MicroNet SP3354 V3 Installation Manual

Broadband adsl router

Advertisement

Quick Links

Installation Guide

Broadband ADSL Router
Model No. SP3354 V3
http://www.micronet.info
CE Declaration of conformity
This equipment complies with the requirements relating to
electromagnetic compatibility, EN55022 class A for ITE, the essential
protection requirement of Council Directive 89/336/EEC on the
approximation of the laws of the Member States relating to
electromagnetic compatibility.
FCC Part 68
This equipment complies with Part 68 of the FCC Rules. On the
bottom of this equipment is a label that contains the FCC Registration
Number and Ringer Equivalence Number (REN) for this equipment.
You must provide this information to the telephone company upon
request.
The REN is useful to determine the quantity of devices you may
connect to the telephone line and still have all of those devices ring
when your number is called. In most, but no t all areas, the sum of the
REN of all devices connected to one line should not exceed five (5.0).
To be certain of the number of devices you may connect to your line,
as determined by the REN, you should contact your local telephone
company to determine the maximum REN for your calling area.
If the modem causes harm to the telephone network, the telephone
company may discontinue your service temporarily. If possible, they
will notify you in advance. But if advance notice isn't practical, you will
be notified as soon as possible. You will be advised of your right to file
a complaint with the FCC.
The telephone company may make changes in its facilities,
equipment, operations, or procedures that could affect the proper
operation of your equipment. If they do, you will be notified in
advance to give you an opportunity to maintain uninterrupted
telephone service.
If you experience trouble with this modem, please contact your dealer
for repair/warranty information. The telephone company may ask you
to disconnect this equipment from the network until the problem has
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP3354 V3 and is the answer not in the manual?

Questions and answers

Summary of Contents for MicroNet SP3354 V3

  • Page 1: Installation Guide

    The telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the proper Model No. SP3354 V3 operation of your equipment. If they do, you will be notified in advance to give you an opportunity to maintain uninterrupted telephone service.
  • Page 2 been corrected or you are sure that the equipment is not the interconnection means. malfunctioning. Notes: This equipment may not be used on coin service provided by the Operation is subject to the following two conditions: telephone company. Connection to party lines is subject to state tariffs. 1) This device may not cause harmful interference, and 2) This device must accept any interference received including Installation...
  • Page 3: Table Of Contents

    3.6.5 Virtual Server ..............37 Table of Contents 3.6.6 DNS..................38 3.6.7 Bridge Filtering ..............40 CE Declaration of conformity...............1 3.6.8 Save Settings..............41 Chapter 1 Introduction ................6 3.6.9 Reboot Without Saving ............42 1.1 Overview ...................6 3.7 Admin Privilege................43 1.2 Features ....................7 3.7.1 WAN Status ................43 1.3 System Requirements..............8 3.7.2 ATM Status .................44 Chapter 2 Installation..................9...
  • Page 4: Chapter 1 Introduction

    Translation (NAT), Dynamic Host Protocol (DCHP) and Routing Chapter 1 Introduction Information Protocol (RIPv2) processor, ADSL DMT Engine, Analogue Front End (AFE) and Line Driver. 1.2 Features This ADSL Router provides home connectivity to an ADSL service provider network over an ADSL/Asynchronous Transfer Mode (ATM) physical layer.
  • Page 5: System Requirements

    - DNS Proxy Chapter 2 Installation - Port Forwarding - DHCP (dynamic host configuration protocol) server and client - NAT (network address translation) - MAPT (network address and port translation) - ICMP (Internet control message protocol) This chapter offers information about installing your router. If you are - Simultaneous USB and Ethernet operation not familiar with the hardware or software parameters presented here, please consult your service provider for the values needed.
  • Page 6: The Front Leds

    2.2 The Front LEDs 2.3 The Rear Ports State Description Connector Description Modem is powered ON POWER POWER Power connector with 9Vdc/ 1.5 Ampere Modem is powered OFF Flashing When the router is working properly READY Reset The reset button, when pressed, resets the modem The router is not ready Button without the need to unplug the power cord...
  • Page 7: Hardware Installation

    2.4 Hardware installation POTS Splitter Configuration (ADSL over POTS) A POTS splitter separates data signals from voice signals on your This section describes how to connect and configure the ADSL router. telephone line. The POTS splitter works by running a separate data line from the voice line, so that the ADSL router has a dedicated cable for data transmission.
  • Page 8: Chapter 3 Configuration

    ISDN Splitter Configuration (ADSL over ISDN) Chapter 3 Configuration A ISDN splitter separates ADSL signals from ISDN signals on your ISDN telephone line. The ISDN splitter works by running a separate ADSL line from the ISDN line, so that the ADSL router has a dedicated cable for data transmission.
  • Page 9: Connecting The Adsl Router To Your Network

    Gather the information as illustrated in the following table and keep it 3.3 Connecting the ADSL Router to your network for reference. Unlike a simple hub or switch, the setup of the ADSL Router consists PPPoE VC-Mux: VPI/VCI, Service Name, Username, Password, and Domain of more than simply plugging everything together.
  • Page 10: Configuring With Web Browser

    If you want to configure the device with the user level, type user in address for you, there are two methods you can use at this mode. the username field and password in the password field. First you can set the "router" mode and give VPI/VCI of WAN. Then save and reboot router, it will work fine with your whole system.
  • Page 11: Adsl

    WAN: These fields display the IP address, Subnet Mask and 3.5.2 ADSL MAC address for the WAN ADSL) interface. The ADSL Status page shows the ADSL physical layer status. LAN: These fields display the IP address, Subnet Mask and MAC address for the LAN interface.
  • Page 12: Lan

    power level of the CPE. 3.5.3 LAN ADSL CO Vendor: This field displays the Central Office DSLAM The LAN page shows the information and status of LAN port, DHCP vendor name, if available. client table, Ethernet link and USB link. Elapsed Time: This field displays the time of the modem has been in operation.
  • Page 13: Ppp

    3.5.4 PPP 3.6 Configuration The PPP Status page shows the status of PPP for each PPP 3.6.1 WAN interface. The WAN configuration page allows the user to set the configuration for the WAN/ADSL ports. PPP: These fields display the Connection Name (user defined), Interface (PVC), Mode (PPPoE or PPPoA), Status (Connected or Not Connected), Packets Sent, Packets Received, Bytes Sent and Byte Received.
  • Page 14 PPP Configuration Service Category: UBR and CBR are supported from the ATM. The current release supports multiple PPP sessions per PVC. The Bandwidth: Bandwidth setting takes effect only when the CBR is PPP configuration in the WAN configuration page is for the first PPP selected.
  • Page 15: Lan

    Automatic Reconnect: When it is checked, it will maintain the 3.6.2 LAN PPP connection all the time. If the ISP shut down the PPP connection, it will automatically reconnect PPP session. The LAN configuration page allows the user to set the configuration for the LAN port.
  • Page 16: Ppp

    maximum pool size can be 253 IP addresses: 255 total IP 3.6.3 PPP addresses – 1 broadcast address – 1 LAN port IP address. The PPP Configuration page allows the user to configure multiple DHCP Gateway Selection: The default setting for the DHCP PPP sessions for each PVC.
  • Page 17 Disconnect Timeout: The Disconnect Timeout allows the user to set the specific period of time to disconnect from the ISP. The default is 0, which means never disconnect from the ISP. MRU: Maximum Receive Unit indicates the peer of PPP connection the maximum size of the PPP information field this device can be received.
  • Page 18: Nat

    3.6.4 NAT page to show all the session Names with its WAN Interface. Session Name: This field allows the user to entere his/her own The NAT Configuration page allows the user to set the configuration session Name to distinguish different NAT session for different for the Network Address Translation.
  • Page 19: Virtual Server

    Click the link Go back to NAT Configuration to the NAT 3.6.5 Virtual Server configuration page. Select the NAPT option. Select the Session Name and assign the PC IP address, and choose the Add action. The Virtual Server Con figuration page allows the user to set the Click the Submit button and go to the Save Settings to save this configuration of Virtual Server.
  • Page 20: Dns

    3.6.6 DNS PPP into the table. And all DNS query messages will be sent to one of the dynamically obtained DNS servers. The DNS Configuration page allows the user to set the configuration Use User Configured DNS Servers Only: The DNS proxy will of DNS proxy.
  • Page 21: Bridge Filtering

    3.6.7 Bridge Filtering 3.6.8 Save Settings The Save Settings page allows the user to save the new The Bridge Filtering configuration page allows the user to set the configuration of IP filtering. configuration to the flash and reboot the system. When the configurations are changes via the Web pages, the new settings need to be saved into the flash, so it is necessary to go to this Source MAC: When the bridge filtering is enabled, enter the...
  • Page 22: Reboot Without Saving

    3.6.9 Reboot Without Saving 3.7 Admin Privilege The Reboot Without Saving page allows the user to reboot the 3.7.1 WAN Status system without save the new configuration to the flash. The WAN Status page shows the information and status of WAN During the Reboot, the following Web page will be displayed “The PVCs.
  • Page 23: Atm Status

    3.7.2 ATM Status 3.7.3 TCP Status The ATM Status page shows all the statistics information of ATM cells. The TCP Status page shows the statistics for all TCP connections. Reset Counters: This button allows user to reset the ATM Status Reset Counters: This button allows user to reset the TCP Status counter.
  • Page 24: Route Table

    3.7.4 Route Table All user defined route entries kept in the CPE memory during run time are saved to flash when the user chooses to save and reboot the CPE. When CPE re starts, it reloads all saved user-defined routes to The Route Table page displ a ys routing table and allows the user to the CPE memory and tries to apply to the system.
  • Page 25: Learned (Bridge) Mac Table

    and LAN). This option lets the user to associate the system-wide 3.7.5 Learned (Bridge) MAC Table Default Gateway to a Network Interface, static or dynamic, and provides a way to fix the Default Gateway to a dynamic Network The Learned MAC Table page shows the current learned Bridge MAC Interface before the interface is established.
  • Page 26: Adsl Configuration

    3.7.6 ADSL Configuration 3.7.7 RIP Configuration The A DSL Configuration page allows the user to set the configuration The RIP Configuration page allows the user to set the configuration for ADSL protocols. for the system wide configuration of RIP. The actual RIP configuration is in the RIP Per Interface Configuration.
  • Page 27 Enable: This field allows the user to Enable (Yes) or Disable (No) invalidated and remains in the internal RIP Route Table. It will be included in the RIP announcements to let other routers know the the specified interface for RIP. changes.
  • Page 28: Password Configuration

    3.7.8 Password Configuration 1.Admin The Admin Password Configuration page allows the user to set the password for administrator. The Admin password is same pas the FTP password, so it must has at least 8-characters for the FTP to work. 2. User The User Password Configuration page allows the user to set the password for the user.
  • Page 29: Miscellaneous Configuration

    3.7.9 Miscellaneous Configuration the Web access. For example, when it is changed to 1001, the HTTP server address for the LAN side is http://10.0.0.2:1001. The Miscellaneous Configuration allows the user to set all the FTP server: This field allows the user to enable or disable the miscellaneous configurations.
  • Page 30: Reset To Factory Default

    3.7.10 Reset to Factory Default 3.7.11 Diagnostic Test The Reset to Factory Default page allows the user the reset the The Diagnostic Test page shows the test results for the connectivity of modem to original factory default configuration (factory.reg). the physical layer and protocol layer for both LAN and WAN sides. Testing Ethernet LAN Connection: This test checks the Ethernet LAN interface connection.
  • Page 31: Code Image Update

    OAM F5 End to End loop back request cells to the CO. This test 3.7.12 Code Image Update will pass if response cell is received. Since some r service providers might not support this test, it could still work even if this The Code Image Update page allows the user to upgrade the image test fails.
  • Page 32: Network Code Image Update

    3.7.13 Network Code Image Update The Network Code Image Update page allows the user to upgrade the image code from the remote FTP server. 1. Firmware Assume an FTP server stores the updated image firmware.dlf on Internet. Click Image Download to initiate the updating. 2.
  • Page 33: System Log

    3.7.14 System Log Chapter 4 Troubleshooting The System Log page shows the events triggered by the system. This chapter gives information about troubleshooting your ADSL Router. After each problem description, instructions are provided to help you diagnose and solve the problem. Basic Function Ÿ...
  • Page 34 WAN_ACT LED Never Blinks If your Router is unable to obtain an ISP address from the ISP, the problem may be one of the following: Ÿ When the Router is turned on the WAN_TST LED blinks for about Ÿ Y our Router may be set incorrectly the login name and password 40 seconds and then turns off.
  • Page 35 To ping the Router from a PC running Windows 95/98/NT: Testing the Path from Your PC to a Remote Device Ÿ From the Windows toolbar, click on the Start button and select After verifying that the LAN path works correctly, test the path from Run.
  • Page 36: Appendix A Glossary

    which simply forward electrical signals from one cable to the other, Appendix A Glossary and full-fledged routers which make routing decisions based on several criteria. Broadband Address mask Characteristic of any network multiplexes independent network A bit mask used to select bits from an Internet address fo r subnet carriers onto a single cable.
  • Page 37 Downstream rate Hop count The line rate for return messages or data transfers from the network A measure of distance between two points on the Internet. It is machine to the user's premises machine. equivalent to the number of gateways that separate the source and destination.
  • Page 38 conne cted. Password Authentication Protocol Internet Protocol (IP) The network layer protocol for the Internet protocol suite PORT The abstraction used by Internet transport protocols to distinguish among multiple simultaneous connections to a single destination IP address host. The 32-bit address assigned to hosts that want to participate in a TCP/IP Internet.
  • Page 39 Route Spanning-Tree Bridge Protocol (STP) The path that network traffic takes from its source to its destination. Spanning-Tree Bridge Protocol (STP) - Part of an IEEE standard. A The route a datagram may follow can include many gateways and mechanism for detecting and preventing loops from occurring in a many physical networks.
  • Page 40 TFTP Virtual Connection (VC) Trivial File Transfer Protocol - A simple file transfer protocol (a A link that seems and behaves like a dedicated point-to-point line or a simplified version of FTP) that is often used to boot diskless system that delivers packets in sequence, as happens on an actual workstations and other network devices such as routers over a point-to-point network.
  • Page 41: Appendix B Cabling / Connection

    Appendix B Cabling / Connection Network cables connect PCs in an Ethernet network Category 5, called "Cat5" for short is commonly used type of network cable today. Cat 5 cables are tipped with RJ-45 connectors, which fit into RJ-45 port. Straight-through vs.
