Xycom XVME-500 Manual page 31

XVME-500/590 Manual
February, 1988
The various input gains are selected by installing two jumpers for each option.
Table 2-8 shows the options and corresponding jumpers.
I
Jumpers
J15, J19
J14, J18
J16, J20
Only one range can be selected at a time.
programmed for specific gains within the selected range.
2.6.4.2 Fixed Gains (Jumper-Selectable - version 1 only)(J6, J7, J8, or J9)
The fixed gain for each analog input channel in the version 1 of the XVME-500/590
is selected by installing or removing one of several jumpers (J6, J7,
Gains can be selected from one of four different levels as follows:
Level
I (Unity Gain)
2
3
4
Only one gain factor can be selected at a time.
programmed for a specific gain range. Thus, when a jumper is installed to achieve
a particular gain, others must be removed. Table 2.9 shows which jumpers are used
to select which gains.
Artisan Scientific - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisan-scientific.com
Table 2-8. Input Gain Range Selection Jumpers
(versions 2 & 3 only)
Installed
Gain Range Selected
Range
Range 2
Range 3
The input channels can only be
Gain Selected
x l
x10
xl00
xl000
The input channels can only be
2-14
1
J8, or J9).
