Registering a Big Button onto a Touchsafe Pro Nursecall system
1. Put the Touchsafe Pro Master Panel into Telecare registration mode; touch the screen and Logon as an Engineer or a Manager
(password required), then from the main menu page touch the Telecare button to open the screen shown below...
On‐screen keypad
Use keypad to enter
8 digit ID here
Select the relevant
Call Point ID here
Save when done
2. Enter the big button ID...
ZXT439
W66794
Ser: 10156722
GD
ID: 20337434
EE0750 V1.07A
3. Press the Close button to exit Telecare mode and the Nursecall panel is now back in normal operating mode.
4. Activate the big button and check a pendant call is displayed on the Nursecall panel like this...
The screen banner is orange for a pendant call (Touch the banner to display notes).
Press the Accept button on the banner to silence the alarm ‐ this will also
notify all other panels the call is being dealt with.
The screen banner changes to purple when a call is accepted.
You must visit the appropriate Nursecall Call Point to cancel the call.
Deleting a Big Button from a Touchsafe Pro Nursecall system
Select the big button ID to be deleted from the Delete Telecare Device pull‐down list box (prefixed with a "T20").
Details of the big button selected will be displayed in the Room, House Code and ID boxes below.
If the details shown are correct press the Delete button.
Press the Close button to exit.
Refer to the Touchsafe Pro Display Panel user guide (Doc No. FM5505) provided with the Nursecall system for
more information.
Tynetec and Aidcall operate a policy of continuous improvement and reserve the right to change product specifications without notice.
If any variation to the details contained in this document are suspected please contact Tynetec's customer support dept on 01670 352371.
Doc No. FM0491 issue E Page 5
The 8 digit ID is printed on a label on the underside of the big button.
Note: this ID will always start with 20xxxxxx.
Touch the Add Telecare Device box then use the on‐screen keypad to enter the ID.
Hint: enter a zone in the Filter box to narrow the search for the room (see below).
Select the users Call Point ID from the Room pull‐down list box then press Save.
Note: this is the room unit that will be will be used to cancel the call.
Close to exit mode
CALLING
CANCEL
HC 345 ID 001
Press the LIGHT GREY
button to cancel the call
