- Page 1 INSTALLER MANUAL Pellet Stove Original Instructions | ©2022 CADEL srl | All rights reserved - Tutti i diritti riservati VERA 7 - VERA 7.0 - INDIGO EVO - INDIGO EVO 7 VERA 7.0 UP - CRISTAL3 7.0 UP...
-
Page 2: Table Of Contents
6.2 MINIMUM DISTANCES ....11 6.3 OVERALL DIMENSIONS ....12 6.4 STOVE DOOR REMOVAL/ INSTALLATION ........13 6.5 REMOVAL/ASSEMBLY OF SIDE PANELS 6.6 ELECTRIC CONNECTION ....14 6.7 CONNECTION TO THE EXTERNAL VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... -
Page 3: Manual Simbology
Proceed as follows: Fig. 1 - Bracket removal • Remove the brackets which secure the feet of the stove (see Fig. 1). Then remove the stove from the pallet. VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... -
Page 4: Stove Handling
Fig. 2 - Chimney components LEGEND Fig. 2 Chimney pot Fume outlet Chimney flue Termal insulation External wall Chimney union Fume pipe Heat generator Inspection door T-union with inspection plug VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... -
Page 5: Smoke Duct (Smoke Fitting)
It is forbidden to use the direct drain on the wall or towards indoor spaces and any other form of drain not provided for by the regulation in force in the country of installation. VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... -
Page 6: Chimney Pot
(**) unless there are specific national derogations (clearly specified in the corresponding instruction manual in English) which under appropriate conditions allow it; in this case, strictly follow the product/installation requirements of the relative regulations/technical specifications/legislation in force in that country. VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... -
Page 7: Maintenance
(***) In the event the combustion air is ducted on unsealed products, still verify that no more than 4 Pa of negative pressure is created inside the installation room with respect to the outside, otherwise provide for an additional air intake in the room. VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... -
Page 8: Combustible Air Inlet For Sealed
How to connect to the stove in the sealed chamber with concentric system: Fig. 9 - Phase1 • Connect the air intake pipe to the combustion air pipe of the stove and tighten everything with a clamp (see [Fig. 9). VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... -
Page 9: Examples Of Installation (Diameters And Lengths To Be Sized)
3. External flue made of insulated stainless-steel pipes, i.e. with double walls: all securely mounted on the wall. With windproof chimneypot. 4. Ducting system using Tee fittings that allow easy access for cleaning without having to remove the pipes. VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... -
Page 10: Installation
Sealed installation means that the product is certified as sealed and its installation (ducting of the combustion air and connection to the chimney) is airtight with respect to the installa- tion environment. VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... -
Page 11: Minimum Distances
In any case, ensure adequate distance to facilitate access during cleaning and extraordinary maintenance. If this is not possible, it must still be possible to distance the product from adjacent walls/elements. VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... -
Page 12: Overall Dimensions
45,7 cm 18,2 cm 31,4 cm 12,9 cm 20,2 cm Exhaust fumes d.8 cm Hole combustion air inlet d.6 cm Fig. 13 - General dimensions:INDIGO EVO - INDIGO EVO 7 VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... -
Page 13: Installation
For some operations (e.g.: side panel assembly and cleaning) you must remove the stove door. To remove the door: • Open the door. • Undo the screws from the upper hinge (see Fig. 16). VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... -
Page 14: Removal/Assembly Of Side Panels
• Connect the supply cable first on the back of the stove (see Fig. 22 and Fig. 23) and then at a wall electric socket. VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... -
Page 15: Connection To The External Thermostat
The stove works through a thermostat probe placed in its inner. If you desire, the stove can be connected to an external room thermostat. This operation must be executed by an authorized technician. VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... -
Page 16: Stove Calibration And Depression
• It is also necessary to have the combustion chamber, motors and fans cleaned and to have the gaskets and the electronical elements checked at least once a year. VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... -
Page 17: Fume Conduit Cleaning
Fig. 29 - Remove the screws Fig. 30 - Remove the inspection cap • Aprire la porta. • Rimuovere le 4 viti (vedi Fig. 29) e rimuovere il tappo d'ispezione (vedi Fig. 30). VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... -
Page 18: Room Fan Cleaning
In case of deterioration of fire door, hopper or fume chamber gaskets, it is necessary to replace them by an autorized technician in order to guarantee the good running of the stove. Use exclusively original spare parts. VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... -
Page 19: In Case Of Anomaly
Clean the auger. example nails) The auger geared motor is out of order Replace the geared motor. Check if on the display there is an Have the stove checked. "ACTIVE ALARM" VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... - Page 20 Stove running and display showing Reached fume outlet The stove runs at minimum. NO PROBLEM! "Smoke Overtepe- limit temperature rature" VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP...
-
Page 21: Technical Datas
(vedi Fig. 36).To assembly proceed at the contrary. Fig. 35 - Remove the screws Fig. 36 - Remove the screw VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... -
Page 22: Features
DISTANCE FROM COMBUSTIBLE MATERIAL (back/side/bottom) 200 / 300 / 0 mm 200 / 300 / 0 mm DISTANCE FROM COMBUSTIBLE MATERIAL (ceiling/front) - / 1000 mm - / 1000 mm VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP... - Page 23 DISTANCE FROM COMBUSTIBLE MATERIAL (back/side/bottom) 200 / 300 / 0 mm 200 / 300 / 0 mm DISTANCE FROM COMBUSTIBLE MATERIAL (ceiling/front) - / 1000 mm - / 1000 mm VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP...
- Page 24 DISTANCE FROM COMBUSTIBLE MATERIAL (back/side/bottom) 200 / 300 / 0 mm 200 / 300 / 0 mm DISTANCE FROM COMBUSTIBLE MATERIAL (ceiling/front) - / 1000 mm - / 1000 mm VERA7 - INDIGO EVO 7 - VERA7 UP - CRISTAL 7UP...
- Page 25 Rev. 00 - 2022 CADEL srl www.cadelsrl.com 31025 S. Lucia di Piave - TV www.free-point.it Via Foresto sud, 7 - Italy www.pegasoheating.com Tel. +39.0438.738669 Fax +39.0438.73343...
