Page 1 Generation IV Multi-Section Outdoor LED Scoreboards Display Manual ED-16960 Rev 2 – 19 November 2008 Models SO-2014 BA-1518 FB-1424 FB-1830L MS-2118 SO-2030 BA-1524 FB-1430 FB-2001 MS-2918 BA-2006 FB-1524 FB-2002 BA-2007 FB-1530 FB-2003 SO-1424 BA-2012 FB-1624 FB-2004 SO-1624 BA-2013 FB-1630 FB-2007...
Page 2 – without written permission of the publisher. ® ® All Sport and PanaView are trademarks of Daktronics, Inc. Other trademarks used in this manual are the property of their respective owners.
Page 3: Table Of Contents
Replacing a Driver ................8-4 Schematic ....................8-4 LED Drivers ....................8-5 Segmentation and Digit Designation ............8-5 Lightning Protection .................. 8-6 Troubleshooting ..................8-7 Replacement Parts ..................8-8 Daktronics Exchange and Repair and Return Programs ......8-10 Table of Contents...
Page 4 Exchange Program ................8-10 Repair and Return Program .............. 8-11 How to reach us ................8-11 Section 9: Team Name Message Center Maintenance ........ 9-1 Team Name Message Center System Overview ........9-1 Maintenance and Troubleshooting Overview ..........9-2 Signal Summary..................9-2 Power Summary..................
Page 5: Introduction
Reference drawings are grouped and inserted in alphanumeric order in Appendix A and Appendix B. Listed below are a number of drawing types commonly used by Daktronics, along with the information that each is likely to provide. System riser diagrams: overall system layout from control room to display, power and phase requirements.
Page 6: Daktronics Nomenclature
For example, this manual would be referred to as ED-16960. The serial and model numbers of a Daktronics scoreboard can be found on the ID label on the display. The label will be similar to the one shown in Figure 2. When calling Daktronics Customer Service, please have this information available to ensure that your request is serviced as quickly as possible.
Page 7: Product Overview
“M- _ _ _ ” denotes a metal part, and “0S-_ _ _ _ _ _” typically denotes a fabricated metal assembly. Product Overview The Daktronics outdoor LED scoreboards are part of a family of scoring and timing displays designed to offer easy installation, readability, and reliability. Microprocessor control assures consistent operation and accuracy.
Page 8: Model Names
-11 are outdoor scoreboards, 120 V and they feature red digits; -21 are outdoor scoreboards, 120 V and feature amber digits. Product Safety Approval Daktronics outdoor scoreboards are ETL listed and tested to CSA standards for outdoor use. Contact Daktronics for information regarding testing procedures. Introduction...
Page 9: Model Identification
Section 2: Model Identification Use the following drawings to determine the model number of your scoreboard. The drawings listed here are located in Appendix A: Reference Drawings; where they are inserted in alphanumeric order by drawing number. Individual scoreboard drawings may also be found in the Appendix.
Page 11: Specifications
See Section 8.4 for more details. Signal wires must be a minimum of 22 AWG with shield. Daktronics recommends using W-1614. Models with an –11 or –12 suffix feature red digits and indicators; suffixes –21 and –22 indicate amber digits.
Page 12 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address BA-1524 2 Total H9’-0”, W16’-0”, D6” 480 lb Indicators 2” 300 W 120 V AC 2.5 A (2743 mm, 4877 (218 kg)
Page 13 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address BA-2006 2 Total H7’-0”, W28’-0”, D6” 640 lb Innings, 1200 W 120 V AC 10 A (2134 mm, 8534 (290 kg)
Page 14 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address BA-2007 2 Total H9’-4”, W36’-0”, D8” 840 lb Innings, 1200 W 120 V AC 10.0 A (2845 mm, 10973 (381 kg)
Page 15 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address BA-2013 2 Total H9’4”, W36’-0”, D6” 840 lb Innings, 1500 W 120 V AC 12.5 A (2845 mm, 10973 (382 kg)
Page 16 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address BA-3718 4 Total H7’-0”, W28’-0”, D6” 640 lb Innings, 900 W 120 V AC 7.5 A (2134 mm, 8534 (290 kg)
Page 17 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address BA-3724 4 Total H9’-4”, W36’-0”, D6” 840 lb Innings, 900 W 120 V AC 7.5 A (2845 mm, 10973 (381 kg)
Page 18 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address FB-1424 2 Total H8’-0”, W18’-0”, D6” 520 lb Indicators 8” 600 W 120 V AC 5.0 A w/TNMC (2438 mm, 5486...
Page 19 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address FB-1524 2 Total H8’-0”, W18’-0”, D6” 400 lb Indicators 8” 300 W 120 V AC 2.5 A (2438 mm, 5486 (181 kg)
Page 20 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address FB-1530 2 Total H8’-0”, W25’-0”, D6” 700 lb Clock 30” 600 W 120 V AC 5.0 A w/TMNC (2438 mm, 7620...
Page 21 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address FB-1630 2 Total H8’-0”, W25’-0”, D6” 720 lb Clock 30 900 W 120 V AC 7.5 A w/TNMC (2438 mm, 7620...
Page 22 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address FB-1630L 2 Total H8’-0”, W32’-0”, D6” 840 lb Clock 30” 900 W 120 V AC 7.5 A w/TNMC (2438 mm, 9754...
Page 23 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address FB-1730 2 Total H8’-0”, W25’-0”, D6” 740 lb Clock 30” 900 W 120 V AC 7.5 A w/TNMC (2438 mm, 7620...
Page 24 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address FB-1830 2 Total H8’-0”, W25’-0”, D6” 760 lb Clock 30” 900 W 120 V AC 7.5 A w/TNMC (2438 mm, 7620...
Page 25 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address FB-1830L 2 Total H8’-0”, W32’-0”, D6” 900 lb Clock 30” 900 W 120 V AC 7.5 A w/TNMC (2438 mm, 9754...
Page 26 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address FB-2001 2 Total H10’-0”, W32’-0”, 1060 lb Clock 30” 900 W 120 V AC 7.5 A w/TNMC D6”...
Page 27 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address FB-2002 2 Total H8’0”, W20’-0”, D6” 640 lb TOL 15” 900 W 120 V AC 7.5 A w/TNMC (2438 mm, 6096...
Page 28 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address FB-2004 2 Total H10’-0”, W32’-0”, 880lb Clock 30” 600 W 120 V AC 5.0 A D6”...
Page 29 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address FB-2007 2 Total Indicators 8” 300 W 120 V AC 2.5 A H8’-0”, W18’-0”, D6” 560 lb (203 mm) (2438 mm, 5486...
Page 30 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address MS-2020 2 Total H9’-0”, W18’-0”, D6” 450 lb Clock, Score 300 W 120 V AC 2.5 A (2743 mm, 5486 (204 kg)
Page 31 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address • SO-1424 2 Total H8’-0”, W18’-0”, D6” 400 lb 300 W 120 V AC 2.5 A Indicators 8”...
Page 32 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address • SO-1624 2 Total H8’-0”, W18’-0”, D6” 520 lb 900 W 120 V AC 7.5 A Indicators 8”...
Page 33 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address • SO-1830 2 Total H8’-0”, W25’-0”, D6” 680 lb 900 W 120 V AC 7.5 A Clock 30”...
Page 34 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address • SO-1830 L 2 Total H8’-0”, W32’-0”, D6” 900 lb 900 W 120 V AC 7.5 A Clock 30”...
Page 35 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address • SO-1930 2 Total H8’-0”, W25’-0”, D6” 760 lb 900 W 120 V AC 7.5 A Clock 30”...
Page 36 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address • SO-2014 2 Total H10’-0”, W32’-0”, 880 lb 600 W 120 V AC 5.0 A Clock 30”...
Page 37 Model Number of Dimensions Weight Digit Size Maximum Power Amps Driver Sections (Height, Width, Uncrated Wattage per Line Number Depth) (Crated) Digit Color (Single Phase) Address • S0-2030 2 Total H8’-0”, W25’-0”, D6” 900 lb 900 W 120 V AC 7.5 A Clock 30”...
Page 39 Drawings, where they are inserted in alphanumeric order by drawing number. Drawings for models that offer optional team name message centers typically include views with and without the TNMC components. Model Drawing Title Drawing BA-1518 Component Locations; BA-1518-11/-21, G3 A-229343 BA-1518 TNMC Component Locations; BA-1518-11/-21, G3 A-179745 BA-1524 Component Locations; BA-1524-11/-21, G3...
Page 40 Model Drawing Title Drawing FB-1430 TNMC Component Locations; FB-1430-11/-21, G3 A-185439 FB-1524 TNMC Component Locations; FB-1524-11/-21, G3 A-181757 FB-1530 Component Locations; FB-1530-11/-21, G3 A-182405 FB-1530 TNMC Component Locations; FB-1530-11/-21, G3 A-182405 FB-1624 Component Locations; FB-1624-11/-21, G3 A-183010 FB-1630 Component Locations; FB-1630-11/-21, G3 A-181807 A-181807 FB-1630 TNMC...
Page 41 Model Drawing Title Drawing MS-2118 Component Locations; MS-2118-11/-21, G3 A-182031 MS-2918 Component Locations; MS-2918-11/-21, G3 A-183029 SO-1424 Component Locations; SO-1424-11/-21, G3 A-188778 SO-1424 TNMC Component Locations; SO-1424-11/-21, G3 A-188778 SO-1624 Component Locations; SO-1624-11/-21, G3 A-188178 A-188178 SO-1624 TNMC Component Locations; SO-1624-11/-21, G3 SO-1830 Component Locations;...
Page 43: Schematics
Drawing A-293354. Models Schematic Name Drawing BA-1518 Schematic; Gen IV Outdoor LED, 16 Column A-285779 Drvr BA-1518 TNMC Schematic; Gen III & IV, OD LED, 1 Drv A-179790 w/TNMC BA-1524 Schematic; Gen III & IV Outdoor LED, 16 A-285779 Column Drvr BA-1524 TNMC Schematic;...
Page 44: Ba-3718 Tnmc
Models Schematic Name Drawing BA-3718 Schematic; Gen III & IV, OD LED, 3 Drvr A-179541 Display BA-3718 TNMC Schematic; Gen III & IV, OD LED, 3 Drv A-180081 w/TNMC BA-3724 Schematic; Gen III & IV, OD LED, 3 Drvr A-179541 Display BA-3724 TNMC Schematic;...
Page 45: Fb-1830 Tnmc
Models Schematic Name Drawing FB-1830 TNMC Schematic; Gen III & IV, OD LED, 2 Drv Multi- A-285418 Sec w/TNMC FB-1830L Schematic; Gen III & IV, OD LED, 2 Drv A-180637 FB-1830L Schematic; Gen III & IV, OD LED, 2 Drv Multi- A-180688 TNMC Sec w/TNMC...
Page 46: So-1830L
Models Schematic Name Drawing Sec w/TNMC SO-1830L Schematic; Gen III & IV, OD LED, 2 Drv A-180637 SO-1830L Schematic; Gen III & IV, OD LED, 2 Drv Multi- A-180688 TNMC Sec w/TNMC SO-1930 Schematic; Gen III & IV, OD LED, 2 Drv A-180637 SO-1930 TNMC Schematic;...
Page 47: Mechanical Installation
Daktronics must approve scoreboard protection devices not provided by Daktronics prior to installation. Failure to follow this approval procedure will void the scoreboard warranty. Daktronics makes available optional devices, including screens and netting, to help protect the scoreboard from damage due to normal ball impacts. Footings and Beams Reference Drawings: Installation Specifications, BA-1518 .......
Page 48: Drawing Title
Model Drawing Title Number BA-2007 Installation Specifications, BA-3724 A-126445 BA-2012, BA-2020 Installation Specifications, BA-2012 A-202766 BA-2013 Installation Specification, BA-3724 A-126445 BA-3718 Installation Specifications, BA-3718 A-126455 BA-3724 Installation Specifications, BA-3724 A-126445 MS-2009 Installation Specifications, MS-2009 A-144415 MS-2020 Installation Specifications, MS-2020 A-241622 MS-2118 Installation Specifications, MS-2118 A-128206...
Page 49: Drawing Title
Models without Drawing Titles Number TNMC Structure, Football A-44556 FB-2001, FB-2004, Beam and Footing Recommendations, FB-200X A-160931 SO-2014 Structure, Football A-44556 FB-2002, FB-2003 Installation Specifications, FB-2002 & FB-2003 A-128044 A-44556 Structure, Football Models with Drawing Titles Number TNMC FB-1424, FB-1524, Beam &...
Page 50: Lifting The Scoreboard
The eyebolts are located along the top of the cabinet for each scoreboard or scoreboard section. Note: Daktronics strongly recommends using a spreader bar, or lifting bar, to lift the display. Using a spreader bar ensures that the force on the eyebolts is straight up, minimizing lifting stress.
Page 51: Scoreboard Mounting
If you must use this method, ensure a minimum angle between the chain and scoreboard of at least 45degrees. Note: Daktronics assumes no liability for scoreboard damage resulting from incorrect setup or incorrect lifting methods. Eyebolts are intended for lifting only. Do not attempt to permanently support the display with the eyebolts.
Page 52: Scoreboard Mounting Using Spacers
7. Model BA-3718-11 requires the use of mounting straps. Refer to Drawing A-114415 for installation instructions. Scoreboard Mounting Using Spacers Reference Drawing: Scoreboard Mtg; Scoreboard with Spacers ....Drawing A-182909 Many Daktronics customers add message centers or advertising panels to the top or bottom...
Page 53: Ad Panel Mounting
Spacer size is determined by the height and the extra depth required for the front surface of the scoreboard to match that of the optional message center or ad panel. Daktronics does not provide these spacers. Ad Panel Mounting Reference Drawing: Ad Panel Mounting............Drawing A-52187...
Page 55: Electrical Installation
Reference Drawing: Schematic; Gen IV Outdoor LED, 16 Column Drvr .... Drawing A-285779 Daktronics outdoor LED scoreboards have been designed for easy access to components, and the power and control signal hookup has been simplified. Front panels are removable to allow access to the digits, cabling, and other electronic components.
Page 56: Grounding
Note: Displays MUST be grounded according to the provisions outlined in Article 250 of the National Electrical Code and according to the specifications in this manual. Daktronics recommends a resistance-to-ground of 10 ohms or less. The contractor performing the electrical installation can verify ground resistance.
Page 57: Power And Signal Connection
Figure 6: Power Terminal Block Drawing A-293354. The conventional power termination panel has been eliminated from Daktronics outdoor scoreboards; the power feeder circuit connects directly to a terminal block in the driver enclosure, as shown in Figure 6 above.
Page 58: Fiber Optic
A minimum cabling of multi-mode; 62.5/125 um; and 2-core fiber cable is recommended. (Daktronics part number is W-1242.) See Figure 8 for the location of fiber connector on the LED driver. (See Drawing A-288137 for the complete image of the LED driver.)
Page 59: Interconnect Harness Connections
Interconnect Harness Connections All multi-section football and soccer scoreboards use an interconnect harness as a connection between the digits of the top section and their corresponding driver in the lower section. Typically, one driver runs the top section of the board, while the other driver runs the bottom section, but only the top section digits use the interconnect harness.
Page 60: Multiple Driver Connections
harnesses, and each harness may contain as many as nine individual digit connectors. They will be routed through 2 " holes in the scoreboard cabinets and into Section A, where the connectors will plug into the appropriate driver connections. (Digits in all sections have been connected and tested at the factory;...
Page 61: Scoreboard Maintenance And Troubleshooting
Section 9 or the service manual that accompanies those units. Cabinet Specifications Cabinets for the Daktronics outdoor LED scoreboards are constructed of heavy- gauge aluminum. Exact dimensions and weights for each model are listed in the chart in Section 3. Removable panels for digits, indicators, and component access are detailed in each model’s component locations drawing, listed in Section 4.
Page 62: Replacing A Digit
Remove the nuts and lift the digit off the standoff screws. The push nuts can be removed in several ways, but Daktronics recommends using a " nut driver. 4. Position a new digit over the screws and tighten the nuts.
Page 63: Replacing A Digit Segment
Replacing a Digit Segment Reference Drawing: Digit Assemblies; Gen III & IV LED Digits ......Drawing B-177679 When a digit malfunctions, in most cases it is necessary to replace the entire digit circuit board. Some larger digits (24", 30", 36"), however, are constructed in segments, as shown in Figure 13, and it may be possible to make repairs by removing only the defective segment.
Page 64: Replacing A Driver
Schematic; Gen IV Outdoor LED, 16 Column Drvr .... Drawing A-285779 Drawings A-179541, A-179790, A-180081, A-180637, A-180688 and A-285779 are the schematic diagrams for the Daktronics multi-section scoreboards and the 16- column drivers used in them. The schematics include power and signal inputs and all...
Page 65: Led Drivers
wiring for the models described in this manual. Refer to Section 5 for a complete listing of scoreboards and the appropriate schematic. LED Drivers Reference Drawings: Address Table, 1 Through 128 ........... Drawing A-115078 Specifications; LED Driver III, 16 Col ......... Drawing A-288137 Address Table 1;...
Page 66: Lightning Protection
In each digit, certain LEDs always go on and off together. These groupings of LEDs are referred to as segments. Drawing A-38532 illustrates digit segmentation. It also details which connector pin is wired to each digit segment and the wiring color code used throughout the display.
Page 67: Troubleshooting
Troubleshooting This section lists potential problems with the scoreboard and indicates possible causes and corrective actions. This list does not include every possible problem, but does represent some of the more common situations that may occur. Symptom/Condition Possible Cause Console not connected or Scoreboard will not light poor connection No power to control console...
Page 68: Replacement Parts
Replacement Parts Refer to the following table for Daktronics scoreboard replacement parts. Description Location Daktronics Part No. Driver enclosure 0P-1192-0383 Driver, 16 col, outdoor, LED Power supply, 24 V, 150W, 86- Driver enclosure A-1720 132 V input Driver enclosure 0P-1110-0011...
Page 69 Description Location Daktronics Part No. Digit segment, 24” outdoor LED, Scoreboard 0P-1192-0205 red (horizontal) Digit segment, 24” outdoor LED, Scoreboard 0P-1192-0204 red (vertical) Digit segment, 24” outdoor LED, Scoreboard 0P-1192-0219 amber (horizontal) Digit segment, 24” outdoor LED, Scoreboard 0P-1192-0218 amber (vertical) Digit segment, 30”...
Page 70: Daktronics Exchange And Repair And Return Programs
4. You must send the problem part to Daktronics within 30 days. If you do not ship it to Daktronics within 30 working days from the invoice date, Daktronics assumes you are purchasing the replacement part outright with no exchange. You will therefore be invoiced for the replacement part at the full purchase price, with the balance due upon receipt.
Page 71 The company also reserves the right to refuse parts that have been damaged due to acts of nature or causes other than normal wear and tear. For items not subject to exchange, Daktronics offers a Repair and Return Program. To send a part for repair, follow these steps.
Page 73: Team Name Message Center Maintenance
Section 9: Team Name Message Center Maintenance IMPORTANT NOTES: 1. Disconnect power before doing any repair or maintenance work on the message centers. 2. Permit only qualified service personnel to access the internal electronics of the display. Disconnect power when the scoreboard is not in use. Team Name Message Center System Overview Team name message centers (TNMCs) are available in two sizes: an 8x32 matrix model with four 8x8-pixel modules, and an 8x48 model comprised of six 8x8 modules.
Page 74: Maintenance And Troubleshooting Overview
Standard Daktronics outdoor LED scoreboards typically are front-accessible, but some models may be ordered with rear service access. For that reason, Daktronics team name message centers have been designed so that they may be accessed from both the front and rear for easy maintenance and repair of internal components.
Page 75: Service And Diagnostics
Schematic, Amber TNMC, GEN IV ......Drawing A-252645 Schematic, Red TNMC, Gen IV ........Drawing A-252681 Component Locations; 832/848 Red/Amb Led TNMC, G-4 ........Drawing A-257029 Refer to your schematic, Drawings A-252645 or A-252681, for complete information on TNMC power routing. Drawing A-257029 indicates the location of the internal electronic components. Note that amber TNMCs always contain two power supplies, while red TNMCs require only a single power supply.
Page 76: Diagnostic Leds
Figure 17: TNMC Controller Assembly Note that connectors J25 and J26 control Home and Guest display. When the ribbon cable is plugged into J25, the TNMC sends home team information to the matrix display. In the opposite message center, the signal cable would be plugged into the J26 connector, and guest information would be displayed.
Page 77: Removing/Changing The Controller
Removing/Changing the Controller Color Function Operation Summary CL signal Steady on DS1 will be on or blinking when the or blinking driver is receiving signal and off when there is no signal. Green CL signal Steady on DS2 will be on or blinking when the or blinking driver is receiving signal and off when there is no signal.
Page 78 Reference Drawings: Exploded Front View; Single Panel Module ..Drawing B-126111 Exploded Rear View; Single Panel Module ... Drawing B-126112 Component Locations; 832/848 Red/Amb LED, TNMC, G4 ......Drawing A-257029 Drawing A-257029 indicates the location of the TNMC controller for each of the TNMC models. Figure 18 below illustrates a typical TNMC layout.
Page 79: Modules And Drivers
4. Remove all power and signal connections from the board. Release “locked” connectors by squeezing together the tabs, and then carefully pulling them from the jack. Label the cables, indicating which cable was removed from which connector; the labeling will be helpful when you replace the board.
Page 80: Power Supplies
Drawings B-126111 and B-126112 illustrate the various module components. Individual components such as louvers can be removed for service, but Daktronics recommends that the module be kept intact and that the entire assembly be sent in for repair or replacement.
Page 81: Weatherstripping
4. Follow these steps in reverse order to install a new power supply. Weatherstripping To ensure that the display is waterproof, weatherstripping has been installed around the entire display and around each module. It is important that the weatherstripping is attached properly at all times, or water may leak into the display and damage the components.
Page 82: Initialization Information At Startup
Symptom/Condition Possible Cause/Remedy working. Replace the power supply assembly on the first module that is not working. Replace the ribbon cable. One row of modules does not work Replace the first module. or is garbled. Replace the controller. A group of modules that share the Replace the power supply assembly.
Page 83 Red LED TNMC, 848 0A-1192-3166 To prevent theft, Daktronics recommends purchasing a lockable cabinet to store manuals and replacement and spare parts. Refer to Section 8.9 for information on the Daktronics Exchange and Repair and Return programs. TNMC Maintenance 9-11...
Page 85: Scoreboard Options
Section 10: Scoreboard Options The following options are available for the Daktronics single-section scoreboards to make them more adaptable to individual scoring and timing needs: Team name caption kits for certain models Trumpet horn for football and soccer Radio control Portable power pack 10.1 Changeable Team Name Captions...
Page 86: 10.2 Trumpet Horn
2118, MS2918, SO- 1424, SO-1624, SO- 1830L, SO-1930, SO- 2014, SO-2030 10.3 Radio Control Radio control is an option with all Daktronics outdoor LED scoreboards, the system providing scoreboard control via a 2.4 GHz, extra-high frequency FM signal. 10-2 Scoreboard Options...
Page 87: 10.4 Portable Power Pack
The receiver plugs into the power terminal block in the driver/power enclosure. For additional information about this option, contact your Daktronics representative; for complete information on radio communications, refer to the All Sport 5000 Series control console Operation Manual ED-11976.
Page 89: Appendix A: Reference Drawings
Installation Specifications, MS-2918..........Drawing A-172188 Schematic; Gen III, OD LED, 3 Drvr Display ........Drawing A-179541 Component Locations, BA-1518-11/-21, G3 ........Drawing A-179745 Schematic; Gen III, OD LED, 1 Drv w/TNMC ........Drawing A-179790 Component Locations, BA-1524-11/-21, G3 ........Drawing A-179869 Schematic;...
Page 90: Component Locations; Ba-1518-11/-21, G3
Component Locations; BA-3724-11/-21, G3 ........Drawing A-228330 Component Locations: BA-3724-11/-21 w/TNMC, G3 ....Drawing A-229073 Component Locations; BA-1524-11/-21, G3 ........Drawing A-229211 Component Locations; BA-1518-11/-21, G3 ........Drawing A-229343 Component Locations; BA-2020-11/-21, G3 ........Drawing A-234140 Component Locations; MS-2009-11/-21, G3 ........Drawing A-234590 Component Locations;...
Page 91 B Drawings Exploded Front, Module ..............Drawing B-126111 Exploded Rear, Module ..............Drawing B-126112 Digit Assemblies; Gen III LED Digits ..........Drawing B-177679 Schematic, Baseball W/S.O.P. GEN IV, Optional TNMC ....Drawing B-204725 F.Assy; LED 12V DC Horn Mounting ..........Drawing B-242731 Schematic;...
Page 199 Appendix B: Eyebolts Eyebolts ......................ED-7244 Eyebolts...
Page 200 Eyebolts Almost every display that leaves Daktronics is equipped with eyebolts for lifting the display. There are two standard sizes of eyebolts: ½″ and ⅝″. Load Increase Factor: The load increases as the lift angle (θ) decreases. The allowable load on the eyebolts also decreases with the lift angle due the bending stress on the eyebolts.
Page 201 F. Eyebolts should never be painted or otherwise coated when used for lifting. Such coatings may cover potential flaws in the eyebolt. G. To attain the safe working loads listed for regular eyebolts, 90% of the thread length must be engaged. Copyright © 1996-2001 ED-7244 Daktronics, Inc. Rev. 4 – 14 March 2001...
Page 202 Appendix C...
Page 203 WARRANTY AND LIMITATION OF LIABILITY This Warranty and Limitation of Liability (the “Warranty”) sets forth the warranty provided by Daktronics with respect to the Equipment. By accepting delivery of the Equipment, Purchaser agrees to be bound by and accept these terms and conditions. All defined terms within the Warranty shall have the same meaning and definition as provided elsewhere in the Agreement.
Page 204 In no event shall Daktronics be liable to Purchaser or any other party for loss, damage, or injury of any kind or nature arising out of or in connection with this Warranty in excess of the purchase price of the Equipment actually delivered to and paid for by the Purchaser.
