ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM-DK6846
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 8
(Included)
(Not Included)
Rev: 16-09-16
Advertisement
Related Manuals for Furniture of America CM-DK6846
Summary of Contents for Furniture of America CM-DK6846
- Page 1 Assembly Instructions CM-DK6846 ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Phillips Screwdriver products, two persons are recommended.
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 8...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 16pcs Cabinet body Bolt 1/4 x 2" #2 x 4pcs #B x 16pcs Flat Washer Ø1/4"...
- Page 4 Remove drawers 1. Prepare 8 bolt assemblies to assemble legs. by first inserting a lock washer (#C) onto the bolt (#A) then a flat washer (#B) #A x 8pcs #B x 8pcs onto that same bolt (#A). #C x 8pcs 2.
- Page 5 Insert into the holes along the cabinet body (#1). Insert the barrel nuts (#E) into the large holes with the openings facing the hole, then insert the bolts (#A) from beneath. Secure #A x 2pcs using the Allen wrench (#D). #E x 2pcs Page 5 of 8...
- Page 6 2. Prepare 4 bolt assemblies by first 1. Align the mirror supports (#7) inserting a lock washer (#C) onto the to the holes along the back. bolt (#A) then a flat washer (#B) onto that same bolt (#A). Insert a bolt #A x 4pcs assembly into each hole and secure.
- Page 7 Insert the brackets along the left and right mirrors (#9) into the pins along mirror (#8). ASSEMBLY IS COMPLETED Page 7 of 8...
- Page 8 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 8pcs Seat Bolt Ø1/4" x 2" #B x 8pcs #2 x 4pcs Flat Washer Ø1/4"...
