Supero SuperServer 5011H User Manual

High-end single processor 1u rackmount server
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
S
S
UPER
USER'S MANUAL
UPER
S
ERVER
SuperServer 5011H
SuperServer 5011E
Revision 1.0a
5011H/5011E
S
UPERMICR
S
UPERMICR
®
R
R

Advertisement

Table of Contents
loading

Related Manuals for Supero SuperServer 5011H

Summary of Contents for Supero SuperServer 5011H

  • Page 1 UPER UPER ERVER SuperServer 5011H SuperServer 5011E USER’S MANUAL 5011H/5011E Revision 1.0a ® UPERMICR UPERMICR...
  • Page 2 The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product. Unless you request and receive written permission from SUPER MICRO COMPUTER, you may not copy any part of this document.

  • Page 3: Preface

    The SuperServer 5011H/5011E is a high-end single processor 1U rackmount server based on the SC810 1U rackmount server chassis and either the Super P3TSSR (for the 5011H) or the P3TSSE (for the 5011E) mainboard. The P3TSSR/P3TSSE mainboard supports single Intel 500 MHz-1.26+ GHz processors and Celeron...
  • Page 4 You should thoroughly familiarize yourself with this chapter for a general overview of safety precautions that should be followed when installing and servicing the SuperServer 5011H/5011E. Chapter 5: Advanced Motherboard Setup Chapter 5 provides detailed information on the P3TSSR and P3TSSE motherboards, including the locations and functions of connectors, head- ers, jumpers, DIP switches and IRQs.
  • Page 5 Preface...

  • Page 6: Table Of Contents

    Choosing a Setup Location ... 2-2 Rack Precautions ... 2-2 Server Precautions ... 2-2 Installing the SuperServer 5011H/5011E into a Rack ... 2-3 Identifying the Sections of the Rack Rails ... 2-3 Installing the Chassis Rails ... 2-4 Installing the Rack Rails ... 2-4 Installing the Server into the Rack ...
  • Page 7 Power ... 3-3 SCSI Drive Carrier LEDs (5011H) ... 3-3 Power Supply Switch ... 3-3 Motherboard LEDs ... 3-3 Chapter 4: System Safety Electrical Safety Precautions ... 4-1 General Safety Precautions ... 4-2 ESD Precautions ... 4-3 Chapter 5: Advanced Motherboard Setup Handling the P3TSSR/P3TSSE Motherboard ...
  • Page 8 CMOS Clear ... 5-21 Speaker Enable/Disable ... 5-21 LAN1/LAN2 Enable/Disable ... 5-21 Keyboard Wake-Up ... 5-21 LVD Channel A SCSI Termination Enable/Disable(5011H) ... 5-22 LVD Channel B SCSI Termination Enable/Disable(5011H) ... 5-22 SCSI Enable/Disable(5011H) ... 5-22 Watchdog Reset ... 5-22 5-10 Floppy/Hard Disk and SCSI Connections ...
  • Page 9 IDE Configuration ... 7-8 Floppy Configuration ... 7-11 Boot Settings Configuration ... 7-12 Event Log Configuration ... 7-15 Chipset Setup ... 7-16 GMCH Configuration ... 7-16 ICH2 Configuration ... 7-20 PCI PnP Setup ... 7-23 Power Setup ... 7-27 Boot Setup ... 7-33 Boot Device Priority ...
  • Page 10 5011H/5011E UPER ERVER User's Manual NOTES...

  • Page 11: Chapter 1: Introduction To The Superserver 5011H/5011E

    SC810 1U rackmount chassis and the P3TSSR (for 5011H) or P3TSSE (for 5011E) single 370-pin Pentium III FCPGA or Celeron FCPGA/PPGA processor mainboard. Please refer to our web site for infor- mation on operating systems that have been certified for use with the SuperServer 5011H/5011E.

  • Page 12: Server Chassis Features

    When configured as a SuperSever 5011H/5011E, the SC810 chassis in- cludes a 200W power supply. SCSI Subsystem (5011H only) The SCSI subsystem on the 5011H supports two 80-pin SCA Ultra160 SCSI hard drives. (Standard 1" drives are supported. SCA = Single Connection Attachment.) The SCSI drives are connected to an SCA backplane that provides power, bus termination and configuration settings.
  • Page 13 The SC810 is a 1U rackmount chassis. Its I/O panel provides one mother- board expansion slot, one COM port (another is internal), two USB ports (5011H only), PS/2 mouse and keyboard ports, a graphics port and two Ethernet ports. (See Figure 1-1.) Figure 1-1.

  • Page 14: Mainboard Features

    UPER ERVER 5011H/5011E Manual Mainboard Features At the heart of the SuperServer 5010H/5010E lies the P3TSSR/P3TSSE, a single processor motherboard designed to provide maximum performance. Below are the main features of the P3TSSR/P3TSSE. Chipset Overview Intel’s 815E chipset is made up of three main components: the Graphics and Memory Controller Hub (GMCH), the I/O Controller Hub (ICH) and the Firm- ware Hub (FWH).
  • Page 15 32-bit PCI cards. Network Interface Controllers (NIC) The P3TSSR/P3TSSE supports two Network Interface controllers (NIC) based on Intel's 82559 and 82562 chips. (For the 5011H server, which is based on the P3TSSR mainboard, two 82559 Ethernet chips are included in the system.)
  • Page 16 UPER ERVER 5011H/5011E Manual Onboard Controllers/Ports An onboard IDE controller supports one floppy drive and up to four UDMA/ 100 hard drives or ATAPI devices. Onboard I/O ports include one COM port, two USB ports, PS/2 mouse and keyboard ports, a video (Graphics) port and two LAN (NIC) ports which back each other up in case one port loses connection.

  • Page 17: Contacting Supermicro

    Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 E-mail: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web site: www.supermicro.com European Office Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML,...
  • Page 18 UPER ERVER 5011H/5011E Manual NOTES...

  • Page 19: Chapter 2: Server Installation

    Decide on a suitable location for the rack unit that will hold the SuperServer 5011H/5011E. It should be situated in a clean, dust-free area that is well ventilated.

  • Page 20: Choosing A Setup Location

    Allow the power supply units and hot plug SCSI drives (5011H) to cool before touching them. Always keep the rack's front door and all panels and components on the servers closed when not servicing to maintain proper cooling.

  • Page 21: Installing The Superserver 5011H/5011E Into A Rack

    Rack This section provides information on installing the SuperServer 5011H/5011E into a rack unit. If the 5011H/5011E has already been mounted into a rack, you can skip ahead to Sections 2-5 and 2-6. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly.

  • Page 22: Installing The Chassis Rails

    Manual Installing the Chassis Rails Position the fixed chassis rail sections you just removed along the side of the 5011H/5011E chassis making sure the five screw holes line up. Note that these two rails are left/right specific. Screw the rail securely to the side of the chassis (see Figure 2-2).

  • Page 23: Installing The Server Into The Rack

    Chapter 2: Server Installation assembly securely to the rack using the brackets provided. Attach the other assembly to the other side of the rack, making sure that both are at the exact same height and with the rail guides facing inward. Installing the Server into the Rack You should now have rails attached to both the chassis and the rack unit.

  • Page 24: Installing The Server Into A Telco Rack

    Manual Installing the Server into a Telco Rack If you are installing the SuperServer 5011H/5011E into a Telco type rack, follow the directions given on the previous pages for rack installation. The only difference in the installation procedure will be the positioning of the rack brackets to the rack.

  • Page 25: Checking The Motherboard Setup

    Checking the Motherboard Setup After you install the 5011H/5011E in the rack, you will need to open the unit to make sure the motherboard is properly installed and all the connections have been made. 1. Accessing the inside of the 5011H/5011E (see Figure 2-5a/2-5b) First, release the retention screws that secure the unit to the rack.
  • Page 26 5011H/5011E UPER ERVER Manual Figure 2-5a. Accessing the Inside of the SuperServer 5011H (with SCSI installed) Top Chassis Cover (Removed) Cover Release Buttons PCI Riser Card Retention Rail Cover Recess P3TSSR Motherboard Blower Fan Power Supply CPU Heatsink SCSI Drive...
  • Page 27 Chapter 2: Server Installation Figure 2-5b. Accessing the Inside of the SuperServer 5011E (with IDE installed) Blower Fan IDE Drive System Memory Control Panel CD-ROM Drive Floppy Drive 5011E...

  • Page 28: Checking The Drive Bay Setup

    ERVER Checking the Drive Bay Setup Next, you should check to make sure the peripheral drives and the SCSI drives (5011H only) and SCA backplane have been properly installed and all connections have been made. 1. Accessing the drive bays All drives can be accessed from the front of the server.

  • Page 29: Chapter 3: System Interface

    Overview There are several LEDs on the control panel as well as others on the SCSI drive carriers and the motherboard to keep you constantly informed of the overall status of the system as well as the activity and health of specific components.

  • Page 30: Control Panel Leds

    Indicates network activity on LAN2 when flashing. NIC1 NIC1: Indicates network activity on LAN1 when flashing. HDD: Indicates IDE channel activity. 5011E, this light indicates CD-ROM drive activity when flashing. Manual You should also check to make sure On the SuperServer 5011H/ The air seals are...

  • Page 31: Power

    Red: A SAF-TE compliant backplane is needed to activate the red LED to indicate a drive failure. (A SAF-TE compliant SCSI backplane is optional on the 5011H.) If one of the SCSI drives fail, you should be notified by your system management software. Please refer to Section 6-4 for instructions on replacing failed SCSI drives.
  • Page 32 UPER ERVER Manual DA1 (SCSI LED) Indicator (5011H only) There is one SCSI LED Indicator (DA1) on the motherboard. When illumi- nated, it indicates that SCSI is active. This SCSI LED (DA1) is located near Ultra III LVD Channel A (JA1) on the P3TSSR mainboard.

  • Page 33: Chapter 4: System Safety

    Electrical Safety Precautions Basic electrical safety precautions should be followed to protect yourself from harm and the SuperServer 5011H/5011E from damage: Be aware of the locations of the power on/off switch on the chassis as well as the room's emergency power-off switch, disconnection switch or electrical outlet.

  • Page 34: General Safety Precautions

    General Safety Precautions Follow these rules to ensure general safety: Keep the area around the SuperServer 5011H/5011E clean and free of clutter. The SuperServer 5011H/5011E weighs approx. 26 lbs. (11.8 kg.) when fully loaded. When lifting the system, two people at either end should lift slowly with their feet spread out to distribute the weight.

  • Page 35: Esd Precautions

    ESD Precautions Electrostatic discharge (ESD) is generated by two objects with different electrical charges coming into contact with each other. An electrical discharge is created to neutralize this difference, which can damage electronic components and printed circuit boards. measures are generally sufficient to neutralize this difference before contact is made to protect your equipment from ESD: Use a grounded wrist strap designed to prevent static discharge.
  • Page 36 5011H/5011E UPER ERVER Manual NOTES...

  • Page 37: Chapter 5: Advanced Motherboard Setup

    Advanced Motherboard Setup This chapter covers the steps required to install the P3TSSR/P3TSSE moth- erboard into the SC810 chassis, connect the data and power cables and install add-on cards. described. A layout and quick reference chart are on pages 5-10 through 5-13.

  • Page 38: Motherboard Installation

    Motherboard Installation This section explains the first step of physically mounting the P3TSSR (5011H) or P3TSSE (5010E) into the SC810 chassis. Following the steps in the order given will eliminate the most common problems encountered in such an installation.

  • Page 39: Connecting Cables

    (See the layout on page 5-10 for connector locations.) IDE Device Cables (J18 and J19) Floppy Drive Cable (J26) SCSI Device Cables (JPA1, JPA2, JPA3) (5011H only) Control Panel Cable (JF1, see next page) Connecting Power Cables The P3TSSR/P3TSSE has a 20-pin primary power supply connector designated "ATX Power"...

  • Page 40: Connecting The Control Panel

    5011H/5011E UPER ERVER Connecting the Control Panel JF1 contains header pins for various front control panel connectors. See Figure 5-1 for the pin locations of the various front control panel buttons and LED indicators. Please note that even and odd numbered pins are on opposite sides.

  • Page 41: I/O Ports

    I/O Ports The I/O ports are color coded in conformance with the PC 99 specification. See Figure 5-2 below for the colors and locations of the various I/O ports. Mouse (Green) COM1 Port Keyboard (Turquoise) (Purple) Ports (Black) Note: The COM2 port is a header on the motherboard, located behind the mouse/keyboard ports.
  • Page 42 ERVER Attaching heat sinks to the processors One passive heat sink has been included with your SuperServer 5011H/ 5011E. Secure the heat sink to the processor with a suitable thermal compound to best conduct the heat from the processor to the heat sink.

  • Page 43: Installing Memory

    Installing Memory CAUTION! Exercise extreme care when install- ing or removing DIMM modules to prevent any possible damage. Memory support The P3TSSR/P3TSSE has three 25-degree DIMMs that support 64MB/ 128MB/256MB/512 MB unbuffered SDRAM. PC133 and PC100 memory are both supported at their respective speeds. However, if three DIMM modules are installed, the memory will run at 100MHz even if PC133 memory is used (due to chipset limitations).

  • Page 44: Adding Pci Cards

    5011H/5011E UPER ERVER Adding PCI Cards 32-bit PCI slot The P3TSSR/P3TSSE has four 32-bit MHz 5V PCI slots available. A riser card designed specifically for using this slot in a 1U rackmount chassis is included with your system. This riser card allows an installed PCI card to sit at a 90 degree angle so it can fit inside the chassis.
  • Page 45 Figure 5-7. 5011H: P3TSSR Motherboard 5011E: P3TSSE Motherboard Chapter 5: Advanced Motherboard Setup Adding PCI Cards PCI Riser Card Memory Modules PCI Riser Card Memory Modules CPU Socket CPU Socket...
  • Page 46 5011H/5011E UPER ERVER Figure 5-8. Super P3TSSR Layout JPWAKE CPU FAN KB/Mouse USB0/1 COM 1 PIII FCPGA or Celeron Processor LAN 1 LAN 2 JP35 JP31 JPA2 Manual (not drawn to scale) 8.7" ATX POWER GMCH BATTERY AGP 4x PCI 1...
  • Page 47 P3TSSR Quick Reference (for 5011H) Jumpers Description JBT1 CMOS Clear JPA1 SCSI Channel A Termination JPA2 SCSI Channel B Termination JP11/12 Front Side Bus Speed JP31 LAN2 Enable/Disable JP34 SCSI Enable/Disable JP35 LAN1 Enable/Disable JP36 Speaker/Watchdog Enable JPWAKE Keyboard Wake-Up...
  • Page 48 5011H/5011E UPER ERVER Figure 5-9. Super P3TSSE Layout JPWAKE CPU FAN KB/Mouse USB0/1 COM 1 PIII FCPGA or Celeron Processor LAN 1 LAN 2 JP35 JP31 Manual (not drawn to scale) 8.7" ATX POWER GMCH BATTERY AGP 4x PCI 1...
  • Page 49 P3TSSE Quick Reference (for 5011E) Jumpers Description JBT1 CMOS Clear JP11/12 Front Side Bus Speed JP31 LAN2 Enable/Disable JP35 LAN1 Enable/Disable JP36 Speaker/Watchdog Enable JPWAKE Keyboard Wake-Up Connectors Description CH FAN 1 Chassis Fan Header COM1/COM2 COM1/COM2 Serial Port Connector CPU FAN CPU Fan Header Infrared Device Header...

  • Page 50: 5-8 Connector Definitions

    5011H/5011E UPER ERVER 5-8 Connector Definitions Power Supply Connector The primary power supply connec- tor on the P3TSSR/P3TSSE is des- ignated ATX POWER. This is a 20- pin connector. Attach an ATX power supply cable to J29 by aligning the tab on the connector.

  • Page 51: Reset

    Reset The Reset connection is located on pins 3 and 4 of JF1. This con- nector attaches to the Reset but- ton on the control panel, which al- lows you to reboot the system. Refer to the table on the right for pin definitions and Figure 5-1 for pin locations.

  • Page 52: Hdd Led

    3-pin header for the Power LED located at J50. (You only need to use connection - that on JF1 is de- signed for Supermicro chassis.) See the tables on the right for pin definitions and Figure 5-1 for pin locations.

  • Page 53: Fan Headers

    Fan Headers* There are several fan headers on the P3TSSR/P3TSSE that provide cooling for various components. In addition to one fan header for the processor (located near the ATX Power Supply), there are one overheat and two chassis fan headers located next to the DIMM modules.

  • Page 54: Atx Ps/2 Keyboard And Mouse Ports

    5011H/5011E UPER ERVER ATX PS/2 Keyboard and PS/2 Mouse Ports The ATX PS/2 keyboard and the PS/2 mouse are located on J30. See the table on the right for pin definitions. (The mouse port is above the keyboard port. See Fig- ure 5-8.)

  • Page 55: Wake-On-Lan

    Wake-On-LAN The Wake-On-LAN (WOL) header allows the system to be woken up upon receiving an appropriate sig- nal via the LAN. You must enable the LAN Wake-Up setting in BIOS to use this feature and have a LAN card with a Wake-on-LAN connector and cable.

  • Page 56: Jumper Settings

    5011H/5011E UPER ERVER Jumper Settings Explanation of Jumpers To modify the operation of the motherboard, jumpers can be used to choose between optional set- tings. Jumpers create shorts be- tween two pins to change the function of the connector. Pin 1 is identified with a square solder pad on the printed circuit board.

  • Page 57: Cmos Clear

    CMOS Clear Refer to the table on the right for setting JBT1 to clear CMOS. ways remove the AC power cord from the system before clearing CMOS. Speaker Enable/Disable JP32 allows you to enable or dis- able the onboard speaker. to the table on the right for jumper settings.

  • Page 58: Lvd Channel A Scsi Termination Enable/Disable(5011H)

    5011H/5011E UPER ERVER LVD Channel A SCSI Termination Enable/Disable (5011H only) Jumper JPA1 allows you to enable or disable termination for the LVD Channel A SCSI con- nector. The normal (default) position is open to enable SCSI termination. See the table on the right for jumper settings.

  • Page 59: 5-10 Floppy/Hard Disk And Scsi Connections

    5-10 Floppy/Hard Disk and SCSI Connections Be aware of the following when connecting the floppy and hard disk drive cables: • A red mark on a wire typically designates the location of pin 1. • A single floppy disk drive ribbon cable has 34 wires and two connectors to provide for two floppy disk drives.

  • Page 60: Ultra160 Scsi Connectors

    68-pin Ultra160 SCSI Connectors (JA1, JA2, JA3) Connector Contact N u m b e r Manual Ultra160 SCSI Connectors (5011H only) Refer to the table below for pin the definitions of the Ultra160 SCSI connectors located at JA1, JA2 and JA3.

  • Page 61: Chapter 6: Advanced Chassis Setup

    Advanced Chassis Setup This chapter covers the steps required to install components and perform maintenance on the SC810 chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the step that follows. Tools Required The only tool you will need to install components and perform maintainance is a Philips screwdriver.

  • Page 62: Control Panel

    5011H/5011E UPER ERVER Figure 6-1. 5011E Rack Unit Retention Screws (3 each side) 5011H Figure 6-2. 5011E 5011H Control Panel The control panel (located on the front of the chassis) must be connected to the JF1 connector on the motherboard to provide you with system control buttons and status indicators.

  • Page 63: System Fans

    System Fans One 10-cm blower fan provides all the cooling needed for the SuperServer 5011H/5011E. The chassis includes air seals under the blower fan and at the chassis cross section, which separates the drive bay area from the motherboard area of the chassis to promote better airflow.

  • Page 64: Drive Bay Installation/Removal

    SuperServer 5011H. CD-ROM/Floppy Disk Drive: For installing/removing the CD-ROM or floppy disk drive, you will need to gain access to the inside of the 5011H/5011E by removing the top cover of the chassis. Proceed to the "CD-ROM and Floppy Drive Installation" section later in this chapter for instructions.

  • Page 65: Scsi Drive Installation

    Secure the drive to the carrier with four screws, as shown in Figure 6-4. Figure 6-4. Mounting a SCSI Drive in a Carrier (5011H only) Use caution when working around the SCSI backplane. Do not touch the backplane with any metal objects and make sure no ribbon cables touch the backplane or obstruct the holes, which aid in proper airflow.
  • Page 66 (see Figure 6-5). Handle Release Button Figure 6-5. Important: are installed, both SCSI drive carriers must remain in the drive bays to maintain proper airflow. Manual Removing SCSI Drives (5011H) Regardless of how many SCSI hard drives...

  • Page 67: Ide Drive Installation

    SCSI Power Cables SCSI power cables should be routed so that they do not block the airflow through the chassis. There is a 4-pin connector for the power cables. SCA Backplane The SCSI drives plug into an SCA backplane that provides power, SCSI ID and bus termination.

  • Page 68: Cd-Rom And Floppy Drive Installation

    The top cover of the chassis must be opened to gain full access to the CD- ROM and floppy drive bays. The CD-ROM drive must have a "slim" profile to fit into the 5011H/5011E. First, release the retention screws that secure the unit to the rack. Grasp the two handles on either side and pull the unit straight out until it locks (you will hear a "click").

  • Page 69: Power Supply

    Power Supply The SuperServer 5011H/5011E has a single 200 watt power supply. This power supply has an auto-switching capability, which enables it to auto- matically sense and operate anywhere between 110v and 220v. on/off switch is located at the back of the power supply.
  • Page 70 5011H/5011E UPER ERVER Manual Figure 6-7. Chassis Rear View 5011E Power Supply I/O Ports (see Figure 1.1) PCI Slot 5011H External High Density SCSI Connector (5011H only) 6-10...

  • Page 71: Chapter 7: Bios

    Introduction This chapter describes the AMIBIOS for the 5011H/5011E. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily upgraded using a floppy disk-based program. Note: Due to periodic changes to BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 72: Bios Features

    UPERSERVER 5011H/5011E User's Manual BIOS Features • Supports Plug and Play V1.0A and DMI 2.3 • Supports Intel PCI (Peripheral Component Interconnect) (PME) local bus specification • Supports Advanced Power Management (APM) specification v 1.1 • Supports ACPI • Supports Flash ROM AMIBIOS supports the LS120 drive made by Matsushita-Kotobuki Electronics Industries Ltd.

  • Page 73: The Main Bios Setup Menu

    The Main BIOS Setup Menu Press the <Delete> key during the POST (Power On Self Test) to enter the Main Menu of the BIOS Setup Utility. All Main Setup options are described in this section. The Main BIOS Setup screeen is displayed below. Main Advanced Chipset PCIPnP Power Boot Security Exit AMIBIOS Version BIOS Build Date...

  • Page 74: Advanced Chipset Setup

    UPERSERVER 5011H/5011E User's Manual Advanced Chipset Setup Choose Advanced BIOS Setup from the AMIBIOS Setup Utility main menu with the Left/Right arrow keys. of the items in the left frame of the screen, such as SuperIO Configuration, to go to the sub screen for that item. Advanced BIOS Setup options are displayed by highlighting the option using the arrow keys.
  • Page 75 Chapter 7: AMIBIOS CPU Overheat Warning This option allows you to Enable or Disable a system overheat warning signal, used to notify you in the event of a dangerous rise in heat levels. CPU Overheat Warning This option allows you to specify the temperature threshold that, when exceeded, will trigger the overheat warning alarm.

  • Page 76: Super I/O Configuration

    UPERSERVER 5011H/5011E User's Manual Super I/O Configuration After selecting the settings for "Health Monitor Features", use the Up/Down arrow keys to select the "SuperIO Configuration" line. When the "SuperIO Configuration" line is highlighted, hit "ENTER" to display the submenu. Advanced...
  • Page 77 Serial Port2 Mode This option specifies Serial Port2 Mode. The settings for this item include Normal, IRDA1.6ms, IRDA311.6, ASKIR, ASKIR500, ASKIRDem, ASKIRD500. Parallel Port Address This option specifies the I/O address used by the parallel port. The settings for this item include Disabled, 378, 278 and 3BC. Select your setting and then press "Enter".

  • Page 78: Ide Configuration

    UPERSERVER 5011H/5011E User's Manual Power Loss Control This option determines how the system will react when power is reapplied after being lost unexpectedly. The settings are Always Off loses power unexpectedly, the computer system will keep power off until the power button is pressed), Always On (if the system loses power unex-...
  • Page 79 Chapter 7: AMIBIOS Type This option sets the type of device that the AMIBIOS attempts to boot from after AMIBIOS POST is completed. The settings include Not installed, Auto, CDROM and ARMD. The "Auto" setting allows BIOS to automatically detect the presence of the IDE controller.
  • Page 80 UPERSERVER 5011H/5011E User's Manual tect the DMA Mode. Select SWDMA0 through SWDMA2 to set single word DMA0 through DMA2. Select MWDMA0 through MWDMA2 to set Multi-word DMA0 through DMA2. Select UDMA0 trhough UDMA4 to set Ultra DMA0 through Ultra DMA4.

  • Page 81: Floppy Configuration

    Chapter 7: AMIBIOS Hard Disk Write Protect This item allows the user to prevent the hard disk from being overwritten. The options are Enabled or Disabled. Enabled allows the drive to be used normally; read, write and erase functions can all be performed. Disabled prevents the hard disk from being erased.

  • Page 82: Boot Settings Configuration

    UPERSERVER 5011H/5011E User's Manual Boot Settings Configuration Quick Boot This option allows the BIOS to skip certain tests that are normally performed on boot up. You can disable the option to speed up boot time. The settings are Disabled and Enabled.
  • Page 83 Chapter 7: AMIBIOS System Keyboard This option is to let the system know if a keyboard is Present or Absent. Primary Display This option specifies the type of monitor display you have installed on the system. The settings are Absent, VGA/EGA, Color 40 x 25, Color 80 x 25 and monochrome.
  • Page 84 This option allows the user to set the configurations for the devices listed below. The options for these devices are Disabled and Enabled. Onboard SCSI Option-ROM (5011H only) Use this option to either Enable or Disable the use of ROM for the onboard SCSI.

  • Page 85: Event Log Configuration

    Chapter 7: AMIBIOS Event Log Configuration Event Logging This option Enables or Disables the logging of events. You can use this screen to select options for the Event Log Configuration Settings. You can access sub screens to view the event log and mark all events as read. Use the up and down arrow keys to select an item, and the plus (+) and minus (-) keys to change the option setting.

  • Page 86: Chipset Setup

    UPERSERVER 5011H/5011E User's Manual Chipset Setup Choose Chipset Setup from the AMIBIOS Setup Utility main menu. The screen is shown below. All Chipset Setup options are described following the screen. You can use this screen to select options for the GHCH Configuration.
  • Page 87 Chapter 7: AMIBIOS Internal Graphics Mode Select This option selects the mode for the internal graphics mode. Settings in- clude Disabled, Enabled; 512 KB and Enabled; 1 MB. Enabled; 1MB: This option allows the Internal Graphic controller to allocate 1 MB of system memory for video display use.
  • Page 88 UPERSERVER 5011H/5011E User's Manual Init Display Cache Memory This option allows the Initial Display cache memory to be adjusted. The setting are Enabled and Disabled. Paging Mode Control This option allows the paging mode controls to be adjusted to either Close or Open.
  • Page 89 System Memory Frequency This option allows the system memory frequency to be adjusted. The set- tings are 100 MHz (for PC100 memory), 133 MHz (for PC133 memory) and Auto, which allows the system memory frequency to auto select itself SDRAM Refresh This option sets the refresh rate for the system memory.

  • Page 90: Ich2 Configuration

    UPERSERVER 5011H/5011E User's Manual ICH2 Configuration You can use this screen to select options for the ICH2 Configuration. Use the up and down arrow keys to select an item, and the plus (+) and minus (-) keys to change the option setting. The settings are described on the following pages.
  • Page 91 Chapter 7: AMIBIOS LPC 4Eh-4Fh Decode This option allows the LPC 4Eh-4Fh to be set. The settings are Disabled and Enabled. DMA-0 Type DMA-1 Type DMA-2 Type DMA-3 Type DMA-4 Type DMA-5 Type DMA-6 Type DMA-7 Type This above options allow you to change the protocol for DMA-0 through DMA-7.
  • Page 92 UPERSERVER 5011H/5011E User's Manual C000, 16k Shadow C400, 16k Shadow C800, 16k Shadow CC00, 16k Shadow D000, 16k Shadow D400, 16k Shadow D800, 16k Shadow DC00, 16k Shadow These options specify how the 16 KB of video ROM at each of the above addresses is treated.

  • Page 93: Pci Pnp Setup

    PCI PnP Setup Choose PCI/PnP Setup from the AMIBIOS Setup main menu. All PCI/PnP options are described in this section. The PCI/PnP Setup screen is shown below. Main Advanced Chipset PCIPnP Plug & Play O/S Reset Config Data PCI Latency Timer Allocate IRQ to VGA Palette Snooping PCI IDE BusMaster...
  • Page 94 UPERSERVER 5011H/5011E User's Manual PCI Latency Timer This option specifies the latency timing of the PCI clocks for all PCI devices. Settings include 32, 64, 96, 128, 160, 192, 224 and 248 PCI clocks. Allocate IRQ to PCI VGA This option lets you allocate an interrupt request (IRQ) to the PCI VGA adapter card (if used).
  • Page 95 Chapter 7: AMIBIOS Legacy USB Support This option allows Legacy USB support. The settings are Disabled, En- abled and Auto. Disabled prevents the use of any USB device in DOS or during system boot. Enabled allows the use of USB devices during boot and while using DOS.
  • Page 96 UPERSERVER 5011H/5011E User's Manual DMA Channel 0 DMA Channel 1 DMA Channel 3 DMA Channel 5 DMA Channel 6 DMA Channel 7 Each of the above list of DMA channel setting options can be set to Avail- able and Reserved. Available means the specified DMA channel is avail- able for use by PCI/PnP devices.

  • Page 97: Power Setup

    Power Setup Choose Power Setup from the AMIBIOS Setup main menu. All Power Setup options are described in this section. below. Main Advanced Chipset ACPI Aware O/S Suspend to RAM Support Repost Video on S3 Resume Power Management/APM Standby Time Out Suspend Power Saving Suspend Time Out Power Button Mode...
  • Page 98 UPERSERVER 5011H/5011E User's Manual ACPI Aware O/S This option allows the system to utilize Intel's ACPI (Advanced Configuration and Power Interface) specification. Settings are No and Yes. DOS®, Windows 3.x®, Windows 95 and Windows NT® are examples of non-ACPI aware operating systems.
  • Page 99 Chapter 7: AMIBIOS Suspend Power Saving Type The settings for this option are C2 and S1. The C2 setting allows the CPU (microprocessor) to be put in a low power state. In this state, incoming interrupts wake-up the CPU (microprocessor) to process them (I/O APIC). S1 allows the system to enter the S1 POS (Power On Suspend) state.
  • Page 100 UPERSERVER 5011H/5011E User's Manual Green PC Monitor Power State This option specifies the power state that a green PC-compliant monitor enters when BIOS places it in a power saving state after the specified period of display inactivity has expired. The settings include Standby, Sus- pend and Off.
  • Page 101 Chapter 7: AMIBIOS THRM Throttle Ratio THRM throttling is used to lower power consumption and reduce heat. The settings include 87.5%, 75.0%, 62.5%, 50%, 37.5%, 25% and 12.5%. Intruder Sel This option allows you to set the Intruder SEL setting to SCI or SMI. SCI stands for System Control Interrupt.
  • Page 102 UPERSERVER 5011H/5011E User's Manual TCO Logic SMI Enable This allows the system to generate a System Management Interrupt when a century rollover occurs. The settings for this option Disabled and Enabled. RTC Resume This allows you to direct the system to resume operation at a predetermined time by using the real-time clock.

  • Page 103: Boot Setup

    LAN Wake-Up This allows you to wake up LAN1 and LAN2 from a System Management Bus device. The settings for this option Disabled and Enabled. Boot Setup Choose Boot Setup from the AMIBIOS Setup main menu. options are described in this section. below.

  • Page 104: Hard Disk Drives

    UPERSERVER 5011H/5011E User's Manual 2nd Boot Device The settings for the 2nd Boot Device are Removeable Device, Hard Drive, ATAPI CDROM, Onboard LAN1Option and Onboard LAN2 Option. 3rd Boot Device The settings for the 3rd Boot Device are Removeable Device, Hard Drive, ATAPI CDROM, Onboard LAN1Option and Onboard LAN2 Option.

  • Page 105: Security Setup

    Security Setup Choose Security Setup from the AMIBIOS Setup main menu. All Security Setup options are described in this section. The Security Setup screen is shown below. Main Advanced Chipset Supervisor Password User Password > Change Supervisor Password > Change User Password >...

  • Page 106: Change Supervisor Password

    UPERSERVER 5011H/5011E User's Manual Change Supervisor Password This option allows you to change a supervisor password that was entered previously. Change User Password This option allows you to change a user password that was entered previ- ously. Clear User Password Use this option to clear the user password so that it is not required to be entered when the system boots up.

  • Page 107: 7-10 Exit Setup

    7-10 Exit Setup Choose Exit Setup from the AMIBIOS Setup main menu. All Exit Setup op- tions are described in this section. The Exit Setup screen is shown below. Main Advanced Chipset > Exit Saving Changes > Exit Discarding Changes >...

  • Page 108: Load Optimal Defaults

    UPERSERVER 5011H/5011E User's Manual Load Optimal Defaults Highlighting this setting and then pressing <Enter> provides the optimum performance settings for all devices and system features. Load Failsafe Defaults Highlighting this setting and then pressing <Enter> provides the safest set of parameters for the system.

  • Page 109: Appendix A: Bios Error Beep Codes And Messages

    Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes & Messages During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 110 5011H/5011E UPER ERVER AMIBIOS Error Beep Codes Beep Error Message Code 1 beep Refresh 2 beeps BIOS ROM file absent 3 beeps Base 64KB memory failure 4 beeps Flash program successful 5 beeps Media read error 6 beeps Keyboard controller Gate...

  • Page 111: Appendix Bamibios Post Checkpoint Codes

    AMIBIOS POST Checkpoint Codes When AMIBIOS performs the Power On Self Test, it writes diagnostic codes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, diagnostic equipment can be attached to the computer to read I/O port 0080h. Uncompressed Initialization Codes The uncompressed initialization checkpoint codes are listed in order of execution: Checkpoint...
  • Page 112 5011H/5011E UPER ERVER Bootblock Recovery Codes The bootblock recovery checkpoint codes are listed in order of execution: Checkpoint Code Description The onboard floppy controller if available is initialized. Next, beginning the base 512 KB memory test. Initializing the interrupt vector table next.
  • Page 113 Uncompressed Initialization Codes The following runtime checkpoint codes are listed in order of execution. These codes are uncompressed in F0000h shadow RAM. Checkpoint Code Description The NMI is disabled. Next, checking for a soft reset or a power on condition. The BIOS stack has been built.
  • Page 114 5011H/5011E UPER ERVER Checkpoint Code Description The video ROM has returned control to BIOS POST. Performing any required processing after the video ROM had control. Reading the 8042 input port and disabling the MEGAKEY Green PC feature next. Making the BIOS code segment writeable and performing any necessary configuration before initializing the interrupt vectors.
  • Page 115 Checkpoint Code Description Interrupts enabled if the diagnostics switch is on. Initializing data to check memory wraparound at 0:0 next. Data initialized. Checking for memory wraparound at 0:0 and finding the total system memory size next. The memory wraparound test is done. Memory size calculation has been done.
  • Page 116 5011H/5011E UPER ERVER Checkpoint Code Description The DMA page register test passed. Performing the DMA Controller 1 base register test next. The DMA controller 1 base register test passed. Performing the DMA controller 2 base register test next. The DMA controller 2 base register test passed. Programming DMA controllers 1 and 2 next.
  • Page 117 Checkpoint Code Description Initializing the bus option ROMs from C800 next. See the last page of this chapter for additional information. Initializing before passing control to the adaptor ROM at C800. Initialization before the C800 adaptor ROM gains control has com pleted.
  • Page 118 5011H/5011E UPER ERVER Bus Checkpoint Codes The system BIOS passes control to different buses at the following checkpoints: Checkpoint Code Description Initializing the different bus system, static, and output devices, if present. Initialized bus input, IPL, and general devices, if present.

  • Page 119: Appendix C: List Of Figures

    Adding PCI Cards SUPER P3TSSR Layout SUPER P3TSSE Layout Chassis Front and Rear Views System Cooling Fans Mounting a SCSI Drive in a Carrier (5011H) Removing SCSI Drives (5011H) Removing IDE Drives (5011E) Chassis Rear View Appendix C: List of Figures...
  • Page 120 5011H/5011E UPER ERVER Manual Notes...

  • Page 121: Appendix D System Specifications

    SCA backplane for two (2) SCA hot-swap SCSI drives Main Drive Bays 5011H: Two (2) drive bays to house two (2) standard 1" 80-pin SCA SCSI drives 5011E: Two (2) drive bays to house two (2) 3.5 x 1" IDE disk drives Peripheral Bays One (1) 3.5"...
  • Page 122 5011H/5011E UPER ERVER Manual Humidity Range: 5-90%, non-condensing Safety Regulations: UL 1950, CUL, TUV EMI: FCC part 15, CISPR 22 (EN 55022) Cooling Fans System: One (1) 10-cm ball bearing blower fan Onboard Fan Headers: One (1) CPU, two (2) chassis and two (2) overheat fan headers;...
