- Page 1 SL7035 ENCH WNER ANUAL 15S Rev A CAUTION! Read all precautions and instructions in this manual before using this equipment.
-
Page 2: Table Of Contents
! CAUTION Read all precautions and instructions in this manual before using this equipment. Table Of Contents Important Safety Instructions Instructions Parts List and Exploded View Measurement Guide Assembly Instructions Assembly Maintenance Schedule General Maintenance Information Weight Training Tips... -
Page 3: Important Safety Instructions
Important Safety Instructions Before beginning any fitness program, you should obtain a complete physical examination from your physician. When using exercise equipment, basic precautions should always be taken, including the following: 1. Read all instructions before using the equipment. These instructions are written to ensure your safety and to protect the unit. 2. - Page 4 Important Safety Instructions Personal Safety During Assembly Read each step in the assembly instructions and follow the steps in sequence. Do not skip ahead. If you skip ahead, you may learn later that you have to disassemble components and that you may have damaged the equipment. Assemble and operate the equipment on a solid, level surface.
-
Page 5: Instructions
Instructions Before beginning assembly please take the time to read instructions thoroughly. Please use the various lists in this manual to make sure that all parts have been included in your shipment. When ordering, use part number and description from the lists. -
Page 6: Parts List And Exploded View
Parts List and Exploded View Button Frame Assy Description Item No. Button Frame Wheel Foot Pad Socket Head Cap Screw M8*45 Flat Washer Φ9*Φ16*1.6 Nylon Lock Nut M8 Seat Frame ASSY Description Item No. Seat Frame Foot Pad ─ 6 ─... - Page 7 Parts List and Exploded View Overall Description Item No. Button Frame ASSY Seat Frame ASSY Sit Pad Socket Head Cap Screw M12*35 Socket Head Cap Screw M10*30 Flat Washer Φ13*Φ24*1.5 Flat Washer Φ11*Φ23*2 ─ 7 ─...
-
Page 8: Measurement Guide
Measurement Guide BHCS = Button Head Cap Screw SHCS = Socket Head Cap Screw FHCS = Flat Head Cap Screw HHB = Hex Head Bolt Millimeters Inches Diameter of bolt M6(1/4") M8(5/16") M10(3/8") M12(1/2") M16(5/8") (mm/inch) Tightening 9~12 22~30 45~59 78~104 193~257 torque (N.m) -
Page 9: Assembly Instructions
Assembly Instructions Assembly of the equipment takes professional installers about 2 hours. If this is the first time you have assembled this type of equipment, plan to spend more time. It is strongly recommended to assemble the equipment by professional installers. -
Page 10: Assembly
Assembly Step 1. Attach the Seat Frame ASSY (#2) to the Button Frame ASSY (#1) using: two M12*35 Socket Head Cap Screw (#4) two Φ13*Φ24*1.5 Flat Washer (#6) 2. Attach the Sit Pad (#3) to the Seat Frame ASSY (#2) using: four M10*30 Socket Head Cap Screw (#5) four Φ11*Φ23*2 Flat Washer (#7) Note: Wrench Tighten Bolts. -
Page 11: Maintenance Schedule
Maintenance Schedule COMMERCIAL HOME LATEST DATE ENTRY ROUTINE MAINTENANCE MAINTENANCE Inspect; Links, Pull Pins, Snap Locks, DAILY WEEKLY Swivels, Weight Stack Pins Clean; DAILY WEEKLY Upholstery Inspect; DAILY WEEKLY Cables or Belts and their tension Inspect; WEEKLY 3 MONTHS Accessory Bars, and Handles Inspect;... -
Page 12: General Maintenance Information
General Maintenance Information Links, Pull-Pins, Snap Hooks, Swivels, Weight Stack Pins: * Check all pieces for signs of visible wear or damage. * Check springs in snap hooks and pull-pins for proper tension and alignment. * If the spring sticks or has lost its rigidity, replace it immediately. Upholstery: * To ensure prolonged upholstery life and proper hygiene, all upholstered pads should be wiped down with a damp cloth after every workout. -
Page 13: Weight Training Tips
Weight Training Tips Use this manual to guide you through the basic exercises you can perform on your equipment. To gain maximum results and avoid possible injury, consult a fitness professional to develop your complete exercise program. Always consult your physician before starting any exercise program. To be successful in your exercise program, it is important to develop an understanding of the basic principles of strength training.
