ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
For more information contact our team: service.ec@foagroup.com
CM-DK6846
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 8
(Included)
(Not Included)
Rev:16-09-05
Advertisement
Table of Contents
Related Manuals for Furniture of America CM-DK6846
Summary of Contents for Furniture of America CM-DK6846
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM-DK6846 ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 8...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 16pcs Cabinet body Bolt 1/4 x 2" #2 x 4pcs #B x 16pcs Flat Washer Ø1/4"...
- Page 4 Pull out drawer for access to rear holes. 1. Prepare 8 bolt assemblies by first inserting a lock washer (#C) onto the bolt (#A) then a flat washer (#B) onto that same bolt (#A). #A x 8pcs #B x 8pcs #C x 8pcs 2.
- Page 5 Insert each end into the holes along the cabinet body (#1). 1. Insert the barrel nut (#E) into the large holes along the hutch back (#5) make sure to align the #A x 2pcs hole. #E x 2pcs 2. Insert the bolts (#A) into the holes from beneath and into the nuts.
- Page 6 . Prepare 2 bolt assemblies by first inserting a lock washer (#C) onto the bolt (#A) then a flat washer (#B) onto that same bolt (#A). #A x 4pcs #B x 4pcs #C x 4pcs 2. Insert into rear inner holes and secure.
- Page 7 Insert the drawers (#6) ASSEMBLY IS COMPLETED Page 7 of 8...
- Page 8 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 8pcs Seat Bolt Ø1/4" x 2" #B x 8pcs #2 x 4pcs Flat Washer Ø1/4"...
