BA-2000 Series
LED Baseball Scoreboards
Display Manual
BA-2001
BA-2008
BA-2018
Rev 4 – 19 November 2010
Models
BA-2002
BA-2009
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Daktronics BA-2000 Series
Summary of Contents for Daktronics BA-2000 Series
- Page 1 BA-2000 Series LED Baseball Scoreboards Display Manual Rev 4 – 19 November 2010 ED-16961 Models BA-2001 BA-2002 BA-2008 BA-2009 BA-2018 201 Daktronics Drive PO Box 5128 Brookings, SD 57006-5128 Tel: 1-800-DAKTRONICS (1-800-325-8766) Fax: 605-697-4700 Web: www.daktronics.com Email: helpdesk@daktronics.com...
- Page 3 – graphic, electronic, or mechanical, including photocopying, taping, or information storage and retrieval systems – without written permission of the publisher. ® ® All Sport and PanaView are trademarks of Daktronics, Inc. Other trademarks used in this manual are the property of their respective owners.
-
Page 5: Table Of Contents
Table of Contents Section 1: Introduction ..........................1 Resources ..........................1 Daktronics Nomenclature ...................... 2 Model Number ........................3 Scoreboard Controllers ......................3 Product Safety Approval......................3 Section 2: Specifications .......................... 5 Section 3: Mechanical Installation ......................7 Footings & Beams ........................7 Lifting the Scoreboard ...................... - Page 6 5.13 Daktronics Exchange and Repair & Return Programs ............. 32 Exchange Program ......................32 Repair & Return Program ..................... 33 Daktronics Warranty and Limitation of Liability ............34 Section 6: TNMC Troubleshooting & Maintenance – Models BA-2001/2002/2008/2009 ... 35 Team Name Message Center System Overview ............... 35 Initialization Information at Startup ...................
-
Page 7: Introduction
Figure 1: Daktronics Drawing Label Reference Drawing: System Riser Diagram ................Drawing C-325405 Daktronics identifies manuals by the DD or ED number located on the cover page of each manual. For example, this manual would be referred to as ED-16961. Introduction... -
Page 8: Daktronics Nomenclature
Figure 3: Typical Label Power or signal plug for the opposite jack Following the Replacement Parts List is the Daktronics Exchange Policy and the Repair & Return Program. Refer to these instructions if replacing or repairing any display component. Introduction... -
Page 9: Model Number
Model Number Daktronics scoreboards are differentiated by their model numbers and two-letter prefixes for each sport. Most Daktronics scoreboards also carry a two-number suffix that refers to the type of power supply and digit color. Refer to the following tables:... -
Page 11: Specifications
1) All displays require a 120 V AC, 15 A circuit. Displays with a 240 V A C power requirement are also available. 2) Signal wire must be minimum of 22 AWG with shield. Daktronics recommends W-1234. 3) TNMC LEDs are the same color as the LED digits on the scoreboard. - Page 12 Model & Number of Dimensions: Weight Watts Amps Driver # Options Sections Height (H), Width (W), Depth (D) 120 / 240 V AC & Address BA-2018 4 Total H 13'-0", W 42'-0", D 8" 2530 lb 1200 W 10 A / 5 A (3962 mm, 12802 mm, 203 mm) (1148 kg) Top Left...
-
Page 13: Mechanical Installation
" aluminum plate or steel nut plate. Daktronics strongly recommends using a spreader bar, or lifting bar, to lift the display. Spreader bars ensure the force on the eyebolts remains straight up, minimizing lifting stress. Figure 4: Lifting Methods... -
Page 14: Scoreboard Mounting
Figure 5. Figure 5: Eyebolt Plane Load Note: Daktronics assumes no liability for damages resulting from incorrect setup or lifting methods. Eyebolts are intended for lifting only. Do not attempt to permanently support the display by the eyebolts. -
Page 15: Clamping To Verticals
Clamping to Verticals An inverted channel mounting installation uses C-channels; clip angles; -13" threaded rods; and " square nuts, hex nuts, lock washers, and optional spacers. Refer to Figure 6 and Drawing A-55101 in Appendix A. Mount the scoreboard as follows: Place the C-channel against the upper and lower rear flanges of the scoreboard. -
Page 16: Welding To Horizontals
Welding to Horizontals Steel clip angles are first bolted to the back of each scoreboard section. These clip angles are then welded on three sides to a horizontal tube, which itself has been welded to the support beams. Refer to the sections below for suggested horizontal tube spacing. Models BA-2001 &... - Page 17 Model BA-2018 Figure 9 shows the spacing of the horizontal tubes for BA-2018 scoreboards. The horizontal tubing must have a vertical dimension (height) of 4" (102 mm). The bottom of the first horizontal tube is level with the bottom of the scoreboard and is considered the zero mark for measuring the other two horizontal tubes.
-
Page 18: Ad Panel Mounting
Figure 10: Scoreboard Mounting Detail, Side View Ad Panel Mounting The installation uses C-channels; clip angles; -13" threaded rods; and " square nuts, hex nuts, lock washers, and optional spacers similar to the clamping mounting method above. Refer to Figure 11 and Drawing A-52187 in Appendix A. Figure 11: Ad Panel Mounting with C-channel, Side View Mechanical Installation... -
Page 19: Scoreboard Protective Devices
Note: Some users install devices to protect the scoreboard from projectiles. Scoreboard protection devices not provided by Daktronics must be approved by Daktronics prior to installation. Failure to follow this approval procedure will void the scoreboard warranty. -
Page 21: Electrical Installation
It is the responsibility of the electrical contractor to ensure that all electrical work meets or exceeds local and national codes. Daktronics engineering staff must approve all changes or the warranty will be void. Installation Overview The diagram shown in Figure 12 illustrates a typical wired setup between a multi-section outdoor scoreboard and controller. -
Page 22: Power
The diagram shown in Figure 13 illustrates a typical wireless setup between a multi-section outdoor scoreboard and controller. Daktronics part numbers are shown in parentheses. Figure 13: Wireless Installation Power Correct power installation is imperative for proper display operation. The subsections that follow give details of display power installation. -
Page 23: Grounding
Proper grounding is necessary for reliable equipment operation and protects the equipment from damaging destructive disturbances and lightning. Daktronics recommends a resistance-to-ground of 10 ohms or less. The electrical contractor performing the electrical installation can verify ground resistance. Daktronics Sales and Service personnel can also provide this service. - Page 24 Figure 15: Driver Enclosure & Power Terminal Block Note: If a power receptacle is needed to operate the control console at the scoreboard for troubleshooting, Daktronics recommends that an installation electrician provides a 120 V outlet close to the disconnect box specifically for this purpose.
-
Page 25: Power-On Self-Test (Post)
Note: Be sure to properly connect the shield (silver) wire to the SHIELD Figure 17: Signal Surge Arrestor Card terminal. For signal cable, Daktronics recommends, as a minimum, single-pair, shielded cable, 22 AWG (Daktronics part number W-1077). Two-pair shielded cable (part W-1234) is preferred. Electrical Installation... -
Page 26: Fiber Optic
All Sport 5000 console. Refer to the Baseball Speed of Pitch Systems Configuration Manual (ED-12224), available online at www.daktronics.com/manuals, for more information about setting up an SOP system. Power/Signal Connections Between Sections Most multi-section outdoor scoreboards use a single power/signal interconnect cable between a driver in the upper section and a driver in the lower section. -
Page 27: Scoreboard Troubleshooting
If a problem occurs that is not listed or that cannot be resolved using the solutions in the following table, contact Daktronics using the information provided in Section 5.13. Problem... - Page 28 Problem Possible Cause Solution/Items to Check Check that the green POWER and amber RADIO IN RANGE indicators on the radio receiver in the scoreboard light up when the control console is powered on (see Section 5.9). Keep the console between 20 to 1500 feet from the scoreboard.
-
Page 29: Component Access
Problem Possible Cause Solution/Items to Check Verify the Mate-N-Lok connector on the back of the digit circuit board is secure (see Section 5.2). Bad connection Verify power/signal interconnect(s) between scoreboard sections Scoreboard works, but some properly connected LEDs do not light or they (see Section 4.5) blink Swap the digit/driver with one known... -
Page 30: Component Locations
Note: If the panel is not held in place when the screws are removed, it could drop and possibly damage LEDs or the digit harness. With a non-digit access panel, simply remove the top, side and bottom screws holding it in place. -
Page 31: Replacing Digit Segments
Replacing Digit Segments Some larger digits (24"/30") are constructed with individual circuit board segments. As with smaller digits, the digit segment circuit boards are mounted to the back of a digit panel (Figure 21). It may be possible to make repairs by removing just the defective segment. -
Page 32: Led Drivers
LED Drivers The LED drivers perform the task of switching digits on and off within the scoreboard. LED drivers are located inside of a driver enclosure. Refer to Figure 22 to view the location and components of a driver enclosure. Figure 22: Driver Enclosure Location &... -
Page 33: Replacing A Driver
When troubleshooting driver problems, three LEDs labeled DS1, DS2, and DS3 in Figure 23, provide the following diagnostic information: Color Function Operation Summary Green Power Steady on DS1 will be on and steady to indicate the driver has power. Signal RX Steady on DS2 will be on or blinking when the or blinking... -
Page 34: Setting The Driver Address
Ensure the driver is set to the correct address (refer to Setting the Driver Address). Close and secure the digit panel, then power up and test the scoreboard to see if changing the driver has resolved the problem. Setting the Driver Address Since the same LED drivers can be used for many scoreboard models, each driver must be set to receive the correct signal input, or address, for the model being used. -
Page 35: Radio Interference
For more information, refer to the Gen V Radio Installation Manual ED-13831, available online at www.daktronics.com/manuals. To locate the radio receiver, look for the antenna sticking out the front of the scoreboard, typically between the STRIKE and OUT digits (Figure 25). - Page 36 The radio receiver has a plastic cover. Three status indicator LEDs are visible (Figure 26). Note: While it is necessary to have the scoreboard powered on to check the LED indicators, always disconnect scoreboard power before servicing. Remove the four screws using a #2 Philips screwdriver and lift off the cover.
-
Page 37: 5.10 Segmentation And Digit Designation
A-179593 BA-2008 & BA-2009 B-204725 (w/ or w/o TNMC) BA-2018 (w/ or w/o TNMC) B-242532 5.12 Replacement Parts Refer to the following table for common Daktronics scoreboard replacement parts: Description Location Daktronics Part # J-Box, " phone, Indoor Signal 0A-1009-0038 J-Box, "... -
Page 38: 5.13 Daktronics Exchange And Repair & Return Programs
The Daktronics Exchange Program is a quick, economical service for replacing key components in need of repair. If a component fails, Daktronics sends a replacement part to the customer who, in turn, returns the failed component to Daktronics. This not only saves money but also decreases equipment downtime. -
Page 39: Repair & Return Program
In most circumstances, the replacement part will be invoiced at the time it is shipped. If the failed part or replacement part is not returned to Daktronics within 3 weeks of the ship date, Daktronics will assume that the customer is purchasing the replacement part and will send an invoice for the value of the new sale part. -
Page 40: Daktronics Warranty And Limitation Of Liability
Fax: 605-697-4444 Daktronics Warranty and Limitation of Liability The Daktronics Warranty and Limitation of Liability is located in Appendix B. The Warranty is independent of Extended Service agreements and is the authority in matters of service, repair, and display operation. -
Page 41: Tnmc Troubleshooting & Maintenance - Models Ba-2001/2002/2008/2009
Section 6: TNMC Troubleshooting & Maintenance – Models BA-2001/2002/2008/2009 IMPORTANT NOTES: 1. Always disconnect scoreboard power before doing any repair/maintenance work on the message centers. 2. Permit only qualified service personnel to access internal display electronics. 3. Disconnect power when not using the scoreboard. Team Name Message Center System Overview Team name message centers (TNMCs) use amber, red, or white LEDs to display team names (home and guest) in place of vinyl captions (Figure 38). -
Page 42: Tnmc Troubleshooting Table
If a problem occurs that is not listed or that cannot be resolved using the solutions in the following table, contact Daktronics using the information provided in Section 5.13. Symptom/Condition Possible Remedy Check/replace the ribbon cables on the module. -
Page 43: Power & Signal Summary
Power & Signal Summary Reference Drawings: Schematic, Amber TNMC, GEN IV ............Drawing A-252645 Schematic, Red TNMC, GEN IV ............. Drawing A-252681 Schematic; 832 / 848 / 864 Red TNMC GEN IV, 240V ......Drawing A-294858 Schematic; 832 / 848 / 864 Amber GEN IV, 240V ........Drawing A-294919 Schematic, OD, 3500, 34mm TNMC, Red/Amb ........ -
Page 44: Component Locations & Access
Component Locations & Access Reference Drawings: Component Locations; 832/848/864 Red/Amb LED, TNMC, G4 .... Drawing A-257029 Component Loc.; 34mm Red/Amb/Wht LED TNMC G4 ......Drawing B-975100 Component Loc.; 46mm Red/Amb/Wht LED TNMC G4 ......Drawing B-975635 Figure 29 illustrates the component locations of an 8x48-34mm TNMC with all modules removed. -
Page 45: For Tnmcs Built Before September 2009
Figure 32: Discontinued 8x48-46mm TNMC with Modules Removed Standard Daktronics outdoor LED scoreboards are typically front-accessible, but some models may be ordered with rear service access. For that reason, Daktronics TNMCs have been designed so that they may be accessed from both the front and rear. -
Page 46: Rear Access
Rear Access To access the internal components from the rear, remove the appropriate rear-access panel from the TNMC by loosening all four of the screws. Slide the access panel sideways to the larger part of the keyhole and carefully lift it off the TNMC. - Page 47 Figure 35: 4 Column MCAST Driver For TNMCs Built Before September 2009 The TNMC driver receives signal from the control console via a signal surge arrestor card and sends data to the modules. Refer to Section 6.4 for more information on signal routing. The driver itself is detailed in Drawing A-166216 in Appendix A.
-
Page 48: Diagnostic Leds
Each module assembly is made up of a module housing (containing LEDs and the driver) and a louver assembly. Individual components such as louvers can be removed for service, but Daktronics recommends that the module be kept intact and that the entire assembly be sent in for repair or replacement. -
Page 49: Weather-Stripping
To replace a module from the rear: Follow the steps in the Rear Access method described in Section 6.5. Use a 1/8" hex wrench or " nut driver to loosen the latch fastener assembly (Figure 43). Turn each fastener a quarter-turn clockwise (if using a nut driver, turn the top latch counter-clockwise and the bottom latch clockwise). -
Page 50: Power Supplies
Power Supplies Power supply configurations will vary depending on the number and/or color of modules. Replacing a Power Supply To remove a power supply from the display: Access the internal components using the appropriate Front/Rear Access method described in Section 6.5. Disconnect all the wires connected to the power supply. -
Page 51: 6.10 Replacement Parts List
6.10 Replacement Parts List The following tables contain TNMC components that may have to be replaced. Many of the components within the display itself have attached part number labels. Part Description Part Number Module; 8X8-34, Red 0A-1208-5005 Module; 8X8-34, Red (Sep 2009 – Nov 2010 only) 0A-1208-5002 Module;... -
Page 52: For Tnmcs Built Before September 2009
Red 8x8 34mm Module Assembly 0A-1208-4004 Amber 8x8 34mm Module Assembly 0A-1208-4005 Red 8x8 46mm Module Assembly 0A-1342-4004 Amber 8x8 46mm Module Assembly 0A-1342-4005 See Section 5.13 for information on Daktronics Exchange and Repair and Return program. TNMC Troubleshooting & Maintenance – Models BA-2001/2002/2008/2009... -
Page 53: Tnmc Troubleshooting & Maintenance - Model Ba-2018
Section 7: TNMC Troubleshooting & Maintenance – Model BA-2018 IMPORTANT NOTES: 1. Always disconnect scoreboard power before doing any repair/maintenance work on the message centers. 2. Permit only qualified service personnel to access internal display electronics. 3. Disconnect power when not using the scoreboard. Team Name Message Center System Overview Team name message centers (TNMCs) use amber or red LEDs to display team names (home and guest) in place of vinyl captions (Figure 38). -
Page 54: Tnmc Troubleshooting Table
If a problem occurs that is not listed or that cannot be resolved using the solutions in the following table, contact Daktronics using the information provided in Section 5.13. Symptom/Condition Possible Remedy Check/replace the ribbon cables on the module. -
Page 55: Power & Signal Summary
Power & Signal Summary Refer to Drawings B-188553 or B-190140 in Appendix A to view detailed schematics about power and signal routing for red and amber TNMC cabinets, respectively. Signal routing for the TNMC can be summarized as follows: ® Data from the All Sport controller travels via cable harness into the scoreboard. -
Page 56: Front Access
Front Access Use a Philips screwdriver to remove the four screws securing the module face panel to the TNMC cabinet (Figure 40). Carefully remove the module from the face of the message center. Note: Do not hang the module by its power/signal cable! Figure 40: TNMC Module, Front View Rear Access... -
Page 57: Tnmc Drivers
TNMC Drivers The TNMC driver receives signal from the control console via a signal surge arrestor card and sends data to the modules. Refer to Section 7.4 for more information on signal routing. Figure 42 illustrates a TNMC control assembly with a 4-column MASC driver. -
Page 58: Modules
Each module assembly is made up of a module face plate, 16 LED segments, and a driver. Individual components can be removed for service, but Daktronics recommends that the module be kept intact and that the entire assembly be sent in for repair or replacement. -
Page 59: Power Supplies
Power Supplies Power supply configurations will vary depending on the number and/or color of modules. Replacing a Power Supply To remove a power supply from the display: Access the internal components using the appropriate Front/Rear Access method described in Section 7.5. Disconnect all the wires connected to the power supply. - Page 60 Amber 8x8-2.5" LED Module Assembly 0A-1192-2674 Final Assembly; 8X48-2.5" (64 mm) Red TNMC 0A-1192-2871 Final Assembly; 8X48-2.5" (64 mm) Amber TNMC 0A-1192-2872 See Section 5.13 for information on Daktronics Exchange and Repair and Return program. TNMC Troubleshooting & Maintenance – Model BA-2018...
-
Page 61: Additional Scoreboard Options
Additional Scoreboard Options Radio Control Radio control is an option for all Daktronics outdoor LED scoreboards. The system provides scoreboard control via a 2.4 GHz, extra-high frequency FM signal. The radio transmitter and receiver are not standard. This setup requires a control console equipped with radio output as well as a radio receiver plugged into the power terminal block in the driver/power enclosure and mounted internally to the front panel of the scoreboard. -
Page 63: Appendix A: Reference Drawings
Appendix A: Reference Drawings Segmentation, 7 Segment Bar Digit ................Drawing A-38532 Ad Panel Mounting ....................... Drawing A-52187 Scoreboard Mounting ....................Drawing A-55101 Steel Clip Angle Mounting .................... Drawing A-83301 Address Table, 1 Through 128 .................. Drawing A-115078 Address Table, 129 Through 255 ................Drawing A-115079 Component Locations;... - Page 73 DAKTRONICS, INC. DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESSED CORRECTED S1 PINOUT WRITTEN CONSENT OF DAKTRONICS, INC. DATE: COPYRIGHT 2013 DAKTRONICS, INC. 01 FEB 13 OUTDOOR LED SCOREBOARDS UPDATE DRIVER J-27 FOR CORRECT PIN OUT...
- Page 85 BA-2018-11/21 7 8 9 10 GUEST HOME AVERAGE AT BAT BALL STRIKE...
- Page 90 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESS WRITTEN CONSENT OF DAKTRONICS, INC. OR ITS WHOLLY OWNED SUBSIDIARIES. PER EC-21432, REPLACED A-1633 W/ A-2259 COPYRIGHT 2016 DAKTRONICS, INC. (USA)
- Page 109 Appendix B: Daktronics Warranty and Limitation of Liability Daktronics Warranty and Limitation of Liability...
- Page 111 Equipment from operating for its intended use. With respect to LEDs, “Defects” are defined as LED pixels that cease to emit light. The limited warranty provided by Daktronics does not impose any duty or liability upon Daktronics for partial LED pixel degradation.
- Page 112 In no event shall Daktronics be liable to Purchaser or any other party for loss, damage, or injury of any kind or nature arising out of or in connection with this Warranty in excess of the purchase price of the Equipment actually delivered to and paid for by the Purchaser.
