Furniture of America Potterville CM-DK6490 Assembly Instructions

ASSEMBLY RATING

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

EASY

CM-DK6490

DIFFICULT

Page 1 of 5

Allen Wrench

Phillips Screwdriver

2 PERSONS RECOMMENDED

(Included)

(Not Included)

Rev.14-10-31

Table of Contents

Do you have a question about the Potterville CM-DK6490 and is the answer not in the manual?

Page 1 Assembly Instructions CM-DK6490 ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Phillips Screwdriver products, two persons are recommended.
Page 2 Page 2 of 5...
Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 16 pcs Vanity Bolt 5/16”x2” #B x 16 pcs #2 x 4 pcs Lock Washer Vanity Leg...
Page 4 Turn right (clockwise) to tighten #A x 8 pcs #B x 8 pcs #C x 8 pcs With the help of another person, carefully place the vanity (#1) facing down on a protected surface. Align the 4 vanity legs (#2) with the pre-drilled holes on the corners of the vanity (#1).
Page 5 #A x 8 pcs #B x 8 pcs #C x 8 pcs Place the seat (#5) facing down on a protected surface. Align the 4 chair legs (#6) with the pre-drilled holes on the corners of the seat (#5). III. Prepare 8 bolt assemblies by inserting FIRST the lock washer (#B) onto the bolt (#A) and then the...
