Summary of Contents for Futech DM3540
- Page 1 USER EN ENGLISH MANUAL Manual in your DM3540 DISTANCE METER - 40M language? DM3560 DISTANCE METER - 60M Check the back cover...
- Page 2 KEYPAD OVERVIEW 01 Function button 02 Add/subtract button / Unit button 03 Measure / Power ON button 04 Clear / Power OFF button 05 Reference button 06 Battery cover SCREEN Laser ON/OFF Reference point at front of device Reference point at back of device Function indicator MAX indicator (continuous measurement) MIN indicator (continuous measurement)
-
Page 3: First Time Usage
SAFETY FIRST TIME USAGE Please read the safety instructions is provided in the separate Remove all protection foils. booklet provided with the device before using. The improper use of this product may result in dangerous inju- ries of laser radiation, electric shock and personal injuries. ·... -
Page 4: Change Units
CHANGE UNITS This device can show the measured distances in different units. The available units are meten (m), inch (in), feet (ft), inch + feet (in+ft). · Once the device is on, activate continuous measurement by · Change the distance units by holding the Add/subtract button holding the Measure button [3] until the fucntion starts. -
Page 5: Area Measurement
The measured value moves to the second display line [L]. A “+” AREA MEASUREMENT or “−” is shown in front of the first display line [N]. The device is ready to make the second measurement. This device allows you to calculate the area of a ·... -
Page 6: Volume Measurement
VOLUME MEASUREMENT INDIRECT MEASUREMENT (PYTHAGORAS) This device allows you to calculate the volume. · Press the function button [01] twice. The function indicator [D] will show you the volume measure- ment symbol. The flashing line in this function indicator [D] shows which length you have to measure. - Page 7 The length of the second measured side is shown on the second AND it should be made at a 90° angle to the point to be display line [K]. The result of the calculation, the distance measured. This second points needs to be between the first between the first and the second measured point, can be read in and third measured point.
-
Page 8: Clear Data
indicator [D] shows which length you have to measure. · Measure the first side, indicated by the function indicator by pressing the measure button [03] (the longest hypotenuse). The length of the first measured side is shown on the third display line [K]. -
Page 10: Technical Specifications
TECHNICAL SPECIFICATIONS MODEL DM3540 DM3560 Accuracy +/- 3mm Range Measurement units m / in / ft / in + ft Continuous measurement Min/Max Surface Volume Pythagoras Yes (x3) Subtract Automatic shutdown Battery 2x 1.5V AAA Operation temperature 0°C ~ +40°C... -
Page 11: Declaration Of Conformity
DECLARATION OF CONFORMITY Futech (Belgium) declares under its own responsibility that this device: - DM3540 Distance Meter - DM3560 Distance Meter is in conformity with the standards EN 61326-1:2013 IEC 60825-1:2014 Lier, Belgium, March 30, 2023 Patrick Waûters Potential misprints are reserved. Images used are not strict. All features, functionality and other product... - Page 12 USER MANUAL other languages: DANSK ITALIANO DEUTSCH NEDERLANDS ESPAÑOL NORSK EESTI KEEL PORTUGUÊS SUOMEN KIELI SLOVENŠČINA FRANÇAIS SVENSKA ÍSLENSKA Facebook @futechtools LinkedIn futechtools World Wide Web futech-easy.com YouTube @futechtools...
