First use
Remove any protective films where applied. Open the battery compartment (6) and
insert batteries, please taking care to observe the indicated polarity.
Turn the transportation lock (5) to the "ON" position. The laser is switched on, the
pendulum levelling mechanism is released, and the instrument is able to align itself
on its own. Make sure that the instrument is not on too much of a slope (within 3,5°).
If the slope of the instrument should exceed 3,5°, the lasers will flash or will go out
automatically.
Horizontal and vertical alignment
After disengagement of the pendulum locking system, and provided the instrument
is within its levelling range, the horizontal line is levelled. De horizontal line is always
activated. You can activate or deactivate the vertical lines using the power-button (4).
Press the number of times this button to get the desired number of laser lines.
It is advisable to place the horizontal line on your working height.
Attention:
∙ Cross line lasers can only be used on tripods which are adjustable in height, such as
cranked or telescopic tripods.
∙ If the workplace is very brightly lit, e.g. out of doors, it may be necessary to use the
laser receiver.
4
> 3,5°
H
ON: H
1x: H + V1
2x: H + V1 + V2
V
2
V
1
