This manual explains the troubleshooting and service of Daktronics Outdoor LED Scoreboards. For additional information regarding the safety, installation, operation, or service of these displays, refer to the telephone numbers listed in Section 4: Daktronics Exchange and Repair & Return Programs (p�28). This manual is not specific to a particular installation.
Reference Drawings: System Riser Diagram ..................DWG-1007804 Daktronics identifies manuals by the DD or ED number located on the cover page. Listed below are drawing types commonly used by Daktronics, along with the information typically provided. All drawings referenced in this manual are found in the appendices.
Troubleshooting Disconnect power before doing any repair or maintenance work on the display� Permit only qualified service personnel to access internal display electronics. Disconnect power when not using the display� Troubleshooting Table This section lists potential problems with the system, indicates possible causes, and suggests corrective action. This list does not include every possible problem, but it does represent some of the more common situations that may occur.
Page 8
Problem Possible Cause Solution/Items to Check Ensure the correct sport code is being Incorrect sport code used for the display model. Refer to the appropriate console operation manual. Display digits light, but not in the correct order Ensure all drivers are set to the correct address.
5500. Refer to schematic drawings and ED- 12224 (see www.daktronics.com/manuals). Component Locations and Access Component location varies with each display model. Refer to the component location drawings attached to the product specification sheets listed in Appendix A. For component locations of Modular and Hybrid Football Scoreboards, refer to the tables in Appendix A.
Scoreboard Digit panels are held in place on the display face by an offset flange across the top and by Face Panel screws at the bottom, as shown in Figure 5. To open a digit panel: Digit 1� Hold the digit panel in place by putting Digit Panel hand pressure on it and remove the holding screws.
Replacing Digit Segments Digits that are 24" or larger are composed of seven circuit board segments. The digit segment circuit boards are mounted to the back of the digit panel (Figure 7). Do not attempt to remove individual LEDs; it may be possible to make repairs by removing just the defective segment.
ATTENTION: METTRE HORS TENSION TOUS LES SECTIONNEURS CERTIFIED TO CSA INTEGRS AVANT D'ENTREPRENDRE LE DEPANNAGE. STD C22.2 NO. 207 INSTALLER A L'EXTERIEUR (After July 2020) 17800 OUTDOOR USE DAKTRONICS 201 DAKTRONICS DR. BROOKINGS, SD PHONE 800-325-8766 Figure 9: Driver Enclosure Components (Gyrus) Troubleshooting...
Several models contain more than one driver to accommodate all of the digits and indicators. Refer to the component location drawings in Appendix A to determine the type and number of drivers for a particular model. When troubleshooting driver problems, four red LEDs labeled DS1, DS2, DS5, and DS8 provide the following diagnostic information: Function Operation...
Setting the Driver Address Reference Drawings: Address Table; Rotary Switches H and L ............DWG-1198765 Since the same LED drivers can be used for many display models, each driver must be set to receive the correct signal input, or address, for the model in which it is being used.
Tennis Models Refer to DWG-1202417 in Appendix B for addressing information for up to 12 courts. Modular Football Models Information Driver # Shown & Address Clock HOME / GUEST; DOWN / TO GO; BALL ON / QTR Hybrid Football Models Driver # Model &...
Note: If replacing the 1000 W power supply (Daktronics part # A-1856R) does not seem to resolve the problem, try replacing its circuit board (part # 0P-1337-2000). This circuit board also contains fuses for each output jack.
HOME GUEST RC-200 hand-held controller, or the DAK Score mobile app, the display will show “bX CY” where X is the Broadcast DAKTRONICS group number and Y is the Channel number. The default is b1C1. RC-100 • If there is a clock, the settings...
REV 01 POWER (Figure 12). Status Indicators RADIO IN RANGE DATA OUT Note: While it is necessary for the display DAKTRONICS WIRELESS RECEIVER to be powered on to check the 2.4GHZ indicators, always disconnect power before servicing. Remove Cover to 2�...
RC-100 Base Station 1� Use a small flathead screwdriver to set the S1 switch (Figure 14) to the desired channel (1-15). 2� Securely close the display access panel. 3� Enter the correct channel setting and sport code into the RC-100 handheld controller to test the radio connection.
Page 22
**** Use for 36" and 48" digits built prior to May 2016. The entire digit panel must be replaced and requires a power supply harness adapter (0A-1192-0411). Refer to Section 4: Daktronics Exchange and Repair & Return Programs (p�28) for information on exchanging or returning parts.
Characters are shown on one line using single-stroke fonts. TNMCs and electronic captions (Figure 15) are both available with red, amber, or white LEDs. Refer to the table below for additional message center specifications. HAWKS BEARS TNMC DAKTRONICS DOWN TO GO BALL ON Electronic Caption...
Troubleshooting The table below lists potential problems with the display and indicates corrective actions. This list does not include every symptom that may be encountered, but it does present several of the most common situations that may occur. Problem Solution/Items to Check Check/replace the ribbon cables on the module.
Display signal routing can be summarized as follows: 1� Data from the All Sport console (or DakTennis software) travels via cable harness into the scoreboard. 2� The signal travels to the driver/power enclosure through the J1 connector on the signal surge card. 3�...
Note: White 46mm TNMCs built after May 2017 feature power supply enclosures with covers that must be removed to access the power supply. Daktronics outdoor LED scoreboards are typically front-accessible, but some models may be ordered with rear service access. For that reason, TNMCs and electronic captions have been designed so that they may be accessed from either the front or rear.
Rear Access 1� To access the internal components from the rear, remove the appropriate rear- access panel from the display cabinet by loosening all four of the screws. 2� Slide the access panel sideways and carefully lift it off the loosened screws. Note: Be careful when removing and handling the access panels as internal display components may still be attached to them.
The S2 DIP switch is the component for setting the address (switches #1-4). With switches 1-4 off, the address setting for a TNMC is preset at “221” (16x80 TNMCs use address “231” for HOME and “232” for GUEST). Multi-court tennis scoreboards (and single-court scoreboards controlled by DakTennis) with TNMCs will require different addresses.
Each module assembly consists of a module housing (containing LEDs and the driver) and a louver assembly. Individual components such as louvers can be removed for service, but Daktronics recommends that the module be kept intact and that the entire assembly be sent in for repair or replacement.
Weather Stripping To ensure that the display is waterproof, weather stripping has been installed around each module. It is important that the weather stripping is attached properly at all times, or water may leak into the display and damage the components. When installing a new module, take note of the following points: •...
Fill out and attach the enclosed UPS shipping document. c� Ship the part to Daktronics. 3� The defective or unused parts must be returned to Daktronics within 5 weeks of initial order shipment� If any part is not returned within five (5) weeks, a non-refundable invoice will be presented to the customer for the costs of replenishing the exchange parts inventory with a new part.
Repair & Return Program For items not subject to exchange, Daktronics offers a Repair & Return Program. To send a part for repair, follow these steps: 1� Call Daktronics Customer Service� United States & Canada: 1-800-DAK-TRON (325-8766) Outside the U.S. & Canada: +1-605-275-1040 2�...
Specifications and Schematics Click the links below to view scoreboard product specification sheets and schematic drawings. Product-specific installation and component location drawings are included with each spec sheet or linked below. Note: Refer to Figure 1 to determine a display's model number. Single-Section Models Model Spec Sheet Schematic...
Page 36
* If built before May 2016, see 1202017. ** If built before May 2016, see 3002321. *** If white digits, see 3312544. If red/amber digits and built before May 2016, see 3002321; if white digits and built before May 2016, see 1202017. **** If white digits, see 3302813.
Reference Drawings Click the links below to view additional drawings referenced in this manual. Any contract-specific drawings take precedence over the general drawings. Reference Drawings: 38532 Segmentation, 7 Segment Bar Digit ................274431 Enclosure: 1000W Power Supply ................. 328274 Address Table: Driver - MCAST G2 - TNMC Switch ............ 793970 Specifications;...
Daktronics Warranty & Limitation of Liability This section includes the Daktronics Warranty & Limitation of Liability statement (SL-02374)� Daktronics Warranty & Limitation of Liability...
Page 45
Warranty Coverage. Daktronics warrants to the original end user (the “End User”, which may also be the Purchaser) that the Equipment will be free from Defects (as defined below) in materials and workmanship for a period of one (1) year (the “Warranty Period”). The Warranty Period shall commence on the earlier of: (i) four weeks from the date that the Equipment leaves Daktronics’...
Page 46
In no event shall Daktronics be liable for loss, damage, or injury of any kind or nature arising out of or in connection with this Warranty in excess of the Purchase Price of the Equipment. The End User’s remedy in any dispute under this Warranty shall be ultimately limited to the Purchase Price of the Equipment to the extent the Purchase Price has been paid.
Page 47
For End User’s protection, in addition to that afforded by the warranties set forth herein, End User may purchase extended warranty services to cover the Equipment. The Extended Service Agreement, available from Daktronics, provides for electronic parts repair and/or on-site labor for an extended period from the date of expiration of this warranty. Alternatively, an Extended Service Agreement may be purchased in conjunction with this Warranty for extended additional services.
