Page 1 BA-1518 FB-2025 BA-1524 FB-2026 BA-2013 FB-2027 BA-3718 FB-3010 BA-3724 MS-2009 FB-2018 MS-2918 FB-2019 SO-2011 FB-2020 SO-2018 FB-2021 SO-2019 FB-2022 SO-2021 FB-2023 SO-2022 FB-2024 SO-2023 *Discontinued 201 Daktronics Drive PO Box 5128 Brookings, SD 57006-5128 Tel: 1-800-DAKTRONICS (1-800-325-8766) Fax: 605-697-4700 www.daktronics.com...
Page 3 – graphic, electronic, or mechanical, including photocopying, taping, or information storage and retrieval systems – without written permission of the publisher. ® ® All Sport and PanaView are trademarks of Daktronics, Inc. Other trademarks used in this manual are the property of their respective owners.
Page 5: Table Of Contents
Table of Contents Section 1: Introduction ..........................1 Resources ..........................1 Daktronics Nomenclature ...................... 2 Model Number ........................3 Scoreboard Controllers ......................3 Product Safety Approval......................3 Section 2: Specifications .......................... 5 Section 3: Mechanical Installation ...................... 11 Footings & Beams ........................11 Lifting the Scoreboard ......................
Page 6 6.10 Replacement Parts List ......................47 For Displays Built Before September 2009 ..............48 Section 7: Daktronics Exchange and Repair & Return Programs ..........49 Exchange Program ........................ 49 Before Contacting Daktronics ..................49 Repair & Return Program ....................50 Shipping Address ......................
Page 7: Introduction
Figure 1: Daktronics Drawing Label Reference Drawing: System Riser Diagram ................Drawing C-325405 Daktronics identifies manuals by the DD or ED number located on the cover page of each manual. For example, this manual would be referred to as ED-17610. Introduction...
Page 8: Daktronics Nomenclature
Power or signal jack Power or signal plug for the opposite jack Following the Replacement Parts List is the Daktronics Exchange Policy and the Repair & Return Program. Refer to these instructions if replacing or repairing any display component. Introduction...
Page 9: Model Number
Model Number Daktronics scoreboards are differentiated by their model numbers and two-letter prefixes for each sport. Most Daktronics scoreboards also carry a two-number suffix that refers to the type of power supply and digit color. Refer to the following tables:...
Page 11: Specifications
Section 2: Specifications The chart on the following pages details all of the mechanical specifications, circuit specifications and power requirements for each display in this manual. Models are listed in alphanumeric order. Notes: 1) All displays require a 120 V AC, 15 A circuit; 240 V AC power also available 2) TNMC and electronic caption LEDs are typically the same color as the LED digits on the scoreboard.
Page 12 Model & Number of Dimensions: Weight Watts Amps Driver # Options Sections Height, Width, Depth 120 / 240 V AC & Address BA-3724 4 Total H 9'-4", W 36'-0", D 6" 840 lb 900 W 7.5 A / 3.75 A (2845 mm, 10973 mm, 152 mm) (382 kg) Top 2...
Page 13 1500 W 12.5 A Captions (362 kg) (120 V AC only) (Top & Bottom) FB-2025 2 Total H 8'-0", W 32'-0", D 6" 780 lb 600 W 5 A / 2.5 A (2438 mm, 9754 mm, 152 mm) (353 kg) Top &...
Page 14 Model & Number of Dimensions: Weight Watts Amps Driver # Options Sections Height, Width, Depth 120 / 240 V AC & Address w/TNMC (same) (same) 1060 lb 900 W 7.5 A / 3.75 A TNMC (481 kg) w/TNMC + (same) (same) 1300 lb 1200 W...
Page 15 Model & Number of Dimensions: Weight Watts Amps Driver # Options Sections Height, Width, Depth 120 / 240 V AC & Address SO-2018 2 Total H 8'-0", W 18'-0", D 6" 565 lb 600 W 5 A / 2.5 A (2438 mm, 5486 mm, 152 mm) (256 kg) SO-2019...
Page 17: Mechanical Installation
" shoulder-type eyebolts mounted to a " aluminum plate or steel nut plate. Daktronics strongly recommends using a spreader bar, or lifting bar, to lift the display. Spreader bars ensure the force on the eyebolts remains straight up, minimizing lifting stress. Mechanical Installation...
Page 18 Figure 5: Eyebolt Plane Load plane of the eyebolt as shown in Figure 5. Note: Daktronics assumes no liability for damages resulting from incorrect setup or lifting methods. Eyebolts are intended for lifting only. Do not attempt to permanently support the display by the eyebolts.
Page 19: Scoreboard Mounting
Scoreboard Mounting Mounting hardware includes inner and outer mounting clamps; clip angles; -13 x 15" threaded rods; -16 x 2" bolts, hex nuts and lock washers; and " square nuts, hex nuts, and lock washers. Refer to Figure 6 or Drawing A-308051 in Appendix A.
Page 20: Scoreboard Mounting Using Vertical Spacers
Note: Some users install devices to protect the scoreboard from projectiles. Scoreboard protection devices not provided by Daktronics must be approved by Daktronics prior to installation. Failure to follow this approval procedure will void the scoreboard warranty.
Page 21: Ad Panel Mounting
Ad Panel Mounting The installation uses C-channels; clip angles; -13" threaded rods; and " square nuts, hex nuts, lock washers, and optional spacers. Refer to Figure 9 and Drawing A-52187 in Appendix A. Figure 9: Ad Panel Mounting with C-channel, Side View Mount the ad panel(s) as follows: Use the width of the beam to determine which hole combination to use for the bolts.
Page 23: Electrical Installation
It is the responsibility of the electrical contractor to ensure that all electrical work meets or exceeds local and national codes. Daktronics engineering staff must approve all changes or the warranty will be void. Installation Overview The diagram shown in Figure 10 illustrates a typical wired setup between a multi-section outdoor scoreboard and controller.
Page 24: Power
The diagram shown in Figure 11 illustrates a typical wireless setup between a multi-section outdoor scoreboard and controller. Daktronics part numbers are shown in parentheses. Figure 11: Wireless Installation Power Correct power installation is imperative for proper display operation. The subsections that follow give details of display power installation.
Page 25: Connection
Daktronics recommends a resistance-to-ground of 10 ohms or less. The electrical contractor performing the electrical installation can verify ground resistance. Daktronics Sales and Service personnel can also provide this service. The display system must be earth-ground. The material for an earth-ground electrode differs from region to region and may vary according to conditions present at the site.
Page 26: Power-On Self-Test (Post)
Figure 13: Driver Enclosure & Power Terminal Block Note: If a power receptacle is needed to operate the control console at the scoreboard for troubleshooting, Daktronics recommends that an installation electrician provides a 120 V outlet close to the disconnect box specifically for this purpose.
Page 27: Signal Connection
(silver) wire to the SHIELD Figure 15: Signal Surge Arrestor Card terminal. For signal cable, Daktronics recommends, as a minimum, single-pair, shielded cable, 22 AWG (part number W-1077). Two-pair shielded cable (part number W-1234) is preferred. Fiber Optic Another common signal communication method is fiber optic cabling.
Page 28: Lightning Protection
On the upper section, open the appropriate access panel to locate the bundle of interconnect cable coming from the driver. Note: Additional panels may be opened for easier access when routing the cable. Route the interconnect cable through the hole in the bottom of the upper cabinet through the hole in the top of the lower cabinet, and plug it into the driver.
Page 29: Scoreboard Troubleshooting
If a problem occurs that is not listed or that cannot be resolved using the solutions in the following table, contact Daktronics using the information provided in Section 7. Problem...
Page 30 Problem Possible Cause Solution/Items to Check Check that the green POWER and amber RADIO IN RANGE indicators on the radio receiver in the scoreboard light up when the control console is powered on (see Section 5.9). Keep the console between 20 to 1500 feet from the scoreboard.
Page 31 Problem Possible Cause Solution/Items to Check Verify the connector on the back of Bad connection the digit circuit board is secure (see Section 5.3). Scoreboard works, but some Swap the digit/driver with one known LEDs do not light or they to work correctly to verify the blink Bad digit or driver...
Page 32: Component Locations
Component Locations Component location varies with each scoreboard model. Refer to the component location drawings in Appendix A. Drivers and power and signal components are typically mounted inside the scoreboard behind a digit or access panel. There are several ways to locate the access panels: Power Warning Label Look for a power warning label toward the bottom of the access panel (Figure 12).
Page 33: Replacing Digits
Replacing Digits LEDs are embedded in a circuit board that is mounted to the back of the digit panel, as shown in Figure 19. Do not attempt to remove individual LEDs. In the case of a malfunctioning LED or digit segment, replace the entire digit circuit board. Figure 19: Digit Assembly To replace a digit circuit board: Open the digit panel as described in Section 5.3.
Page 34: Replacing Digit Segments
Replacing Digit Segments Larger digits (24"/30") are constructed with individual circuit board segments. As with smaller digits, the digit segment circuit boards are mounted to the back of the digit panel (Figure 20). It may be possible to make repairs by removing just the defective segment.
Page 35: Led Drivers
LED Drivers The LED drivers perform the task of switching digits on and off within the scoreboard. LED drivers are located inside of a driver enclosure. Refer to Figure 22 to view the location and components of a driver enclosure. Figure 22: Driver Enclosure Location &...
Page 36: Replacing A Driver
When troubleshooting driver problems, three LEDs labeled DS1, DS2, and DS3 in Figure 23, provide the following diagnostic information: Color Function Operation Summary Green Power Steady on DS1 will be on and steady to indicate the driver has power. Signal RX Steady on DS2 will be on or blinking when the or blinking...
Page 37: Setting The Driver Address
Carefully lift the driver from the display and place it on a clean, flat surface. Position a new driver over the screws and tighten the nuts. Reconnect all power/signal connectors. Note: The connectors are keyed and will attach in one way only. Do not attempt to force the connections.
Page 38: Replacing A Power Supply
Attach the circuit board to the new power supply and secure both to the mounting plate. Note: If replacing the 1000 W power supply (Daktronics part # A-1856R) does not seem to resolve the problem, try replacing its circuit board (part # 0P-1337-2000).
Page 39: Radio Interference
For more information, refer to the Gen V Radio Installation Manual (ED-13831), available online at www.daktronics.com/manuals. To locate the radio receiver, look for the antenna sticking out the front of the scoreboard (Figure 27).
Page 40: 5.10 Trumpet Horns
16 Column Driver (x 2) Model 120/240 V & TNMC White Digits & TNMC FB-2018 SO-2018 FB-2019 SO-2019 B-298205 FB-2020 FB-2021 SO-2021 FB-2022 SO-2022 B-298352 B-930720 FB-2023 SO-2023 FB-2024 FB-2025 B-576754 FB-2026 FB-2027 FB-3010 B-315137 MS-2918 SO-2011 B-876548 MS-2009 B-1007768 Scoreboard Troubleshooting...
Page 41: 5.13 Replacement Parts
16 Column Driver (x 3) w/ SOP & TOD Model 120/240 V & TNMC B-204725 BA-2013 5.13 Replacement Parts Refer to the following table for common Daktronics scoreboard replacement parts: Description Location Daktronics Part # J-Box, " phone, Indoor Signal...
Page 42 " phone Signal P-1003 Signal cord; " phone 20' Signal W-1236 Signal cord; " phone 50' Signal W-1237 Signal cord; " phone 30' Signal W-1238 See Section 7 for information on Daktronics Exchange and Repair and Return program. Scoreboard Troubleshooting...
Page 43: Tnmc & Electronic Caption Troubleshooting & Maintenance
Section 6: TNMC & Electronic Caption Troubleshooting & Maintenance IMPORTANT NOTES: 1. Always disconnect scoreboard power before doing any repair/maintenance work on the message centers. 2. Permit only qualified service personnel to access internal display electronics. Disconnect power when not using the scoreboard. Display Overview Team Name Message Centers (TNMCs) are programmable LED displays that allow users to show custom Home and Guest names or messages of ~15 characters on the scoreboard in...
Page 44: Initialization Information At Startup
If a problem occurs that is not listed or that cannot be resolved using the solutions in the following table, contact Daktronics using the information provided in Section 7. Symptom/Condition Possible Remedy One or more LEDs on a single Check/replace the ribbon cables on the module.
Page 45: Power & Signal Summary
Power & Signal Summary Reference Drawings: Schematic, Amber TNMC, GEN IV ............Drawing A-252645 Schematic, Red TNMC, GEN IV ............. Drawing A-252681 Schematic; 832 / 848 / 864 Red TNMC GEN IV, 240V ......Drawing A-294858 Schematic; 832 / 848 / 864 Amber GEN IV, 240V ........Drawing A-294919 Schematic, OD, 3500, 34mm TNMC, Red/Amb ........
Page 46: Component Locations & Access
Component Locations & Access Reference Drawings: Component Locations; 832/848/864 Red/Amb LED, TNMC, G4 .... Drawing A-257029 Component Loc.; 34mm Red/Amb/Wht LED TNMC G4 ......Drawing B-975100 Component Loc.; 46mm Red/Amb/Wht LED TNMC G4 ......Drawing B-975635 Figure 31 illustrates the component locations of an 8x48-34mm display with all modules removed.
Page 47: For Displays Built Before September 2009
Figure 34: Discontinued 8x48-46mm Display with Modules Removed Standard Daktronics outdoor LED scoreboards are typically front-accessible, but some models may be ordered with rear service access. For that reason, TNMCs and electronic captions have been designed so that they may be accessed from both the front and rear.
Page 48: Rear Access
Rear Access To access the internal components from the rear, remove the appropriate rear-access panel from the display cabinet by loosening all four of the screws. Slide the access panel sideways to the larger part of the keyhole and carefully lift it off the display cabinet.
Page 49: For Displays Built Before September 2009
Figure 37: 4 Column MCAST Driver For Displays Built Before September 2009 The display driver receives signal from the control console via a signal surge arrestor card and sends data to the modules. Refer to Section 6.4 for more information on signal routing. The driver itself is detailed in Drawing A-166216 in Appendix A.
Page 50: Diagnostic Leds
Each module assembly is made up of a module housing (containing LEDs and the driver) and a louver assembly. Individual components such as louvers can be removed for service, but Daktronics recommends that the module be kept intact and that the entire assembly be sent in for repair or replacement.
Page 51: Weather-Stripping
To replace a module from the rear: Follow the steps in the Rear Access method described in Section 6.5. Use a 1/8" hex wrench or " nut driver to loosen the latch fastener assembly (Figure 39). Turn each fastener a quarter-turn clockwise (if using a nut driver, turn the top latch counter-clockwise and the bottom latch clockwise).
Page 52: Power Supplies
Power Supplies Power supply configurations will vary depending on the number and/or color of modules. Replacing a Power Supply To remove a power supply from the display: Access the internal components using the appropriate Front/Rear Access method described in Section 6.5. Disconnect all the wires connected to the power supply.
Page 53: 6.10 Replacement Parts List
6.10 Replacement Parts List The following tables contain TNMC components that may have to be replaced. Many of the components within the display itself have attached part number labels. Part Description Part Number Module; 8X8-34, Red 0A-1208-5005 Module; 8X8-34, Red (Sep 2009 – Nov 2010 only) 0A-1208-5002 Module;...
Page 54: For Displays Built Before September 2009
Red 8x8 34mm Module Assembly 0A-1208-4004 Amber 8x8 34mm Module Assembly 0A-1208-4005 Red 8x8 46mm Module Assembly 0A-1342-4004 Amber 8x8 46mm Module Assembly 0A-1342-4005 See Section 7 for information on Daktronics Exchange and Repair and Return program. TNMC & Electronic Caption Troubleshooting & Maintenance...
Page 55: Daktronics Exchange And Repair & Return Programs
The Daktronics Exchange Program is a service for quickly replacing key components in need of repair. If a component fails, Daktronics sends a replacement part to the customer who, in turn, returns the failed component to Daktronics. This decreases equipment downtime.
Page 56: Repair & Return Program
Repair & Return Program For items not subject to exchange, Daktronics offers a Repair & Return Program. To send a part for repair, follow these steps: Call or fax Daktronics Customer Service: Refer to the appropriate market phone number in the chart on the previous page.
Page 57: Scoreboard Options
(240 V Scoreboards Only) Radio Control Radio control is an option for all Daktronics outdoor LED scoreboards. The system provides scoreboard control via a 2.4 GHz, extra-high frequency FM signal. The radio transmitter and receiver are not standard. This setup requires a control console equipped with radio output as well as a radio receiver plugged into the power terminal block in the driver/power enclosure and mounted internally to the front panel of the scoreboard.
Page 58: Time Outs Left (T.o.l) Digits
Time Outs Left (T.O.L) Digits Certain scoreboards have the option to add a time outs left (TOL) digit for both the home and guest teams. These digits are installed by simply unscrewing the blank face panel, connecting and securing the digit panel, and manually applying the “T.O.L.” vinyl caption. The following scoreboard models in this manual have optional T.O.L.
Page 59: Appendix A: Reference Drawings
Appendix A: Reference Drawings Segmentation, 7 Segment Bar Digit ................Drawing A-38532 Ad Panel Mounting ....................... Drawing A-52187 Address Table, 1 Through 128 .................. Drawing A-115078 Address Table, 129 Through 255 ................Drawing A-115079 Installation Specifications, BA-3724 ................. Drawing A-126445 Schematic, Multipurpose LED DRVR ................
Page 60 Schematic; FB/SO-20XX 32' GEN IV SCBDS ............Drawing B-576754 Component Location; FB-2024-11/-21, Vinyl, G4 ............Drawing A-580578 Component Location; FB-2025-11/-21, Vinyl, G4 ............Drawing A-583033 Component Location; FB-2026-11/-21, Vinyl G4 ............Drawing A-584382 Component Locations; MS-2009-11/-21 W/ TNMC ........... Drawing A-745603 Schematic;...
Page 67 DAKTRONICS, INC. DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESSED CORRECTED S1 PINOUT WRITTEN CONSENT OF DAKTRONICS, INC. DATE: COPYRIGHT 2013 DAKTRONICS, INC. 01 FEB 13 OUTDOOR LED SCOREBOARDS UPDATE DRIVER J-27 FOR CORRECT PIN OUT...
Page 73 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESS WRITTEN CONSENT OF DAKTRONICS, INC. OR ITS WHOLLY OWNED SUBSIDIARIES. PER EC-21432, REPLACED A-1633 W/ A-2259 COPYRIGHT 2016 DAKTRONICS, INC. (USA)
Page 86 DAKTRO I N CS...
Page 131 Appendix B: Daktronics Warranty and Limitation of Liability Daktronics Warranty and Limitation of Liability...
Page 133 WARRANTY AND LIMITATION OF LIABILITY This Warranty and Limitation of Liability (the “Warranty”) sets forth the warranty provided by Daktronics with respect to the Equipment. By accepting delivery of the Equipment, Purchaser agrees to be bound by and accept these terms and conditions. All defined terms within the Warranty shall have the same meaning and definition as provided elsewhere in the Agreement.
Page 134 In no event shall Daktronics be liable to Purchaser or any other party for loss, damage, or injury of any kind or nature arising out of or in connection with this Warranty in excess of the purchase price of the Equipment actually delivered to and paid for by the Purchaser.
