ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
For more information contact our team: service.ec@foagroup.com
CM-DK6845
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 8
(Included)
(Not Included)
Rev:16-09-05
Advertisement
Table of Contents
Related Manuals for Furniture of America Harriet CM-DK6845
Summary of Contents for Furniture of America Harriet CM-DK6845
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM-DK6845 ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 8...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 13pcs Mirror Bolt 1/4" x 2" #2 x 2pcs #B x 8pcs Mirror Support Flat Washer Ø1/4"...
- Page 4 1. Prepare 8 bolt assemblies by first inserting a lock washer (#C) onto the bolt (#A) then a flat washer (#B) onto that same bolt (#A). #A x 8pcs #B x 8pcs #C x 8pcs 2. Align the legs (#9) to the holes along the corners of the cabinet body (#8), then insert the bolt assemblies...
- Page 5 1. Insert the pins along the top panel (#4) into the holes along the side panels (#5). 2. Insert the barrel nuts (#E) into the large holes along the #A x 3pcs side panels (#5), make sure #E x 2pcs the holes face the openings.
- Page 6 1. Insert the barrel nut (#E) into the large holes along the back panel (#6), make sure to align the hole. #A x 2pcs #E x 2pcs 2. Insert the bolts (#A) into the holes from beneath and into the nuts. Secure using the Allen wrench (#D).
- Page 7 Align the mirror (#1) to the holes along the mirror supports (#2),then insert the mirror bolts (#G). Turn right to secure. #G x 2pcs Insert the drawer top (#7) and the drawer bottom (#10). ASSEMBLY IS COMPLETED Page 7 of 8...
- Page 8 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 8pcs Seat Bolt Ø1/4" x 2" #B x 8pcs #2 x 4pcs Flat Washer Ø1/4"...
