Futech DM3540 User Manual

Laser distance meter 40/60m
Hide thumbs Also See for DM3540:
1
2
3
4
5

Advertisement

Quick Links

Download this manual
USER MANUAL [EN]
DM3540 – LASER DISTANCE METER (40M)
DM3560 – LASER DISTANCE METER (60M)
OVERVIEW
MANUAL DM3540 & DM3560 [EN]
A: Dimension button (measure area, volume, Pythagorean)
B: Distance unit button (transformation of m/in/ft/ft+in (long press); plus and
minus operation (short press))
C: Red power button (start, single measure, continuous)
D: Clear/off button (the final step will be canceled (short press); power off (long
press))
E: Reference button (Datum of change measurement)
F: Battery cover
www.futech-EASY.com
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the DM3540 and is the answer not in the manual?

Questions and answers

Related Manuals for Futech DM3540

Summary of Contents for Futech DM3540

  • Page 1 USER MANUAL [EN] DM3540 – LASER DISTANCE METER (40M) DM3560 – LASER DISTANCE METER (60M) OVERVIEW A: Dimension button (measure area, volume, Pythagorean) B: Distance unit button (transformation of m/in/ft/ft+in (long press); plus and minus operation (short press)) C: Red power button (start, single measure, continuous) D: Clear/off button (the final step will be canceled (short press);...
  • Page 2 - The instrument will automatically shut down when no operations are performed within 45 seconds. CLEAR DATA Press the red power button [C] to turn on the instrument. Press the clear/off button [D] to clear or delete data. MANUAL DM3540 & DM3560 [EN] www.futech-EASY.com...
  • Page 3 The instrument will automatically calculate the volume and the calculation will be shown in the main display area [T]. The measured length, width and height are shown in the auxiliary display [Q, R and S]. MANUAL DM3540 & DM3560 [EN] www.futech-EASY.com...
  • Page 4 Turn the machine off and on. If it is still not resolved after several times of restarting, please contact the company SPECIFICATIONS DM3540 DM3560 Measurement accuracy +/- 3mm Measuring unit M/in/ft/in+ft Measuring range 0,05-40m 0,05-60m MANUAL DM3540 & DM3560 [EN] www.futech-EASY.com...
  • Page 5 Area/volume/Pythagorean measurement function Button’s service life One million times Type and service life of battery AAA, 1.5vX2, max 6000 times Product size 100*35*23mm Weight Working temperature 0°C – 40°C Storage temperature -20°C – 60°C MANUAL DM3540 & DM3560 [EN] www.futech-EASY.com...
