ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM-DK6431
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 6
(Included)
(Not Included)
Rev:16-09-01
Advertisement
Table of Contents
Related Manuals for Furniture of America CM-DK6431
Summary of Contents for Furniture of America CM-DK6431
- Page 1 Assembly Instructions CM-DK6431 ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Phillips Screwdriver products, two persons are recommended.
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 10pcs Cabinet body Bolt Ø1/4" x 2" #2 x 4pcs #B x 8pcs Lock Washer Ø1/4"...
- Page 4 1. Prepare 8 bolt assemblies by first inserting a lock washer (#B) onto the bolt (#A) then a flat washer (#C) onto that same bolt (#A). Pull out drawer for #A x 8pcs access to rear holes. #B x 8pcs #C x 8pcs 2.
- Page 5 #F x 4pcs #H x 4pcs Align the mirror supports (#4) to the base (#3), then insert a bolt (#F) with flat washer (#H) into each hole. Secure using a screwdriver. #G x 2pcs Align the mirror (#5) to the holes along the mirror supports (#4) then insert the mirror bolts (#G) and turn right to tighten.
- Page 6 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 8pcs Seat Bolt Ø1/4" x 2" #B x 8pcs #2 x 4pcs Lock Washer Ø1/4"...
