Futech MULTICROSS 3D COMPACT Manual page 5

MULTICROSS 3D COMPACT
MANUAL
Slope mode
3 sec.
Slide the on/off switch (5) to "OFF" so the laser beams are turned off and the trans-
portationlock is active.
Press 3 seconds on the power button (4). The horizontal laser line will be highlighted.
Now sloping surfaces and ramps will be constructed.
&
In order to use vertical lines, press 1x on the power button (4) to activate laser line V1
(2). Press a second time in order to activate laser line V2 (3). Pressing a third time will
switch off the laser.
IMPORTANT:
∙ In this mode, the laser lines no longer alighn automatically. This is signalised by the
laser lines flashing.
5
