ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
For more information contact our team: service.ec@foagroup.com
CM-DK6162
DIFFICULT
Tools Required For Assembly:
Allen Wrench
2 PERSONS RECOMMENDED
Page 1 of 8
(Included)
Rev:18-07-11
Advertisement
Related Manuals for Furniture of America CM-DK6162
Summary of Contents for Furniture of America CM-DK6162
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM-DK6162 ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Allen Wrench easy and 5 being difficult).
- Page 2 Use cardboard or carpet area when assembling furniture to prevent scratches .Make sure the furniture rests on a flat and level surface with each leg evenly touching the floor. No dragging of products/parts.
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 5pcs Cabinet body Bolt Ø1/4" x 2" #2 x 4pcs #B x 5pcs Barrel Nut Ø1/4"...
- Page 4 Attach legs (#2) to the bottom holes of the cabinet body (#1). Align and attach the risers (#4) to the holes of the bottom plate (#3). #I x 1pc Pour glue (#I) into the hold (#3) before installing the wood dowel Page 4 of 8...
- Page 5 Insert barrel nuts (#B) to the holes of the bottom plate (#3). Make sure the barrel nut (#B) holes are facing the same direction as the hole on the back side of bottom plate (#3). Align backplane (#5) to the holes of the bottom plate (#3), then secure by attaching bolts (#A) to barrel nuts (#B).
- Page 6 Prepare 4 bolts assembly by inserting lock washer (#D), then flat washer (#E) onto bolts (#C). Align mirror connecting rods (#10) to the holes located in the back side of the cabinet body (#1). Secure with bolts (#C). #C x 4pcs #D x 4pcs #E x 4pcs Prepare 4 bolts assembly by inserting lock washer (#D), then flat washer (#E) onto bolts (#C).
- Page 7 Slide the side mirrors (#9) down to the metal pole of the middle mirror (#8). Unscrew the knob, then reattach the knob to the outside of the drawer.
- Page 8 Prepare 8 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align legs (#2) to the holes of the cushion (#1), then secure with bolts (#A).
