Daktronics Tuff Sport

Basketball

LED Scoreboards

Display Manual

ED-13110

BB-2101

BB-2103

BB-2105

BB-2107

BB-2109

BB-2111

BB-2114

BB-2115

BB-2116

BB-2117

BB-2119

BB-2120

* Discontinued

Rev 17 – 15 January 2013

Models

BB-2121

BB-2144

BB-2122

BB-2152

BB-2123

BB-2153

BB-2125

BB-2155

BB-2127

PN-2101

BB-2128

SD-2101

BB-2130

SD-2102

BB-2131

SD-2103

BB-2132

SD-2104

BB-2137

SD-2106

BB-2142

SD-2107

BB-2143

Table of Contents

Troubleshooting

Need help?

Do you have a question about the Tuff Sport BB-2127 and is the answer not in the manual?

Questions and answers

Summary of Contents for Daktronics Tuff Sport BB-2127

Page 1 BB-2127 PN-2101 BB-2111 BB-2128 SD-2101 BB-2114 BB-2130 SD-2102 BB-2115 BB-2131 SD-2103 BB-2116 BB-2132 SD-2104 BB-2117 BB-2137 SD-2106 BB-2119 BB-2142 SD-2107 BB-2120 BB-2143 * Discontinued 201 Daktronics Drive PO Box 5128 Brookings, SD 57006-5128 Tel: 1-800-DAKTRONICS (1-800-325-8766) Fax: 605-697-4746 Web: www.daktronics.com...
Page 3 – graphic, electronic, or mechanical, including photocopying, taping, or information storage and retrieval systems – without written permission of the publisher. ® ® ® ® All Sport , Tuff Sport , UniView , and PanaView are trademarks of Daktronics, Inc.
Page 5: Table Of Contents
Multiple Drivers ......................27 Segmentation and Digit Designation .................. 27 Schematics ..........................27 Replacement Parts List ......................28 Daktronics Exchange and Repair & Return Programs ............. 29 Exchange Program ......................29 Repair & Return Program ..................... 30 Table of Contents...
Page 6 Daktronics Warranty and Limitation of Liability ............30 Section 6: Scoreboard Options ......................31 Horns ............................31 Adjusting Horn Volume ....................31 Radio Control ......................... 31 Visual Horn Indicator (VHI) ....................31 Changeable Captions ......................32 Time Outs Left (TOL) Digits ....................32 Double Bonus Indicators ......................
Page 7: Introduction
Project-specific information takes precedence over any other general information found in this manual. Scoreboard Controllers Daktronics Tuff Sport scoreboards are designed for use with the All Sport 1600 and 5000 ® series control consoles, and certain models may also be controlled with the RC-100 handheld controller.
Page 8: Scoreboard Label
Scoreboard Label Serial and model numbers of a Daktronics scoreboard can be found on the ID label on the display, similar to that shown in Figure 1. Figure 1: Display ID Label Please list the model number, display serial number, and the date this display became operational in the blanks provided on the second page of this manual.
Page 9: Daktronics Nomenclature
Power or signal jack Power or signal plug for the opposite jack Following the Replacement Parts List is the Daktronics Exchange Policy and the Repair & Return Program. Refer to these instructions if replacing or repairing any display component. Product Safety Approval Daktronics Tuff Sport scoreboards are ETL-listed, tested to CSA standards and CE-labeled for indoor use.
Page 11: Specifications
Section 2: Specifications The chart on the following pages details all of the mechanical specifications, circuit specifications, and power requirements for each display in this manual. Models are listed in alphanumeric order. Notes: 1) All displays require a 120 VAC, 15 A circuit. Displays with a 230 VAC power requirement are also available.
Page 12 Dimensions: Uncrated Amps Driver # Model Watts Height, Width, Depth Weight 120/230 VAC & Address BB-2116 4'-0" H, 14"-0" W, 6" D 210 lb 200 W 1.7/0.9 A (1219 mm, 4267 mm, 152 mm) 154 kg [225 lb [300 W] [2.5/1.3 A] 102 kg] BB-2117...
Page 13 Dimensions: Uncrated Amps Driver # Model Watts Height, Width, Depth Weight 120/230 VAC & Address BB-2132 2'-4" H, 2'-9" W, 2'-5" D 75 lb 300 W 2.5/1.3 A (711 mm, 838 mm, 737 mm) 34 kg BB-2137 2'-2.5" H, 8'-0" W, 6" D 70 lb Connects directly to (673 mm, 2438 mm, 152 mm)
Page 14 Dimensions: Uncrated Amps Driver # Model Watts Height, Width, Depth Weight 120/230 VAC & Address SD-2102* 6'-0" H, 3'-6" W, 6" D 90 lb 400 W 3.3/1.7 A Left Display: (1829 mm, 1067 mm, 152 mm) 41 kg [98 lb [500 W] [4.2/2.2 A] 45 kg]...
Page 15: Mechanical Installation
Be sure that the installation complies with local building codes. Note: Daktronics does not assume any liability for any installation derived from the information provided in this manual or installations designed and installed by others.
Page 16: Scoreboard & Statistics Display Mounting
Figure 6: Wall Mounting specification drawings listed in Appendix A. Due to the variety of wall materials used in sports facilities, Daktronics cannot anticipate a user‟s individual installation needs or provide mounting hardware suitable for every installation. Choose a method of installation that will safely support the weight of the display.
Page 17: Shot Clock Mounting
Notes: 1) Daktronics recommends that two cables be used at each end of the scoreboard. 2) Cables and hardware must be specified by a licensed engineer. 3) Do not attach suspension hardware to ad panels – attach to top of scoreboard.
Page 19: Electrical Installation
It is the responsibility of the electrical contractor to ensure that all electrical work meets or exceeds local and national codes. Daktronics engineering staff must approve all changes or the warranty will be void. Installation Overview The diagram shown in Figure 7 illustrates a typical wired setup between a scoreboard and the control system.
Page 20: Power
Connect the scoreboard to earth ground. Proper grounding assures reliable equipment operation and protects the equipment against damaging electrical disturbances and lightning. Daktronics recommends a resistance-to-ground of 10 ohms or less. The electrical contractor performing the electrical installation can verify ground resistance. Daktronics Sales and Service personnel can also provide this service.
Page 21: Power-On Self-Test (Post)
(J-box) near the display. Refer to Drawing A-28124 and Drawing A-125316 in Appendix E for signal wire connection. At a minimum, use a paired, 22 AWG shielded cable (Daktronics part # W-1077) and connect the cable to a dual "...
Page 22: Statistics Display Signal Connection
Refer to Figure 7 for more information about connecting the signal wiring that runs from the scoreboard to the controller. See also Drawing A-124688 in Appendix E. At a minimum, use a paired, 22 AWG shielded cable (Daktronics part # W-1077) and connect the cable to a dual "...
Page 23: Shot Clock Signal Connection
See also Drawings A-124688 and A-125415 in Appendix E. At a minimum, use a paired, 22 AWG shielded cable (Daktronics part # W-1077) and connect the cable to a dual " J-box at the control console end.
Page 24: Portable Shot Clock Installations
BB-2132 come prewired with a twistlock male power inlet. A female plug is provided by Daktronics that must be attached to a power cord by the customer. Note: Model BB-2114 comes equipped with a standard 12' (3.7 m) power cord and plug.
Page 25: Scoreboard Troubleshooting
If a problem occurs that is not listed or that cannot be resolved using the solutions in the following table, contact Daktronics using the information provided in Section ‎ 5 .8. Problem...
Page 26 Problem Possible Cause Solution/Items to Check Move the console 20-30 feet from the scoreboard and test again. Verify that both the console and scoreboard antennae are securely tightened and in a vertical position. Replace the radio receiver. Check that the scoreboard is receiving 120 (or 230) VAC power.
Page 27: Component Location & Access
Problem Possible Cause Solution/Items to Check Bad digit or driver (see solution on previous page) Incorrect sport code (see solution on previous page) Incorrect driver address (see solution on previous page) Wrong console controlling Another console’s radio signal could Scoreboard works, but some scoreboard be transmitting to the scoreboard.
Page 28: Panaview
PanaView To replace a PanaView digit circuit board (Figure 15): Open the digit panel as described in Section ‎ 5 .2. Disconnect the power/signal connector from the back of the digit by squeezing together the locking tabs and pulling the connector free. Use a "...
Page 29: Uniview
UniView To replace a UniView digit circuit board (Figure 16): Open the digit panel as described in Section ‎ 5 .2. Disconnect the power/signal connector from the back of the digit by squeezing together the locking tabs and pulling the connector free. Use a "...
Page 30: Led Drivers
LED Drivers In each scoreboard, one or more LED drivers perform the task of switching LEDs on and off. LED drivers are located inside of a driver enclosure. Refer to Figure 17 to view the location and components of a Tuff Sport driver enclosure. Figure 17: Driver Enclosure Location &...
Page 31 Connector # Function 1-16 Output to digits and indicators Control signal Control for horn Address Refer to Drawing A-126174 in Appendix E for detailed driver pin out/switch specifications. The table below shows the function of the primary connectors for a 4-column driver: Connector # Function Output to digits and indicators...
Page 32: Replacing A Driver
Figure 18: Driver Status Indicators Replacing a Driver If the driver status indicators do not appear to be working correctly, it may be necessary to replace the driver. Open the digit panel or scoreboard face panel as described in Section ‎ 5 .2. Disconnect all connectors from the driver by squeezing together the locking tabs and pulling the connectors free.
Page 33: Setting The Driver Address
Setting the Driver Address Since the same LED drivers can be used for many scoreboard models, each driver must be set to receive the correct signal input, or address, for the model being used. This address is set with jumper wires in a 12-pin plug which mates with jack J19 on the driver (Figure 19).
Page 34: Replacement Parts List
Replacement Parts List Refer to the following table for Daktronics scoreboard replacement parts. Description Daktronics Part # Horn, 120V with capacitor 0A-1152-0332 Main clock, start/stop switch 0A-1166-0003 Shot clock, start/stop switch 0A-1196-0031 LED driver, 16-column 0P-1150-0126 LED driver, 4-column 0P-1150-0130 PanaView Digit, 7"...
Page 35: Daktronics Exchange And Repair & Return Programs
The Daktronics Exchange Program is a service for quickly replacing key components in need of repair. If a component fails, Daktronics sends a replacement part to the customer who, in turn, returns the failed component to Daktronics. This decreases equipment downtime.
Page 36: Repair & Return Program
Repair & Return Program For items not subject to exchange, Daktronics offers a Repair & Return Program. To send a part for repair, follow these steps: Call or fax Daktronics Customer Service: Refer to the appropriate market number in the chart listed on the previous page.
Page 37: Scoreboard Options
Visual Horn Indicator (VHI) In addition to the horn, Daktronics offers a visual horn indicator (VHI) that lights up when the buzzer sounds. To install a VHI, users must tap into the existing horn wiring to provide power and signal.
Page 38: Changeable Captions
Changeable Captions Team name and statistics caption kits contain hardware for one caption only and consist of an upper caption retainer, a lower caption retainer, a changeable caption panel and screws. The standard HOME and GUEST captions are applied directly to the face of the scoreboard. Team name captions are on changeable panels that fit into retainers mounted above and below the standard captions.
Page 39: Tnmc & Electronic Caption Troubleshooting & Maintenance
Section 7: TNMC & Electronic Caption Troubleshooting & Maintenance IMPORTANT NOTES: 1. Always disconnect scoreboard power before doing any repair/maintenance work on the message centers. 2. Permit only qualified service personnel to access internal display electronics. 3. Disconnect power when not using the scoreboard. Display Overview Team Name Message Centers (TNMCs) are programmable LED displays that allow users to show custom Home and Guest names or messages of ~15 characters on the scoreboard in...
Page 40: Initialization Information At Startup
If a problem occurs that is not listed or that cannot be resolved using the solutions in the following table, contact Daktronics using the information provided in Section ‎ 5 .8. Symptom/Condition...
Page 41: Power & Signal Summary
Power & Signal Summary Reference Drawings: Schematic: 3/4" and 1" DC TNMC’s ............Drawing B-146975 Schematic, Electronic Caption, BB-2153 ..........Drawing A-1102510 Refer to Drawing B-146975 in Appendix D for detailed schematics about display power and signal routing. Refer to Drawing A-1102510 for BB-2153 and BB-2155 scoreboards. Display signal routing can be summarized as follows: ®...
Page 42: Diagnostic Leds
Figure 21 illustrates some of the primary jacks and indicators of a display driver. Figure 21: Display Driver Diagnostic LEDs The following table explains the functions of the primary diagnostic LEDs on the drivers: LED Name Color Illumination Summary DS1 PWR Green Steady on or blinking when the driver has power Steady on or blinking when the driver is receiving...
Page 43: Modules
Modules Display modules consist of LEDs embedded in a circuit board. One or more circuit boards are mounted to the back of a display face panel. Do not attempt to remove individual LEDs. In the case of malfunctioning LEDs, replace the entire module circuit board. Replacing Modules Access the internal components as described in Section ‎...
Page 44: Power Supplies
Power Supply; 12V @ 8.5A, 85-264VAC (for 1" mods) A-1555 Power Supply; 5V @ 10A, 85-264VAC (for 0.75" mods) A-1568 Cable; 18 pos, Ribbon, 6" W-1320 See Section ‎ 5 .8 for information on Daktronics Exchange and Repair and Return program. TNMC & Electronic Captions Maintenance & Troubleshooting...
Page 45: Appendix A: Mechanical Specification Drawings
Appendix A: Mechanical Specification Drawings Drawing Title Drawing Number Mechanical Spec, BB-2101 ...................... A-144651 Mechanical Spec, BB-2105 ...................... A-144741 Mechanical Spec, BB-2107 ...................... A-144817 Mechanical Spec, BB-2103 ...................... A-149234 Mechanical Spec, PN-2101 ...................... A-162230 Mechanical Specs, SD-2106 ....................A-163544 Mechanical Spec, BB-2116 ...................... A-164590 Mechanical Spec- BB-2123 ......................
Page 49: Appendix C: Scoreboard Options
HOME GUEST PERIOD FOULS T.O.L. PLAYER FOUL T.O.L. FOULS SCORE MATCH SCORE...
Page 79 DAKTRONICS DAKTRONICS...
Page 80 HOME GUEST T.O.L. T.O.L.
Page 81 HOME GUEST PERIOD T.O.L. T.O.L.
Page 83 Appendix B: Electrical Specification Drawings Drawing Title Drawing Number Electrical and Signal Spec- BB-2107 and BB-2108 ..............A-158571 Electrical and Signal Spec- BB-2101 and BB-2102 ..............A-158845 Electrical and Signal Spec- BB-2103 and BB-2104 ..............A-158848 Electrical and Signal Spec- BB-2105 and BB-2106 ..............A-158849 Electrical &...
Page 85 HOME GUEST PERIOD FOULS T.O.L. PLAYER FOUL T.O.L. FOULS SCORE MATCH SCORE daktronics HOME GUEST PERIOD FOULS T.O.L. PLAYER FOUL T.O.L. FOULS SCORE MATCH SCORE...
Page 86 HOME GUEST PERIOD HOME GUEST PERIOD...
Page 87 HOME GUEST PERIOD FOULS PLAYER FOUL FOULS T.O.L. T.O.L. SCORE MATCH SCORE HOME GUEST PERIOD PERIOD FOULS PLAYER FOUL FOULS T.O.L. T.O.L. SCORE MATCH SCORE...
Page 88 HOME GUEST PERIOD HOME GUEST PERIOD...
Page 90 HOME GUEST PERIOD HOME GUEST PERIOD...
Page 91 HOME GUEST PERIOD FOULS PLYR FOUL FOULS daktronics HOME GUEST PERIOD PLYR FOUL FOULS Patent Pending...
Page 92 HOME GUEST PERIOD FOULS T.O.L. PLAYER FOUL T.O.L. FOULS SCORE MATCH SCORE daktronics HOME GUEST PERIOD FOULS T.O.L. PLAYER FOUL T.O.L. FOULS SCORE MATCH SCORE...
Page 93 HOME GUEST PERIOD daktronics HOME GUEST PERIOD...
Page 99 DAKTRONICS...
Page 101 DAKTRONICS DAKTRONICS...
Page 102 DAKTRONICS...
Page 103 DAKTRONICS...
Page 106 DAKTRONICS...
Page 112 HOME PERIOD GUEST HOME PERIOD GUEST...
Page 116 DAKTRONICS DAKTRONICS...
Page 117 DAKTRONICS DAKTRONICS SIGNAL IN CUR. LOOP SIGNAL OUT SIGNAL HAZARDOUS VOLTAGE AT EXPOSED TERMINALS. DISCONNECT POWER BEFORE SERVICING.
Page 118 DAKTRONICS HAZARDOUS VOLTAGE AT EXPOSED TERMINALS. DISCONNECT POWER BEFORE SERVICING. SIGNAL IN CUR. LOOP SIGNAL OUT RED BLK SIGNAL...
Page 119 DAKTRONICS DAKTRONICS SIGNAL IN SIGNAL OUT CUR. LOOP RED BLK SIGNAL...
Page 120 DAKTRONICS DAKTRONICS HAZARDOUS VOLTAGE AT EXPOSED TERMINALS. DISCONNECT POWER BEFORE SERVICING. SIGNAL IN SIGNAL OUT CUR. LOOP RED BLK SIGNAL...
Page 121 DAKTRONICS DAKTRONICS HAZARDOUS VOLTAGE AT EXPOSED TERMINALS. DISCONNECT POWER BEFORE SERVICING. SIGNAL IN SIGNAL OUT CUR. LOOP RED BLK SIGNAL...
Page 122 DAKTRONICS DAKTRONICS SIGNAL IN CUR. LOOP SIGNAL OUT SIGNAL HAZARDOUS VOLTAGE AT EXPOSED TERMINALS. DISCONNECT POWER BEFORE SERVICING.
Page 123 DAKTRONICS HAZARDOUS VOLTAGE AT EXPOSED TERMINALS. DISCONNECT POWER BEFORE SERVICING. SIGNAL IN CUR. LOOP SIGNAL OUT RED BLK SIGNAL...
Page 124 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DAKTRONICS, INC. DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESSED WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2012 DAKTRONICS, INC. TUFF SPORT SCOREBOARDS ELECTRICAL AND SIGNAL SPEC; BB-2153 AND BB-2154 JVANAAR...
Page 125 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DAKTRONICS, INC. DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESSED WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2013 DAKTRONICS, INC. TUFF SPORT SCOREBOARDS ELECTRICAL AND SIGNAL SPEC, BB-2155 AND BB-2156 KDRAGT...
Page 127 Appendix C: Scoreboard Options Drawing Title Drawing Number Backstop Mounting Suggestions ....................A-91230 Wiring for Shot Clock on Portable Backstop ................A-98293 Advertising/Identification Display Mounting ................A-147668 Suspension Lift Eye Installation ....................A-148644 12V DC Horn Option Installation ....................A-148960 T.O.L.
Page 140 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DAKTRONICS, INC. DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESSED WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2012 DAKTRONICS, INC. INDOOR LED SCOREBOARDS INSTALLATION, ELECTRONIC CAPTION, BB-2153 MMILLER...
Page 141 Appendix D: Schematic Drawings Drawing Title Drawing Number Schematic; Dual 1/4" Phone J-box w/ Shunt Jack ..............A-125316 Schematic; 3/4" & 1" DC TNMCs ....................B-146975 Schematic- 16V 1 Driver- 120 or 230VAC ................A-158348 Schematic, 16V 2 Driver, 120 or 230 VAC ................B-158859 Schematic, 16V 3 Driver, 120 or 230 VAC ................
Page 142 Schematic, Multi-section SCBD A-165285 BB-2120 Schematic- 16V 1 Driver- 120 or 230VAC A-158348 BB-2121 Schematic- 16V 1 Driver- 120 or 230VAC A-158348 BB-2122 Schematic, 16V 2 Driver, 120 or 230 VAC B-158859 BB-2123 Schematic- 16V 1 Driver- 120 or 230VAC A-158348 BB-2125 Schematic: BB-2128- 120VAC...
Page 167 Appendix E: Additional Reference Drawings Drawing Title Drawing Number Signal Connection; Installation ....................A-28124 Segmentation, 7 Segment Bar Digit ................... A-38532 Address Table, 1 Through 128 ....................A-115078 Address Table, 129 Through 255 ..................... A-115079 Protocol Table, 1 Through 15 ....................A-115081 4 Column LED Driver II;...
Page 181 Appendix F: Daktronics Warranty and Limitation of Liability Daktronics Warranty and Limitation of Liability...
Page 183 WARRANTY AND LIMITATION OF LIABILITY This Warranty and Limitation of Liability (the “Warranty”) sets forth the warranty provided by Daktronics with respect to the Equipment. By accepting delivery of the Equipment, Purchaser agrees to be bound by and accept these terms and conditions. All defined terms within the Warranty shall have the same meaning and definition as provided elsewhere in the Agreement.
Page 184 In no event shall Daktronics be liable to Purchaser or any other party for loss, damage, or injury of any kind or nature arising out of or in connection with this Warranty in excess of the purchase price of the Equipment actually delivered to and paid for by the Purchaser.
