page 21 N130 User Manual Japanese(ASCII) Swiss(French) USA(International) Slovenian Croatian Bosnian Macedonian Albanian Serbian(Latin) Serbian(Cyrillic) Czech_QWERTZ Czech_QWERTY Czech(Programmers) Estonian Latvian Latvian_QWERT...
  • Page 22 N130 User Manual Lithuania Lithuanian (IBM) Slovakian_QWERTZ Slovakian_QWERTY Hungarian_101_Key Spanish(Variation) Bulgarian(Cyrillic) Bulgarian(Latin) Canadian(French_Legacy) Canadian(Multilingual) Italian_142 Polish_214 Polish_Programmers Brazilian_MS Greek_Polytonic Greek_220...
  • Page 23 N130 User Manual Greek_319 Greek_Latin Greek_220_Latin Greek_319_Latin Greek_MS Russia_MS Russian(Typewriter) Thai(Pattachote) Thai(Kedmanee) Irish Maltese Icelandic Ukrainian Uzbek(Cyrillic) Kazakh Kyrgyz(Cyrillic)
  • Page 24 N130 User Manual Azeri(Latin) Azeri(Cyrillic) Belarusian Faeroese Gaelic Tatar Mongolian(Cyrillic)

  • Page 25: Usb Virtual Serial Port

    N130 User Manual USB Virtual Serial Port When the scanner uses a USB communication interface, but the host application uses serial communication to receive data, you can set the scanner to the USB virtual serial port. This function requires that be installed the appropriate driver on the host.

  • Page 26: Chapter 3 Scanning Mode

    N130 User Manual Chapter 3 Scanning Mode Manual Mode In manual mode, when the trigger control interface of the scanner changes into trigger electrical level, the scanner will start to shoot and read. In the limited time of “single reading time”, the scanner will continuously shoot and read until it is successful.

  • Page 27: Sensitivity

    N130 User Manual Sensitivity Normal (Default) Fast Ultra-fast  Single Reading Time In sensing reading mode, the parameter indicates the maximum time of allowing reading engine to continuously collect and identify barcode before reading successfully. After reading successfully or single read timeout, the reading engine will enter the interval of not collecting the read. The range of single read time is 0.1~9.9s, step length is 0.1s.

  • Page 28: Command Programming

    N130 User Manual Command Programming In this mode, scanner needs the host to trigger and decode the barcode. The scanner can set the length of the reading time. The reading code time can be set to 0.1~9.9s. When it be set to 0 that...

  • Page 29: Chapter 4 Illumination And Aiming

    N130 User Manual Chapter 4 Illumination and Aiming Aiming There is a projecting device on the scanner that is used to project a special image when reading, which characterizes the center of the scene image taken by the scanner. When the scanner is used for shooting, the image is projected on the reading target, and the scanner aims at the reading target, which makes it easier to read the target.

  • Page 30: Chapter 5 Symbologies

    N130 User Manual Chapter 5 Symbologies Every symbology (barcode type) has its own unique attributes. This chapter provides programming barcodes for configuring the scanner so that it can identify various symbologies. It is recommended to disable those that are rarely used to increase the efficiency of the scanner.

  • Page 31: Ena-13

    N130 User Manual ENA-13 Enable/Disable EAN-13 Enable (Default) Disable Enable/Disable 2/5-bit Add-On code The 2/5-digit Add-On code refers to the 2/5-digit digital barcode added after the ordinary barcode. Enable (Default) Disable Auto UPC-E Enable/Disable UPC-E Enable (Default) Disable Transmit check character UPC-E barcode data is fixed to 8 characters, and the eighth character is the check bit, which is used to check the correctness of all 8 characters.

  • Page 32: Enable/Disable 2/5-Bit Add-On Code

    N130 User Manual Enable/Disable 2/5-bit Add-On code The 2/5-digit Add-On code refers to the 2/5-digit digital barcode added after the ordinary barcode. Enable (Default) Disable Auto Convert UPC-E to UPC-A The chip can convert the decoding results of UPC-E type barcodes to UPC-A type barcodes according to standard algorithms.

  • Page 33: Upc-E1

    N130 User Manual UPC-E1 Transmit system character (Default) Transmit system character and country code (“0” only for USA) Not transmit preamble Enable/Disable 2/5 Add-On code The 2/5-digit Add-On code refers to the 2/5-digit digital barcode added after the ordinary barcode.

  • Page 34: Transmit Check Character

    N130 User Manual Transmit check character UPC-A bar code data is fixed to 13 characters, and the 13th character is check bit, which is used to check the correctness of all 13 characters. Transmit check character (Default) Disable Enable/Disable 2/5-bit Add-On code The 2/5-digit Add-On code refers to the 2/5-digit digital barcode added after the ordinary barcode.

  • Page 35: Code 39

    N130 User Manual Code 39 Enable/Disable Code 39 Enable (Default) Disable Check character verification and transmit Code 39 barcode data does not contain a check character. If there is a check character, it is the last character of the data. A check character is a value calculated from all data to verify that the data is correct.

  • Page 36: Convert Code 39 To Code32

    N130 User Manual Convert Code 39 to Code32 Enable Disable (Default) Code 32 prefix Enable add prefix character "a" Disable (Default) Code 93 Enable/Disable code 93 Enable (Default) Disable Code 11 Enable/Disable code 11 Enable Disable (Default) Check Setting Code 11 barcode data does not contain the check digit. If there is a check digit, it can be the last one or two characters of the data.

  • Page 37: Transmit Check Character

    N130 User Manual Not check (Default) 1-bit check 2-bit check Transmit check character Transmit check character Disable (Default) Code 128 Enable/Disable code 128 Enable (Default) Disable Note: if this barcode is set to disable, the scanner will not be able to scan and switch the corresponding function settings.

  • Page 38: Codabar

    N130 User Manual Codabar Enable/Disable Codabar Enable (Default) Disable Start and stop characters Enable CLSI Disable CLSI (Default) Enable this parameter to remove the start and stop characters, and insert spaces after the first, fifth and tenth characters of the 14-character Codabar barcode.

  • Page 39: Check Bit Algorithm

    N130 User Manual 1-bit check 2-bit check Check bit algorithm 1 MSI MOD10/MOD10 (Default) 2 MSI MOD10/MOD11 Transmit check character Transmit check character Disable (Default) Interleaved 2 of 5 Enable/Disable Interleaved 2 of 5 Enable (Default) Disable Check and transmit character Interleaved 2 of 5 barcode data does not contain the check digit.

  • Page 40: Convert I 2 Of 5 To Ean-13

    N130 User Manual Not check (Default) USS check OPCC check Transmit check character: Transmit check character Disable (Default) Convert I 2 of 5 to EAN-13 Convert I 2 of 5 to EAN-13 Disable (Default) Matrix 2 of 5 Enable/Disable Matrix 2 of 5...

  • Page 41: Industrial 2 Of 5

    N130 User Manual Not check (Default) Check Transmit check character Transmit check character Disable (Default) Industrial 2 of 5 Enable/Disable Industrial 2 of 5 Enable Disable (Default) Standard 25 Enable/Disable Standard 25 Enable Disable (Default) ISSN Enable Disable (Default)

  • Page 42: Isbn

    N130 User Manual ISBN Enable Disable (Default) Data bit setting Use 13 bits (Default) Use 10 bits ISBT 128 Enable/Disable ISBT 128 Enable (Default) Disable GS1 128 Enable/Disable GS1 128 Enable (Default) Disable Gs1-128 emulation mode for UCC/EAN composite code...

  • Page 43: Gs1 Databar

    N130 User Manual GS1 DataBar Enable/Disable GS1 DataBar Enable (Default) Disable Convert GS1 DataBar to UPC/ENA Convert DataBar to UPC/ENA Disable (Default) GS1 DataBar Limited Enable/Disable GS1 DataBar Limited Enable Disable (Default) GS1 DataBar Expanded Enable/Disable GS1 DataBar Expanded Enable...

  • Page 44: 1D Barcode Inverse

    N130 User Manual 1D Barcode Inverse Disable(Default) Enable Automatic detection 1D Barcode Anti-color Auto (Default) Disable...

  • Page 45: 2D Barcode Setting

    N130 User Manual 2D Barcode Setting PDF417 Enable/Disable PDF417 Enable (Default) Disable Data Matrix Anti-color Auto (Default) Disable Only read Anti-color color Enable/Disable Data Matrix Enable (Default) Disable Mirror Images Auto (Default) Enable Disable...

  • Page 46: Inverse

    N130 User Manual Inverse Disable (Default) Enable Auto Enable/Disable QR Enable (Default) Disable Enable/Disable Micro QR code (this setting is only valid when enable QR) Enable (Default) Disable Inverse Disable (Default) Enable Auto...

  • Page 47: Anti-Color

    N130 User Manual Anti-color Auto (Default) Only read Anti-color color Disable Aztec Inverse Disable (Default) Enable Auto Anti-color Auto (Default) Only read Anti-color color Disable...

  • Page 48: Han Xin

    N130 User Manual Han Xin Anti-color Auto (Default) Only read Anti-color color Disable Inverse Disable (Default) Enable Auto...

  • Page 49: Chapter 6 Troubleshooting

    N130 User Manual Chapter 6 Troubleshooting Q: There are some barcodes cannot be scanned. A: Check the barcode type, open the barcode function; if it is verified, try to turn off. Q: The barcode data is incorrect. A: Check the error display of barcodes (all barcodes errors or specific barcode error) Q: Barcode can be read but not displayed.

  • Page 50: Chapter 7 Scanner Settings

    N130 User Manual Chapter 7 Scanner Settings Serial Port Command Format Permanent Length Operand Host/Slave Data Checksum Command Length Operand Status Data 1 BYTE 1 BYTE 1 BYTE 1 BYTE 1 BYTE~250BYTE 1 BYTE Length operands + H/D + permanent command + data...

  • Page 51: General Settings (Default Hid Single Scan Mode)

    N130 User Manual General settings (default HID single scan mode) Host mode (CDC, HID, BT, COM） Operand: 0x41 USB Virtual Serial Port USB Virtual Keyboard General Serial Port Data 0x02 0x01 0x03 0x04 Set scanner interface mode Trigger mode (Single scanning, scanning continuously, auto sensing)

  • Page 52: Data Prefix

    N130 User Manual Data prefix Operand: 0x52 Disable Custom Define Data0 0x00(Default) 0x01~0xfd Data1 0x00 0x01~0xfd Note: 1. If the character set to be 0x20, you need to set the data = 0xFE. 2. If only one character is set, you need to set another to 0x00 Disable.
  • Page 53 N130 User Manual...

  • Page 54: Baud Rate Of Virtual Serial Port

    N130 User Manual Baud rate of virtual serial port Operand: 0x48 115200 38400 19200 9600 4800 2400 1200 Data 0x00 0x01 0x02 0x03(Default) 0x04 0x05 0x06 Set serial port baud rate, this setting applies to USB virtual serial port and normal serial port only.

  • Page 55: The Convert Rate In Hid Mode

    N130 User Manual The convert rate in HID mode Operand: 0x4E Fast Normal Slow Data 0x01 0x02 (Default) 0x0a Timeout setting of the same barcode in non-single scan mode Operand: 0x4F Variable Data 0x00~0x63 Data: 0x00 indicates that there is no Timeout Invalid. If there is a barcode, it can still output.
  • Page 56 N130 User Manual ◼ Commands that support only barcodes Set F1~F12 (only analog key output is supported) Set the barcode content as follows: Name F1 Value 0x16 0x17 0x18 0x19 0x1A 0x1B 0x1C 0x1D 0x1E 0x1 0x10 0x15 Users can directly write the appropriate data to generate the appropriate barcode, then scan the barcode can achieve the function of virtual key output.

  • Page 57: Virtual Serial Port Mode Command Settings

    N130 User Manual Virtual serial port mode command settings Start scanning Operand: 0xE4 Data: 0x00 This feature only supports serial mode. Stop scanning Operand: 0xE5 Data: 0x00 This feature only supports serial mode. Setting barcode convert mode Operand: 0xEE Data:...

  • Page 58: Barcode Function Settings

    N130 User Manual Barcode function settings ITF cut the first few bits of data Operand: 0x55 Enable Disable Data 0x01 (Default) 0x02~0x32 Note: 0x02 indicates cutting the first data; 0x32 indicates cutting 49 data from the front. Disable Cut the first data...

  • Page 59: Skip The Number Of Characters Before Barcode Data

    N130 User Manual Reduce multiple consecutive spaces to one space Skip the number of characters before barcode data Operand: 0x59 data: *0: Do not skip barcode data 1-31: skip the number of characters before barcode data *Not skip barcode data...
  • Page 60 N130 User Manual Convert barcode data into lower case...

  • Page 61: Insert Characters Into Barcode Data

    N130 User Manual Insert characters into barcode data (up to 8 characters) Operand: 0x5C Data: Data0 ~ data1: the position of the inserted data in the barcode data Data2: data inserted in corresponding position (range: 0x01 ~ 0x7F) Note: Data0 ~ data1 Calculation method: data0 = (x/64) +0x20 data1 = (x%64) +0x20, where x is the position of the character to be inserted (range: 1 ~ 6143).

  • Page 62: Appendix Ⅰ Barcode Enabling Settings

    N130 User Manual Appendix Ⅰ Barcode Enabling Settings Operand: 0x40 Data: 2BYTE data Set the barcode enabling parameter, DATA 0 is the barcode parameter, DATA 1 is the barcode parameter variable. The following is the parameter default value. 0 is OFF, 1 is ON...
  • Page 63 N130 User Manual Australia Post 0x1A Enable Netherlands KIX Code 0x1B Enable USPS 4CB 0x1C Disable UPU FICS Postal 0x1D Disable GS1 DataBar-14 0x1E Enable GS1 DataBar Limited 0x1F Disable GS1 DataBar Expanded 0x20 Disable 0x21 Composlte CC-C Disable 0x22...

  • Page 64: Appendix Ⅱ Data Code Prefix And Suffix

    N130 User Manual Appendix Ⅱ Data code prefix and suffix E.g. Adding prefixes “@!”, steps: Scan the setting barcode【open prefix 1】--> Scan the setting barcode【@】 Scan the setting barcode【open prefix 2】--> Scan the setting barcode【!】 The detailed barcode is set as follows:...
  • Page 65 N130 User Manual "...
  • Page 66 N130 User Manual < >...
  • Page 67 N130 User Manual...
  • Page 68 N130 User Manual ‘...
  • Page 69 N130 User Manual...
  • Page 70 N130 User Manual...

  • Page 71: Appendix Ⅲ Ascii Code Table

    N130 User Manual Appendix Ⅲ ASCII Code Table Hexadecimal Decimal Character NUL （Null char.） SOH （Start of Header） STX （Start of Text） ETX （End of Text） EOT （End of Transmission) ENQ （Enquiry） ACK （Acknowledgment） BEL （Bell） BS （Backspace） HT （Horizontal Tab）...
  • Page 72 N130 User Manual ! （Exclamation Mark） " （Double Quote） # （Number Sign） $ （Dollar Sign） % （Percent） & （Ampersand） ` （Single Quote） ( （Right / Closing Parenthesis） ) （Right / Closing Parenthesis） * （Asterisk） + （Plus） , （Comma） - （Minus / Dash）...
  • Page 73 N130 User Manual [ （Left / Opening Bracket） \ （Back Slash） ] （Right / Closing Bracket） ^ （Caret / Circumflex） _ （Underscore） ' （Grave Accent）...
  • Page 74 N130 User Manual { （Left/ Opening Brace） | （Vertical Bar） } （Right/Closing Brace） ~ （Tilde） DEL （Delete）...
