TUFF SPORT
®
INDOOR LED SCOREBOARDS
INSTALLATION MANUAL
P1749/1763
DD2481645
30 August 2019
BB-2101
BB-2131
BB-2103
BB-2132
BB-2105
BB-2142
BB-2107
BB-2143
BB-2109
BB-2144
BB-2111
BB-2152
BB-2114
BB-2153
BB-2115
BB-2155
BB-2116
BB-3101*
BB-2117
BB-3103*
BB-2119
BB-3105*
BB-2121
BB-3107*
BB-2122
BB-3114*
BB-2123
BB-3115*
BB-2125
BB-3121*
BB-2130
BB-3123*
*ColorSmart or compatible model
& COLORSMART
Rev 07
Models
BB-3125*
SD-2106
BB-3142*
SD-3101*
CU-2001
SD-3102*
H-2101
SD-3103*
H-2102
SD-3106*
H-2103
SQ-2001
H-2104
TI-2030
H-2106
TI-2101
H-2108
TI-2102
H-2111
TI-2103
H-2114
TI-2200
H-2115
TI-3103*
SD-2101
VB-2101
SD-2102
SD-2103
SD-2104
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BB-2101 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daktronics BB-2101

Summary of Contents for Daktronics BB-2101

  • Page 1 BB-3101* H-2108 TI-2102 BB-2117 BB-3103* H-2111 TI-2103 BB-2119 BB-3105* H-2114 TI-2200 BB-2121 BB-3107* H-2115 TI-3103* BB-2122 BB-3114* SD-2101 VB-2101 BB-2123 BB-3115* SD-2102 BB-2125 BB-3121* SD-2103 BB-2130 BB-3123* SD-2104 *ColorSmart or compatible model 201 Daktronics Drive Brookings, SD 57006-5128 www.daktronics.com/support 800.325.8766...
  • Page 2 Daktronics trademarks are property of Daktronics, Inc. All other trademarks are property of their respective companies.

  • Page 3: Table Of Contents

    Table of Contents Introduction ���������������������������������������������������������������������������������������������������������������������������1 Important Safeguards ..........................1 Specifications Label ..........................1 Resources ..............................1 Troubleshooting ............................2 Display Controllers ..........................2 Sport Codes���������������������������������������������������������������������������������������������������������������������������������������3 Product Safety Approval ........................3 Mechanical Installation �������������������������������������������������������������������������������������������������������4 Lifting ..............................4 Wall Mounting ............................5 Single-Section Displays ��������������������������������������������������������������������������������������������������������������������5 Suspension Mounting �����������������������������������������������������������������������������������������������������������������������5 Corner Mounting�������������������������������������������������������������������������������������������������������������������������������5 Multi-Section Displays ����������������������������������������������������������������������������������������������������������������������6 Shot Clock Mounting ..........................7 Hockey Scoring Modules ........................7...
  • Page 4 Table of Contents Changeable Caption Kits ........................16 Goal Lights ............................16 Protective Devices ..........................16 Daktronics Exchange and Repair & Return Programs ����������������������������������������������������17 Exchange Program ..........................17 Repair & Return Program ........................18 Daktronics Warranty & Limitation of Liability ...................18 A Specifications ����������������������������������������������������������������������������������������������������������������������19 Reference Drawings �����������������������������������������������������������������������������������������������������������21 C Daktronics Warranty &...

  • Page 5: Introduction

    Please have the assembly number, model number, and the date manufactured on hand when calling Daktronics customer service to ensure the request is serviced as quickly as possible. Knowing the facility name and/or job number will also be helpful. Note that the Product Number(s) are sometimes used to distinguish different generations of displays that have the same model number.

  • Page 6: Troubleshooting

    Reference Drawings: System Riser Diagram ..................DWG-1007804 Daktronics identifies manuals by the DD or ED number located on the cover page. Listed below are drawing types commonly used by Daktronics, along with the information typically provided. All drawings referenced in this manual are found in the appendices.

  • Page 7: Sport Codes

    4401 (without SOG) Hockey 4402 (with SOG) 2101 (MATCH/GAME) Volleyball 2105 (PLYR/FL/PTS) Wrestling 3101 Squash Product Safety Approval Daktronics indoor scoreboards are ETL-listed, tested to CSA standards, and CE-labeled for indoor use. Contact Daktronics with any questions regarding testing procedures. Introduction...

  • Page 8: Mechanical Installation

    Smaller game/ shot clocks do not require eyebolts and are not equipped with them. Note: Daktronics assumes no liability for damages resulting from incorrect setup or lifting methods. Eyebolts are intended for lifting only. Do not attempt to permanently support the display by the eyebolts.

  • Page 9: Wall Mounting

    Rather than being mounted to the wall or in a corner, a display may be suspended using a special lift eye mounting kit. Refer to DWG-1130959 in Appendix B for more information. Always contact Daktronics about any installation that involves permanently suspending the scoreboard�...

  • Page 10: Multi-Section Displays

    Multi-Section Displays In typical multi-section installations, the lowest display section is installed first, but be sure to verify with the mounting drawing. 1� Use eyebolts to lift the lowest display section into position on the wall. 2� Ensure the cabinet is level, and secure it to the wall by attaching 1/2"...

  • Page 11: Shot Clock Mounting

    Multi-sided shot clocks are frequently mounted to vertical backstop supports. Refer to DWG-91230 in Appendix B for shot clock mounting information. Note: Daktronics does not supply the hardware or brackets to mount shot clocks to backstops and is not responsible for the integrity or suitability of mounting systems manufactured and installed by others.

  • Page 12: Electrical Installation

    Block Diagram: AS5000 BB- VB and WR #3 ............DWG-124688 Block Diagram, A/S 3000 or 5000 Hockey ............DWG-124689 Figure 9 illustrates a wired setup between a scoreboard and controller. Daktronics part numbers are shown in parentheses. DWG-124686, DWG-124688, and DWG-124689 in Appendix B also show power and signal layouts.

  • Page 13: Power

    – must be electrically grounded. Only qualified individuals may perform electrical work, including verification of ground resistance. Daktronics is not responsible for improper grounding or damage incurred as a result of improper grounding. Grounding methods must meet the provisions of all applicable local and national codes.

  • Page 14: Lightning Protection

    (J-box) near the display. Refer to Figure 9 for typical signal layout. Refer also to DWG-28124 and DWG-125316 in Appendix B for signal wire connection. At a minimum, use a paired, 22 AWG shielded cable (Daktronics part # W-1077). 1� Connect the cable to a dual 1/4" J-box at the control console end.

  • Page 15: Bb-2117 & Bb-2119 Power/Signal Connection

    For more information, refer to the Gen VI Radio Installation Manual (DD2362277), provided with the receiver unit and available online at www.daktronics.com/manuals. RC-100/RC-200 Control A hand-held RC-100/RC-200 wireless radio control system requires a base station receiver plugged into the 6-pin J21 jack on the primary driver and mounted internally to the front panel of the display.

  • Page 16: Statistics Display & Hockey Module Signal Connection

    [To Controller] Wireless Control Also Available J31 - J32 - SIGNAL IN SIGNAL OUT J31 - J32 - J31 - SIGNAL IN SIGNAL OUT SIGNAL IN daktronics PLYR FLS PLYR FLS HOME GUEST PERIOD FOULS PLAYER FOUL FOULS SCORE MATCH SCORE...

  • Page 17: H-2103 Connection

    H-2103 Connection H-2103 hockey scoring modules must connect to an H-2102 or H-2115. H-2103 modules may be placed above, below, or beside other scoreboard sections and are equipped with digit jacks on both the top and the bottom of the cabinet. Connect the two DIGIT INPUT jacks (J11 and J12) to the matching DIGIT OUTPUT jacks (J11 and J12) using the included 9-pin to 9-pin cables.

  • Page 18: Scoreboard Options

    Scoreboard Options Time of Day Mode Time of Day (TOD) mode allows the scoreboard to function as a clock when no All Sport signal is present. The instructions below DO NOT apply to ColorSmart models. Note: TOD mode is available on scoreboards with driver firmware version 1.0 or higher. Also, the scoreboard must have at least four clock digits.

  • Page 19: Team Name Message Centers & Electronic Captions

    Be sure to set the volume according to the acoustics of the facility. Visual Horn Indicator (VHI) In addition to the horn, Daktronics offers a visual horn indicator (VHI) that lights up when the buzzer sounds. To install a VHI, the existing horn wiring must be tapped into in order to provide power and signal.

  • Page 20: Time Outs Left (Tol) Digits

    To install optional hockey goal lights, refer to the Indoor Hockey Goal Lights Manual (ED- 13358). Protective Devices Daktronics indoor displays have been designed so that indoor sports balls impact will not damage the LEDs or display cabinet, reducing the need for protective devices. However, Daktronics also makes optional protective devices, including screens and netting, to help prevent damage to the display due to normal ball impacts.

  • Page 21: Daktronics Exchange And Repair & Return Programs

    Fill out and attach the enclosed UPS shipping document. c� Ship the part to Daktronics. 3� The defective or unused parts must be returned to Daktronics within 5 weeks of initial order shipment� If any part is not returned within five (5) weeks, a non-refundable invoice will be presented to the customer for the costs of replenishing the exchange parts inventory with a new part.

  • Page 22: Repair & Return Program

    Repair & Return Program For items not subject to exchange, Daktronics offers a Repair & Return Program. To send a part for repair, follow these steps: 1� Call or fax Daktronics Customer Service� Refer to the appropriate number in the chart on the previous page.

  • Page 23: A Specifications

    When viewing the digital version of this manual, simply click a link below to open it. • When referencing the printed version of this manual, open an Internet browser and go to www�daktronics�com/Web%20Documents/HSPR-Documents/DD#######�pdf (replace “DD#######” with one of the Spec Sheet numbers shown below). Model...
  • Page 24 This page intentionally left blank.

  • Page 25: B Reference Drawings

    Reference Drawings Refer to Resources (p�1) for information regarding how to read the drawing number. Any contract-specific drawings take precedence over the general drawings. Reference Drawings: Signal Connection; Installation ................DWG-28124 Backstop Mounting Suggestions ................. DWG-91230 Wiring for Shot Clock on Portable Backstop............DWG-98293 Block Diagram: AS5000 BB- VB and WR #1 ............
  • Page 26 This page intentionally left blank.
  • Page 29 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESS WRITTEN CONSENT OF DAKTRONICS, INC. OR ITS WHOLLY OWNED SUBSIDIARIES. COPYRIGHT 2018 DAKTRONICS, INC. (USA) BASKETBALL SCOREBOARDS PROJECT:...
  • Page 31 W-1238, 30 FT ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY W-1340, 10 FT ANY MEANS WITHOUT THE EXPRESS WRITTEN CONSENT OF J1,J2 DAKTRONICS, INC. OR ITS WHOLLY OWNED SUBSIDIARIES. COPYRIGHT 2018 DAKTRONICS, INC. (USA) OR J3 120V AC SHOT CLOCK CONTROL...
  • Page 32 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESSED WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2012 DAKTRONICS, INC. ALL SPORT 5000 BLOCK DIAGRAM: A/S5000 HOCKEY E BRAVEK...
  • Page 34 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESS WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2015 DAKTRONICS, INC. TUFF SPORT INDOOR SCOREBOARDS 12V DC HORN OPTION INSTALLATION...
  • Page 36 DAKTRONICS, INC. THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESSED WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2013 DAKTRONICS, INC. TUFF SPORT SCOREBOARDS CORNER MOUNTING A VANBEMMEL...
  • Page 39 TEAM NAME/ELECTRONIC CAPTION MOUNTING AREA ON SCOREBOARD TNMC CAPTION BASE TNMC CAPTION PANEL 8-32 X .5" SCREW 1144 NOTE: ALIGN CAPTION CENTER HORIZONTALLY NUTSERT BASED ON SCOREBOARD AND 8-32 X .5" SCREW 1269 1144 CLOSEST ALIGNMENT HOLE. CENTER CAPTION VERTICALLY. PROCEDURE: 1.
  • Page 40 INSTALL THE EYEBOLTS IN HOLES IN THE ANGLES AND SECURE WITH LOCK NUTS. ATTACH SUSPENSION CABLES TO EACH EYEBOLT WITH A SHACKLE (CLEVIS) AND PIN. DAKTRONICS RECOMMENDS THAT TWO CABLES BE USED AT EACH END OF THE SCOREBOARD FOR REDUNDANCY. CABLES DIVERGE TO MINIMIZE SWINGING.

  • Page 41: C Daktronics Warranty & Limitation Of Liability

    Daktronics Warranty & Limitation of Liability This section includes the Daktronics Warranty & Limitation of Liability statement (SL-02374)� Daktronics Warranty & Limitation of Liability...
  • Page 42 This page intentionally left blank.
  • Page 43 Warranty Coverage. Daktronics warrants to the original end user (the “End User”, which may also be the Purchaser) that the Equipment will be free from Defects (as defined below) in materials and workmanship for a period of one (1) year (the “Warranty Period”). The Warranty Period shall commence on the earlier of: (i) four weeks from the date that the Equipment leaves Daktronics’...
  • Page 44 In no event shall Daktronics be liable for loss, damage, or injury of any kind or nature arising out of or in connection with this Warranty in excess of the Purchase Price of the Equipment. The End User’s remedy in any dispute under this Warranty shall be ultimately limited to the Purchase Price of the Equipment to the extent the Purchase Price has been paid.
  • Page 45 For End User’s protection, in addition to that afforded by the warranties set forth herein, End User may purchase extended warranty services to cover the Equipment. The Extended Service Agreement, available from Daktronics, provides for electronic parts repair and/or on‐site labor for an extended period from the date of expiration of this warranty. Alternatively, an Extended Service Agreement may be purchased in conjunction with this Warranty for extended additional services.
  • Page 46 This page intentionally left blank.
