- Page 1 User’s Manual 11N ADSL2+ Modem Router Model No.: SP3367N http://www.micronet.info...
-
Page 2: Table Of Contents
Table of Contents Chapter 1 Introduction................. 2 1.1 Package Contents ..................2 1.2 Key Features ....................2 1.3 Safety Information ..................3 1.4 Specifications....................4 Chapter 2 Physical Description ..............6 2.1 Back Panel..................... 6 2.2 Front Panel ....................7 Chapter 3 System and Network Setup ............ - Page 3 4.4.4 UPnP .........................41 4.4.5 DDNS ........................42 4.5 Maintenance ....................44 4.5.1 Administrator ....................44 4.5.2 Time Zone ......................44 4.5.3 Firmware ......................45 4.5.4 System Restart ....................46 4.5.5 Diagnostics .......................46 4.6 Status......................47 4.6.1 Device Info......................47 4.6.2 System Log ......................47 4.6.3 Statistics......................48 Chapter 5 Glossary ..................49...
- Page 4 Certifications This equipment has been tested and found to comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received. Include interference that may cause undesired operation.
-
Page 5: Chapter 1 Introduction
Chapter 1 Introduction Micronet SP3367N, 11N ADSL2+ Modem Router, delivers highly reliable and scalable network environment. The model has incorporated both modem and router functions into a single unit with wireless support. It is compliant with IEEE 802.11 Draft-N and backward compatible with IEEE 802.11b/g. -
Page 6: Safety Information
PPP over AAL5 (RFC 2364). PPP over Ethernet (RFC 2516). Support 802.11n Wireless Access Point Complies with IEEE 802.11n draft 2.0, IEEE 802.11g and IEEE 802.11b standards. Farther coverage, less dead spaces and higher throughput with MIMO technology. High data rate – up to 300Mbps network speed. Supports 64-bit/128-bit WEP, WPA-PSK and WPA2-PSK wireless security functions. -
Page 7: Specifications
If users want to place this router at high places, please make sure the router is firmly secured. Falling from high places would damage the router and its accessories, and in such cases, the warranty will be void. Accessories of this router, like antenna and power supply, are danger to small children under 3 years old. - Page 8 Sharing Virtual Server VPN Pass Through (IPSec/PPTP) SPI Anti-DOS Firewall ACL (Access Control) IP/MAC/Application/URL Filter UPnP (Universal Plug and Play) Dynamic DNS Security Features 64/128-bit WEP WPA-PSK WPA2-PSK Management Web UI SNMP Humidity 10~90% (Non-Condensing) Temperature 10~40℃ Power 12VDC, 1A Switch Power Adaptor Certification FCC, CE...
-
Page 9: Chapter 2 Physical Description
Chapter 2 Physical Description Back Panel Parameter Description The antenna connector of the router is reverse SMA Antenna connector. It allows you to connecting an external Connector antenna with reverse SMA connector to the router easily. Press and hold <Reset> button for 5 seconds to Reset clear all settings. -
Page 10: Front Panel
Front Panel Status Description Device is switched on. Wireless LAN disabled. WLAN Blinking Wireless transmission detected. WPS function is disabled. Blinking WPS function is enabled. Successful connection to DSLAM. ADSL Blinking No connection. LAN port is connected. No network connection. (1-4) Blinking Data is being sent or received. -
Page 11: Chapter 3 System And Network Setup
Chapter 3 System and Network Setup Build Network Connection Please follow the following instruction to build the network connection between the new wireless router and other network computers and devices: Connect the ADSL port of modem router by telephone cable (RJ-11) to an outlet or splitter. -
Page 12: Connecting To Web-Based Management
Connect the A/C power adapter to the wall socket, and then connect it to the ‘Power’ socket of the router. The ADSL LED will be ON if the router is connected to the ADSL cable and receives the ADSL signals successfully. If the LED is blinking, please contact with your ISP (Internet Service Provider) to check the problem. - Page 13 3. Check the list of Network Components. If TCP/IP is not installed, click the <Add> button to install it. If TCP/IP is installed, go to step 6. 4. In the Network Component Type dialog box, select <Protocol> and click <Add> button.
- Page 14 b) Windows 2000 1. Click the <Start> button and select <Settings>, then click <Control Panel>. The Control Panel window will appear. 2. Double-click <Network and Dial-up Connections> icon. In the Network and Dial-up Connection window, double-click on <Local Area Connection> icon. The Local Area Connection window will appear.
- Page 15 2. Double-click <Local Area Connection> icon. The Local Area Connection window will appear. 3. Check the list of Network Components. Users should see Internet Protocol [TCP/IP] on the list. Select it and click the <Properties> button. 4. In the Internet Protocol (TCP/IP) Properties window, select <Obtain an IP address automatically>...
- Page 16 2. Select <Obtain an IP address automatically> and <Obtain DNS server address automatically>, then click <OK>.
-
Page 17: Router's Ip Address
3.2.2 Router’s IP Address 1. After the IP address setup is complete, please click <Start> then <Run> at the bottom lower corner of the desktop. 2. Enter ‘cmd’ command and click <OK>. 3. Input ‘ipconfig’, then press ‘Enter’ key. Please check the IP address followed by ‘Default Gateway’... -
Page 18: Starting Web-Based Management Ui
3.2.3 Starting Web-Based Management UI 1. After the computer has obtained an IP address from router, please start the web browser. Input the IP address of router in the address bar and the following message should appear: 2. Please input username and password in the field respectively. Default username is ‘admin’... -
Page 20: Chapter 4 Web-Based Management Ui
Chapter 4 Web-Based Management UI Quick Start Wizard The Quick Start section is designed to get the broadband router running as quickly as possible. In the Quick Start, users are required to fill in only the information necessary to access the Internet. Once user clicks on the <Quick Start> and click on <Run Wizard>, the following screen will appear. - Page 21 Step 2: Time Zone The Time Zone allows router to base its time on the settings configured in this section. Click on <NEXT> to proceed to the next page: Broadband Type.
- Page 22 Step 3: Broadband Type In this section users have to select one of four types of connections that it will be using to connect to broadband router WAN port to the ISP (see screen below). Different ISPs require different methods of connecting to the Internet, please check with the ISP as to the type of connection it requires.
-
Page 23: Interface Setup
Step 4 Enter the Internet account details provided by ISP Click <Next> to complete the Quick Start Wizard and restart modem router. Interface Setup 4.2.1 Internet Below interface is for entering all parameters in regards to connecting to ISP devices for Internet. - Page 24 ATM VC Parameter Description VPI (Virtual Path Identifier) and VCI (Virtual Channel Identifier Virtual Circuit define a virtual circuit. VPI is a virtual path determines the way an ATM cell should be routed. The VPI is an 8-bit (in UNI) or 12-bit (in NNI) number that is included in the header of an ATM cell.
- Page 25 CBR (Constant Bit Rate) – This class is used for emulating circuit switching. The cell rate is constant with time. Select CBR to specify fixed (always on) bandwidth for voice or data traffic. UBR (Unspecified Bit Rate) – Select UBR for applications that are non-time sensitive, such as e-mail.
- Page 26 Parameter Description Service Name Enter the name of your ISP. User Name Enter the username exactly as your ISP assigned. Password Enter the password that your ISP has assigned to you. Please check with your ISP the method of multiplexing. In Bridge Mode, please select “1483 Bridge IP LLC”...
-
Page 27: Lan
Dynamic routing allows routing tables in routers to change as the possible routes change. This router supports RIP1, RIP2- Dynamic Route B and RIP2-M protocols for dynamic routing. After the RIP protocol is selected, please choose the RIP direction from “None”, “Both”, “IN Only”... - Page 28 Dynamic routing allows routing tables in routers to change as the possible routes change. This router supports RIP1, RIP2- Dynamic Route B and RIP2-M protocols for dynamic routing. After the RIP protocol is selected, please choose the RIP direction from “None”, “Both”, “IN Only”...
-
Page 29: Wireless
4.2.3 Wireless Access Point Settings Parameter Description Activated or deactivated the wireless function of the router. Access Point When it is activated, the router will be an access point for other wireless clients to connect wirelessly. It is the radio channel used by the wireless LAN. All devices in the same wireless LAN should use the same channel. - Page 30 Determines the interval the Access Point will send its DTIM broadcast traffic. The range is from 1 to 255 and the default value is 3 beacons. 802.11b – It only allows 802.11b wireless network client to connect to this router (maximum transfer rate 11Mbps). 802.11g –...
- Page 31 Select “Yes” to make the SSID to be visible so wireless clients can scan the router within the network. Select “No” if you want Broadcast SSID to hide the SSID of the router. Wireless clients have to set the same SSID of the router in order to access the network. The short of Wi-Fi Multi Media, it will enhance the data transfer performance of multimedia contents when they’re being transferred over wireless network.
- Page 32 It’s very important to set wireless security settings properly. If not enabled, hackers and malicious users can reach your network and valuable data without user’s consent and this will cause serious security problem. Authentication Type This router supports WEP, WPA-PSK and WPA2-PSK authentication type.
- Page 33 Wireless MAC Address Filter Parameter Description This router can prevent the wireless clients from accessing the wireless network by checking the MAC Address of the Active clients. If users enable this function, please set the MAC Address of the wireless clients to be filtered. Allow Association –...
-
Page 34: Advanced Setup
Advanced Setup 4.3.1 Firewall Parameter Description When you enable the firewall function, it will protect you from following attacks of WAN side: SYN flooding attack Firewall Ping of Death Teardrop Land attack If you enable SPI, all traffics initiated from WAN site will be blocked including DMZ, Virtual Server, etc. - Page 35 Routing Table List Users can see the current routing table of the router here. If they want to add another routing rule, please click “ADD ROUTE”. Parameter Description Dest IP Show the IP Address of the destination LAN. Show the Subnet Mask of the destination LAN. If it shows “8” that means the Subnet Mask is “255.0.0.0”;...
-
Page 36: Nat
IP Subnet Mask Enter the Subnet Mask address of the destination LAN. This is the gateway IP Address where packets are sent. Enter Gateway IP Address the gateway IP Address and select the channel (PVC) you want to configure. The number of hops (routers) to pass through to reach the Metric destination LAN. - Page 37 The DMZ Host is a local computer exposed to the Internet. When setting a particular internal IP Address as the DMZ Host, all incoming packets will be checked by the firewall and NAT algorithms then passed to the DMZ Host. For example, if you have a local client PC that cannot run an Internet application (e.g.
- Page 38 Parameter Description Show the Virtual Server setting is for single or multiple IP Virtual Server for Addresses. Rule Index Choose the rule number. Select the application of the virtual server, for example: FTP Application or HTTP Server. When the application is selected, the port number for the application will be assigned automatically.
-
Page 39: Adsl
4.3.4 ADSL Parameter Description The default setting is “Auto Sync-Up”. This mode will automatically detect the ADSL mode including ADSL2+, ADSL Mode ADSL2, G.DMT, T1.413 and G.lite. If you are not sure how to select the ADSL mode, please contact with your ISP. Check with your ISP about the ADSL type of the DSLAM ADSL Type device they use. -
Page 40: Access Management
Access Management 4.4.1 ACL If users want to restrict users from accessing certain Internet applications/services such as Internet websites, email, FTP etc., then this is the place to set that configuration. Access Control allows users to define the traffic type permitted in your LAN or WAN. Users can control which computer can have access to these services by entering the IP Address of the computer. -
Page 41: Filter
4.4.2 Filter Users can forbid some users from accessing the router by filtering IP Address or MAC Address. Users can also restrict some applications or URLs be accessing by users through the router here. Please select the filter type to start configuring. IP/ MAC Filter IP/ MAC Filter Set Editing... - Page 42 Parameter Description IP/MAC Filter Set This is the item number to record the setting. Index Interface Select which channel (PVC) to configure. Select the access to the Internet (Outgoing) or from the Direction Internet (Incoming), or Both. IP / MAC Filter Rule Editing Parameter Description IP/MAC Filter Rule...
- Page 43 Parameter Description Application Filter Activate or deactivate the application filter. If “Allow” is selected, the packets for these applications will be ICQ/MSN/YMSG/ Real able to pass through the router. If you want to restrict these Audio/Video applications, please select “Deny”. URL Filter Parameter Description...
-
Page 44: Snmp
A URL can be thought of as the "address" of a web page and is sometimes referred to informally as a "web address." Please enter the web address here that you want to restrict to be connected. 4.4.3 SNMP Simple Network Management Protocol (SNMP) is a popular protocol for network management. -
Page 45: Ddns
Parameter Description UPnP Activated or deactivated the UPnP function. Select this check box to allow UPnP-enabled applications to automatically configure the router so that they can communicate through the router, for example by using NAT Auto-configured traversal, UPnP applications automatically reserve a NAT forwarding port in order to communicate with another UPnP enabled device. - Page 46 Parameter Description Dynamic DNS Activated or deactivated the DDNS function. Service Provider This router supports DynDNS service provider. Enter the domain name assigned to your router by the service My Host Name provider. E-mail Address Enter the E-mail address assigned by DDNS service provider. Username Enter your username.
-
Page 47: Maintenance
Maintenance 4.5.1 Administrator Parameter Description Username The username of the router is “admin” by default. New Password Enter up to 30-digit for the new password. Confirm Password Enter the new password again to confirm the setting. 4.5.2 Time Zone The Time Zone allows the router to set its time and this will affect function such as System Log. -
Page 48: Firmware
Parameter Description Current Date/Time Show the current date/time of the router. NTP Server Automatically – Set the time automatically with a NTP Server. Synchronize time with PC’s Clock – Set the time synchronize with computer. Manually – Set the time manually. Select the time zone of the country you are currently in. -
Page 49: System Restart
4.5.4 System Restart In this interface, users can restart the router or restore to factory defaults. If users wish to restart the router using the factory default settings, select “Factory Default Settings” to reset to factory defaults. Users can also click the “Reset” button in the rear panel of the router over 5 seconds to reset default settings. -
Page 50: Status
Status 4.6.1 Device Info In this interface, it will show the device information including firmware, MAC Address, LAN and WAN settings and also the ADSL line status. 4.6.2 System Log Display system logs accumulated up to the present time. You can also save the logs for future reviewing. -
Page 51: Statistics
4.6.3 Statistics Show the statistics of transmitted and received packets on the LAN port, ADSL line or WLAN port. -
Page 52: Chapter 5 Glossary
Chapter 5 Glossary 10Base-T It is an Ethernet standard for Local Area Network (LAN). 10Base-T uses a twisted pair cable with maximum length of 100 meters. ATM Adaptation Layer that defines the rules governing segmentation and reassembly of data into cells. Different AAL types are suited to different traffic classes. ADSL Asymmetric Digital Subscriber Line, as its name showing, is an asymmetrical data transmission technology with high traffic rate downstream and low traffic rate upstream. - Page 53 Default Gateway (Router) Every non-router IP device needs to configure a default gateway’s IP address. When the device sends out an IP packet, if the destination is not on the same network, the device has to send the packet to its default gateway, which will then send it out towards the destination.
- Page 54 Idle Timeout Idle Timeout is designed so that after there is no traffic to the Internet for a pre-configured amount of time, the connection will automatically be disconnected. Internet Service Provider is a business that provides connectivity to the Internet for individuals and other businesses or organizations.
- Page 55 Application Protocol Port Number Telnet SMTP POP3 H.323 1720 SNMP SNMP Trap HTTP PPTP 1723 PC Anywhere TCP 5631 PC Anywhere UDP 5632 PPP is the Point-to-Point-Protocol. The successor to SLIP, PPP provides router-to-router and host-to-network connections over both synchronous and asynchronous circuits. PPPoA (RFC 2364) The Point-to-Point Protocol (PPP) provides a standard method for transporting multi- protocol data grams over point-to-point links.
- Page 56 Request for Comments. The document (begun in 1969) is for describing the Internet suite of protocols and related experiments. Not all RFCs describe Internet standards, but all Internet standards are written up as RFCs. RFC 1483 Multi-protocol encapsulation over AAL-5. Two encapsulation methods for carrying network interconnect traffic over ATM AAL-5.
- Page 57 It is the virtual terminal protocol in the Internet suite of protocols. Allows users of one host to log into a remote host and act as normal terminal users of that host. Virtual Circuit Identifier is part of the ATM cell header. A VCI is a tag indicating the channel over which a cell will travel.
