- Page 1 USER MANUAL Pellet Stove ©2022 CADEL srl | All rights reserved - Tutti i diritti riservati SWEET 7, 7.0 - PERLA 7, 7.0 - CRISTAL 7, 7.0, 7.0 UP ONE AIRTIGHT - BEAM AIRTIGHT - ACCENT AIRTIGHT SHARP AIRTIGHT - LEE AIRTIGHT - CHROME 5, 7 AIRTIGHT...
-
Page 2: Table Of Contents
PAG. 13 ..............21 SUMMARY 9 FUEL ............22 1 MANUAL SIMBOLOGY ........3 9.1 FUEL ..............22 2 DEAR CUSTOMER ..........3 9.2 PELLET SUPPLY .............22 2.1 REVISIONS TO THE PUBLICATION ......4 9.3 PELLET REFUELLING TIMER ........23 2.2 CARE OF THE MANUAL AND HOW TO CONSULT IT ...4 10 VENTILATION ..........23 SAFETY REQUIREMENTS ......5 11 REMOTE CONTROL (OPTIONAL) ....23... -
Page 3: Manual Simbology
MANUAL SIMBOLOGY USER AUTHORISED TECHNICIAN (ONLY to interpret or the Stove-manufacturer or the Authorized Technician of Technical Assistance Service approved by the Stove-manufacturer) SPECIALIZED STOVE-REPAIRER CAUTION: READ CAREFULLY THE NOTE CAUTION: DANGER OR IRREVERSIBLE DAMAGE POSSIBILITY • The icons with the stylized figures indicates whom the subject dealt in the paragraph is addressed to (between the User and/ or the Authorized Technician and/or the Specialized Stove-repairer). -
Page 4: Revisions To The Publication
Hereby CADEL S.r.l. declares that the radio equipment type Easy Connect Plus + Navel Stand Alone is in compliance with Directive 2014/53/EU. According to (EU) No. 305/2011 regulation, the " Declaration of Performance" and "Declaration of Conformity" are available online, in the download area, at the web sites: - www.cadelsrl.com... -
Page 5: Safety Requirements
SAFETY REQUIREMENTS • Installation, electrical connection, functional verification and maintenance must only be performed by qualified or authorised personnel. • Live electrical parts: disconnect the product from the 230V power supply before perfor- ming any maintenance operation. Only power the product after completing assembly. •... -
Page 6: Cautions - Warranty Conditions
experience and knowledge must be kept away from packaging. The stove IS NOT a toy. • Childreen must be constantly overseen in order to assure that they do not play with the appliance. • During its running, the stove reaches high temperatures: keep away childreen and animals and for your safety please use appropriate fireproof devices, such as heat-protecting gloves. -
Page 7: Warranty Conditions
WARRANTY CONDITIONS The duration, conditions and limitations of CADEL S.r.l. can be found on the guarantee card enclosed with the device. The company guarantees the product, with the exception of elements subject to normal wear listed below, for a period of 2 (two) years from the date of purchase attested by: •... -
Page 8: Spare Parts
tions and in accordance with the fee in force for the work to be carried out. The user will also be charged for any costs incurred to remedy the incorrect technical interventions, tampering or damage to the appliance, not attributable to original faults. Save for the legal or regulatory limits, the guarantee does not cover the containment of atmospheric and acoustic pollution. -
Page 9: Information For Management Of Electric And
LEGENDA WHERE TO DISPOSE MATERIALS Metal If there is any, to be disposed of separately based on Glass A. OUTER CLADDING the material used: Tiles or ceramics Stone Glass ceramic (fire door): to be disposed of with If there is any, to be disposed of separately based on inert or mixed waste B. -
Page 10: Wifi - Bluetooth Connection
DESCRIPTION CODE MATERIAL SYMBOL DIRECTIONS FOR COLLECTION SORTED waste collection - WOOD BED WOOD WOOD - WOOD CAGE Check with the competent body on FOR 50 - WOOD PALLET how to dispose of this packaging at the recycling depot SORTED waste collection - CARDBOARD BOX PAPER CORRUGATED CARDBOARD... -
Page 11: Navel Stand Alone (Optional)
Fig. 3 - EASY CONNECT PLUS module Fig. 4 - EASY CONNECT PLUS display Fig. 5 - EASY CONNECT PLUS app The documentation for connecting the Wi-Fi and using the App are available online at the following addresses: https://www.cadelsrl.com/donwload-wi-fi/ http://www.free-point.it/it/downloads/ https://www.pegasoheating.com/it/documenti/ NAVEL STAND ALONE (OPTIONAL) Procedure if only valid for models with NAVEL STAND ALONE Wi-Fi technology. -
Page 12: Use
Fig. 6 - NAVEL STAND ALONE module Fig. 7 - App EASY CONNECT PLUS The documentation for connecting the Wi-Fi and using the App are available online at the following addresses: https://www.cadelsrl.com/donwload-wi-fi/ http://www.free-point.it/it/downloads/ https://www.pegasoheating.com/it/documenti/ INTRODUCTION To have the best performance with the lowest consumption please follow the here descripted instructions. •... -
Page 13: Control Panel Display
CONTROL PANEL DISPLAY Menu items. Fig. 8 - Control panel Fig. 9 - Control panel (wi-fi) Fig. 10 - Display LEGEND Fig. 8|Fig. 9|Fig. 10 Boiler lighting/shutdown (ESC) Scrolling of programming menu to decrease Menu Scrolling of programming menu to increase Decrease set temperature/programming functions Increase set temperature/programming functions Display... - Page 14 g - Off Time Eco (default 5 minutes) x - Easy Set h - Pellet Recipe i - Smoke Fan rpm j - Components Test (displayed only when the boiler is switched off) k - Chimney Sweep Function (activated only when the boiler is switched on, for field emissions test) l - Technical Menu a - Language To select the language act as follows:...
- Page 15 • Press “menu” to confirm and “esc” to exit. g - Off Time Eco To select the Off Time Eco function act as follows: • Press the “menu” button. • Scroll to “Settings” using the arrows • Press “menu” to confirm. •...
-
Page 16: Info Menu
• Press “menu” to confirm. • Select “On” with the + - keys (Off by default) • Press “menu” to confirm and “esc” to exit l - Technical Menu To access the technical menu one must contact an assistance centre as one needs a password to enter. INFO MENU •... -
Page 17: Switch Off (On Panel: Off With Flashing Flame)
SWITCH OFF (ON PANEL: OFF WITH FLASHING FLAME) If the shutdown key is pressed or if there is an alarm signal, the boiler goes into the thermal shutdown phase which entails the automatic execution of the following stages: • Pellet loading is stopped. •... -
Page 18: Programmed Mode (Timer) - Main Menu
If the stove is set to maximum heat output 5 and the fans to minimum output 1, this may cause overheating and the “THERMAL SAFETY” alarm to go off. Comfort Mode - In the air versions, it cannot be deactivated. At power 1 the fans are off. In versions with ducting, the comfort mode allows you to automatically activate or deactivate all the fans at power 1. -
Page 19: Programming Examples
8.12 PROGRAMMING EXAMPLES: 08:00 12:00 11:00 14:00 Boiler on from 08:00 to 14:00 08:00 11:00 11:00 14:00 Boiler on from 08:00 to 14:00 17:00 24:00 00:00 06:00 Boiler on from 17:00 on monday to 06:00 on tuesday 8.13 NOTES FOR TIMER OPERATION •... -
Page 20: Sleep Function (Main Menu)
8.15 SLEEP FUNCTION (MAIN MENU) The sleep function is activated only when the boiler is switched on and allows to quickly set a time at which the product must switch off. To set the Sleep function act as follows: • Enter MENU •... -
Page 21: Pellets Recipe
LEGENDA Fig. 23 Smoke Outlet Combustion Air Intake Inspection cap 8.17 PELLETS RECIPE (SEE SECTION H SETTINGS MENU A PAG. 13) Changes to be made with the support of the authorised technician. Activates only with the Easy Set function disabled, "SET: 0" ! This function is for adapting the stove to the pellets that are being used. -
Page 22: Fuel
FUEL FUEL • Use top-quality pellets because they have influence in the calorific value and in ash remains. • Not adequate pellets cause a bad combustion, a frequent burning pot obstruction and exhaust conduits obstruction. Further it decreases the calorific value, soils the glass and increases consumptions and ash and unburnt granules quantity. Humid pellets cause a bad combustion and running, so please assure you that they are stored in dry places and far at least one meter from the stove and/or any other source of heat. -
Page 23: Pellet Refuelling Timer
PELLET REFUELLING TIMER This stove is equipped with a safety timer that activates after the pellet hopper door has been open for 90 seconds during reloa- ding (see Fig. 26 and Fig. 28). After 90 seconds, the stove goes into "A05" depression alarm and proceeds to switch off. Wait until it switches off, then light it again. -
Page 24: Safety Devices And Alarms
Used batteries contain metals which are harmful for the environment; they must therefore be disposed of separately in the special containers. Fig. 30 - Remote control LEGEND Fig. 30 Button 1 Increase the desired temperature (5÷35 °C) Button 2 Decrease the desired temperature (35÷5 °C) Button 3 On / off Button 4... -
Page 25: Gear Motor
12.6 GEAR MOTOR If the gear motor stops, the boiler will continue to run until the flame goes out due to lack of fuel and until a minimum level of cooling is reached. 12.7 TEMPORARY POWER CUT If the power cut lasts less than 10” the boiler returns to its previous operating status; if it lasts more it carries out a cooling/restart cycle. -
Page 26: Alarm Reset
12.11 ALARM RESET To reset the alarm you must keep the 1 (ESC) button pressed for some time. The stove performs a check to determine whether the warning cause is still present. If this is the case, the warning will be shown again, otherwise the stove will switch to the OFF position. If the warning is still present, contact a service centre. -
Page 27: Hopper Cleaning
Fig. 33 - Burning pot extraction Fig. 34 - Burning pot cleaning • Extract the burning pot (see Fig. 33) from its seat and empty it from the ash. • If necessary clean with a pointed object the holes obstructed by encrustations (see Fig. 34). Fig. -
Page 28: Fume Pipes Annual Cleaning
13.5 FUME PIPES ANNUAL CLEANING Clean annually from soot with brushes. The cleaning operation must be executed by a specialized stove-repairer who will provide for the cleaning of fume pipe, chimney flue and chimney pot. He will also check their eficiency and will release a written declaration of the safety of the appliance. This operation must be executed at least once a year. -
Page 29: Checking The Inner Components
When not in use the appliance must be disconnected from the mains power supply. It is recommended to remove the power cable for additional safety, especially in the presence of children. The service fuse may have to be replaced if the control panel display does not switch on. There is a fusebox on the back of the product, near the power socket. - Page 30 PROBLEM CAUSE SOLUTION INTERVENTION The stove is without Check if the plug is connected. power supply Burned protection fuse in the electric Replace the protection fuses in the electric socket (3.15A-250V). socket The control display Faulty control Replace the control display. does not switch on display Faulty flat cable...
- Page 31 PROBLEM CAUSE SOLUTION INTERVENTION Check as following: probable obstructions of the combustible air Not sufficient com- inlet from the back or from the bottom of the stove; burning pot bustion air obstructed holes with too ash remains. Have the fan blades and auger cleaned.
-
Page 32: Technical Documentation For Local Space Heaters According To Commission Regulations (Eu) 2015/1185 - (Eu) 2015/1186 (Product Fiche)
TECHNICAL DOCUMENTATION FOR LOCAL SPACE HEATERS ACCORDING TO COM- MISSION REGULATIONS (EU) 2015/1185 - (EU) 2015/1186 (PRODUCT FICHE) CADEL srl - Via Foresto Sud 7 - 31025 Santa Lucia di Piave (TV) - Italy Manufacturer CADEL: SWEET3 7.0 - PERLA3 7.0 - CRISTAL 7.0... - Page 33 TECHNICAL DOCUMENTATION FOR LOCAL SPACE HEATERS ACCORDING TO COM- MISSION REGULATIONS (EU) 2015/1185 - (EU) 2015/1186 (PRODUCT FICHE) CADEL srl - Via Foresto Sud 7 - 31025 Santa Lucia di Piave (TV) - Italy Manufacturer CADEL: CRISTAL3 7.0 UP Trademak: model identifier FREEPOINT: SHARP AIRTIGHT-LEE AIRTIGHT PEGASO:VERA 7.0 UP...
- Page 34 TECHNICAL DOCUMENTATION FOR LOCAL SPACE HEATERS ACCORDING TO COM- MISSION REGULATIONS (EU) 2015/1185 - (EU) 2015/1186 (PRODUCT FICHE) CADEL srl - Via Foresto Sud 7 - 31025 Santa Lucia di Piave (TV) - Italy Manufacturer CADEL: SOUND3 7 UP Trademak: model identifier FREEPOINT: CHROME7 AIRTIGHT- ROUND7 AIRTIGHT PEGASO: FLOYD 7.0...
- Page 35 TECHNICAL DOCUMENTATION FOR LOCAL SPACE HEATERS ACCORDING TO COM- MISSION REGULATIONS (EU) 2015/1185 - (EU) 2015/1186 (PRODUCT FICHE) CADEL srl - Via Foresto Sud 7 - 31025 Santa Lucia di Piave (TV) - Italy Manufacturer CADEL: SOUND3 5 UP Trademak: model identifier FREEPOINT: CHROME5 AIRTIGHT- ROUND5 AIRTIGHT PEGASO: FLOYD 5.0...
- Page 36 TECHNICAL DOCUMENTATION FOR LOCAL SPACE HEATERS ACCORDING TO COM- MISSION REGULATIONS (EU) 2015/1185 - (EU) 2015/1186 (PRODUCT FICHE) CADEL srl - Via Foresto Sud 7 - 31025 Santa Lucia di Piave (TV) - Italy Manufacturer CADEL: SOUND 5 PS Trademak: model identifier...
- Page 37 TECHNICAL DOCUMENTATION FOR LOCAL SPACE HEATERS ACCORDING TO COM- MISSION REGULATIONS (EU) 2015/1185 - (EU) 2015/1186 (PRODUCT FICHE) CADEL srl - Via Foresto Sud 7 - 31025 Santa Lucia di Piave (TV) - Italy Manufacturer CADEL: SOUND 7 PS Trademak: model identifier...
- Page 38 NOTE...
- Page 39 NOTE...
- Page 40 Rev. 01 - 2022 CADEL srl www.cadelsrl.com 31025 S. Lucia di Piave - TV www.free-point.it Via Foresto sud, 7 - Italy www.pegasoheating.com Tel. +39.0438.738669 Fax +39.0438.73343...
