For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM-DK6103 T/B
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 7
(Included)
(Not Included)
Rev: 18-06-13
Advertisement
Related Manuals for Furniture of America CM-DK6103 T
Summary of Contents for Furniture of America CM-DK6103 T
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM-DK6103 T/B ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 7...
- Page 3 Before you begin, please read Page 2,3 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 4pcs Wood Dowel 5/16" x 1-1/4" #2 x 2pcs #B x 8pcs Pedestal Bolt Ø1/4"...
- Page 4 Attach legs (#3) to the bottom holes of the pedestals (#2). Unscrew knobs from the inside of the drawers in the pedestals (#2), then secure knobs to the outside of the drawers.
- Page 5 Remove first two drawers on each pedestals (#2). 1) Attach dowels (#A) to the holes of the pedestals (#2) as shown in the image. Prepare 8 bolts assembly by inserting lock washer (#C), then flat washer (#D) onto bolts (#B). 2) Align top (#1) to the holes of the pedestals (#2).
- Page 6 2) Plug power cords to the electrical outlet. 1) Connect wires together. Attach drawers back into the pedestals (#2).
- Page 7 Lift and extend the table. Turn on the led light ASSEMBLY IS COMPLETED Page 7 of 7...
