- Page 1 User’s Manual 8-Port VDSL Managed Switch Model No.: SP3508A http://www.micronet.info...
-
Page 2: Table Of Contents
Chapter 5 Web-Based UI Management Interface ...13 5.1 Home Page...13 5.2 Port Status...13 5.3 Port Statistics...14 5.4 IP Address ...15 5.5 Switch Setting ...15 T5.5.1 TBasic ...15 5.5.2 Advanced ...16 5.6 Port Controls...19 5.7 Link Aggregation...20 5.7.1 Aggregator Setting ...20... - Page 3 5.7.2 Aggregator Information...21 5.7.3 State Activity ...21 5.8 Filter Database ...22 5.8.1 IGMP Snooping ...22 5.8.2 Static MAC Address ...23 5.8.3 Port Security...24 5.8.4 MAC Filtering ...24 5.9 VLAN Configuration ...25 5.9.1 Basic ...26 5.9.2 Port VID...27 5.10 Spanning Tree ...28 5.11 Port Sniffer ...30 5.12 SNMP ...31 5.13 Signal to Noise Ratio ...33...
-
Page 4: Chapter 1 Introduction
Chapter 1 Introduction Micronet SP3508A is an EoVDSL (Ethernet over VDSL) clustering switch that aggregates 8 VDSL lines into 2 Gigabit Ethernet uplinks. It delivers cost- effective and high-performance broadband / multimedia services to multiunit building environments, such as enterprise, campus, hospital, hotel, and telecom. - Page 5 Supports SNMP v1 RFC-1493 Bridge MIBs RFC-1643 Ethernet MIB RFC-1213 MIB II Enterprise MIBs RMON groups 1(Statistics), 2(Alarm), 3(Event), 9(History) Supports TFTP/XMODEM for firmware upgrade Built-in POTS/ISDN splitter for POTS/ISDN telephone service...
-
Page 6: Chapter 2 Installation
The Modem should be located in a cool dry place with at least 10cm of space at the front and back for ventilation. Place the switch out of direct sunlight, and away from heat sources or areas with a high amount of electromagnetic interference. -
Page 7: Connecting To Gigabit Ethernet
The IP DSLAM has 2 X 10/100/1000 Mbps Giga Ethernet ports. Support full or half-duplex operation and transmission mode is using auto-negotiation. All network devices connected to the switch must support auto- negotiation. Devices without auto-negotiation will operate at half- duplex. -
Page 8: Connecting To Rj-11
Networking devices can be installed on a single telephone wire that can span up to maximum of 1.7km between the two points. SP3508A has embedded Splitter between every VDSL side (VDSL Line) and POTS side (POTS port). It permits user to deliver broadband service on the same lines as Plain Old Telephone Service (POTS), PBX, ISDN traffic and VDSL Signal. -
Page 9: Chapter 3 Physical Description
LED) Flash/Green Steady/Green 1000/ACT (Ethernet LED) Flash/Green SP3508A front view SP3508A rear view Operation Device is powering on or reset ok. Lights on when device is booting. Turns off when booting is finished. Lights up steadily to show good linkage. -
Page 10: Switch Connectors
Connecting to the telephone, Fax or ISDN modem Gigabit Connecting to an Ethernet network device. Ethernet Console Console port for managing the switch. AC Socket accepts AC power 85 to 265 voltage Each VDSL port has a LED and lights up to show good linkage. Description... -
Page 11: Chapter 4 Ip Address Configuration
Chapter 4 IP Address Configuration Out-Band Access 4.1.1 Console Port Users can configure the product with the local serial console port. The procedure is to connect a notebook computer to the RS-232 port, then boot windows @95/98/ME/2000 system, and run “Hyper-terminal” program into terminal window. - Page 12 Step 2. Connects PC with the IP DSLAM, the login window will appear on the screen. Enter the default login details: Login: admin Password: 123 The program will enter the following text-based user interface. Step 3. Choose ‘VDSL Switch Static Configuration’ to enter the page below.
- Page 13 Step 4. Choose ‘Administration Configuration’ to proceed to the page below. Step 5. Choose ‘IP Configuration’ to proceed to IP configuration page. Parameter Edit CTRL+A Save Previous Menu Main Menu Description Select <Edit> to change IP address, subnet mask and gateway. Action menu.
-
Page 14: Remote Access
Users must setup the IP address with the local serial console port (RS-232 Port), and then use this IP address to control this VDSL switch via Telnet or Web-Based UI. Otherwise, users can change the computer’s IP domain to be the same as VDSL switch. - Page 15 Enter the default IP address of the switch into the web browser for the login confirmation window to appear.
-
Page 16: Chapter 5 Web-Based Ui Management Interface
Chapter 5 Web-Based UI Management Interface Home Page This is the VDSL switch’s home page. The switch’s image on the top indicates which port is being connected. Pressing the ports on the image will open up a window to show port statistics. -
Page 17: Port Statistics
Description Display port status with either disable or enable. ‘Down’ is no link and ‘Up’ is link. VDSL Switch’ auto-negotiation mode. Port 9-10 are 10/100/1000Mbps and port 1- 8 are 5/15/25Mbps. Display full-duplex or half-duplex mode. Display flow control status with either enabled or disabled mode. -
Page 18: Ip Address
Parameter IP Address Subnet Mask Gateway Switch Setting 5.5.1 Basic This is interface displays the basic information of the VDSL Switch such as firmware version, hardware version and MAC address. Description Default: 192.168.16.250 Default: 255.255.255.0 Default: 192.168.16.1... -
Page 19: Advanced
Range: 300~765 seconds. Default: 300 seconds. Limit the packets queuing time in the switch. If enable, the packet queued that exceed the limit will be drop. Range: 1sec, 2 sec, 4 sec and off. Default: 2 seconds. -
Page 20: Priority Queue Service Settings
Low means that the switch sends 5 high priority packets before sending 2 low priority packets. Limit the low priority packets queuing time in the switch. If the low priority packets exceed Max Delay Time, it will be sent. ‘Max bridge transit delay bound control’... - Page 21 VDSL Switch and nodes. If the switch is connected to a device with GVRP enabled, users can send a GVRP request using the VID of a VLAN defined on the switch, the switch will automatically add that device to the existing VLAN.
-
Page 22: Port Controls
2. Power on both devices. 3. The device will start auto-speed function after SP3501AS re-boot. 4. SP3508A will try 25M mode to link with SP3501AS, if fail, auto speed down to 15M mode and re-link with SP3501AS. If fails again, auto- speed down to 5M and keep this mode then re-link with SP3501AS. -
Page 23: Link Aggregation
System Priority Group ID Description A value used to identify the active LACP. The VDSL Switch with the lowest value has the highest priority and is selected as the active LACP. Users can create a link aggregation across two or more ports. -
Page 24: Aggregator Information
LACP Work Ports Click <Apply> to activate the setting. 5.7.2 Aggregator Information When users are setting LACP aggregator, related information will be displayed in this interface. This page is Actor and Partner trunking one group with port 1 to port 1. 5.7.3 State Activity A link having either two active LACP ports or one active port can perform dynamic LACP trunking. -
Page 25: Filter Database
224.0.0.0 through 239.255.255.255. 5.8.1 IGMP Snooping IGMP have three fundamental types of message as follows: 1. Query: A message sent from the queries (IGMP router or SP3508A) asking for a response from each host belonging to the multicast group. Description The port automatically sends LACP protocol packets. -
Page 26: Static Mac Address
5.8.2 Static MAC Address When users add a static MAC address, it remains in the SP3508A’s address table, regardless of whether the device is physically connected to the switch. -
Page 27: Port Security
<Submit> to apply the changes on this page. 5.8.4 MAC Filtering MAC address filtering allows the SP3508A to drop unwanted traffic. Traffic is filtered based on the destination addresses. For example, if the network is congested because of high utilization from one MAC address, users can filter... -
Page 28: Vlan Configuration
Port-based Tagging rule VLAN is an IEEE 802.1Q specification standard. Therefore, it is possible to create a VLAN across devices from different SP3508A venders. IEEE 802.1Q VLAN uses a technique to insert a “tag” into the Ethernet frames. Tag contains a VLAN Identifier (VID) that indicates the... -
Page 29: Basic
VLAN ID based on not only default PVID but also other information about the packet, such as the protocol. VDSL Switch will support protocol- based VLAN classification by means of both built-in knowledge of layer 2 packet formats used by selected popular protocols, such as Novell IPX and AppleTalk’s EtherTalk, and some degree of programmable protocol matching... -
Page 30: Port Vid
5.9.2 Port VID The interface sets the Port VLAN ID that will be assigned to untagged traffic on a given port. For example, if port 10's Default PVID is 100, all untagged packets on port 10 will belong to VLAN 100. The default setting for all ports is VID 1. -
Page 31: Spanning Tree
1. User can view spanning tree information about the Root Bridge in the following screen. 2. Users can view the spanning tree status of the SP3508A in the following screen. 3. Users can set new value for STP parameter, then click <Apply>... - Page 32 Parameter Priority Max Age Hello Time Forward Delay Time 4. The following parameter can be configured on each port and click <Apply> button to modify. Description Users can change priority value to identify the root bridge. The bridge with the lowest value has the highest priority and is selected as the root.
-
Page 33: Port Sniffer
Path Cost 5.11 Port Sniffer The Port Sniffer is a method for monitor traffic in SP3508A networks. Traffic through ports can be monitored by one specific port. Meaning, traffic goes in or out of monitored ports will be duplicated into sniffer port. -
Page 34: Snmp
LAN Analysis, Session Wall or Netxray. The ports for monitoring. All monitor port traffic will be copied to sniffer port. Users can select max 9 monitor ports in the SP3508A. If users want to disable the function, select monitor port to none. - Page 35 SP3508A. Fill in the system options data, and then click <Apply> to update the changes on this page. Parameter Name Location Contact 2. Community strings serve as passwords and can be entered as one of the following.
-
Page 36: Signal To Noise Ratio
5.14 Security Manager This interface allows users to change the username and password. Description When VDSL Switch’s internal temperature is greater than 70 , system will send a “Temperature alarm" trap. When the VDSL Switch’s internal cooling FAN doesn’t run, the system will send a “FAN speed alarm”... -
Page 37: Tftp Update Firmware
5.15 TFTP Update Firmware The following menu options provide some system control functions to allow a user to update firmware and remote boot SP3508A’s system 1. Install TFTP Turbo98 and execution. 2. Copy firmware update version image.bin to TFTP Turbo98 directory. -
Page 38: Configuration Backup
TFTP Restore Configuration Use this page to set TFTP server address. Users can restore EEPROM value from here, however it is necessary to enter image in TFTP server and the SP3508A will download back the flash image. 5.16.2 TFTP Backup Configuration Use this page to set TFTP server IP address. -
Page 39: Reset And Rebooting System
Parameter Reset Reboot Description The interface will reset the device back to factory default settings. Please ensure SP3508A is detached from the VDSL modem when performing this function. This interface allows user to restart the device with settings remaining unaltered. -
Page 40: Chapter 6 Application
Ethernet RJ-45 port and VDSL RJ11 port. Flexible Configuration The SP3508A is not only designed to segment the network, but also to provide a wide range of options in the configuration of home network connections. It can be used as a simple stand-alone VDSL Switch or can be connected with another VDSL Switch, Cable modem, Router, XDSL, ISDN, gateway or other network interconnection devices in various configurations. -
Page 41: Chapter 7 Appendix
Transmitter ：0.9 ~ 3.9 MHz Spectrum Receiver：4 ~ 7.9 MHz POTS/ISDN pass filter Spectrum : 0 ~ 630 kHz Power Supply Input: AC 85-265 volts/50-60Hz/1A Operating ℃ Temperature Humidity 10% ~ 90% non-condensing SP3508A ℃ ~ 50 (32F ~ 122F) - Page 42 Dimension 435 x 255 x 44mm Certification CE, FCC, RoHS...
-
Page 43: Appendix B: Troubleshooting
Verify the cables are connected properly on both ends. Verify the proper cable is used and the distant does not exceed the specified limit. Phone wire must be connected between SP3508A and VDSL modem prior to powering on of devices. Replace the defective cable or modem if necessary. -
Page 44: Appendix C: System Diagnostics
Appendix C: System Diagnostics 7.3.1 Power and Cooling Problems If the POWER indicator does not turn on when the power cord is plugged in, users may have a problem with the power outlet, power cord, or internal power supply as explained in the previous section. However, if the unit should turn itself off after running for a while, check for loose power connections, power loss or surges at the power outlet, and verify that the fan on back of the unit is unobstructed and running prior to shutdown. -
Page 45: Cabling
7.3.6 System Integrity As a last resort verify the SP3508A integrity with a power-on reset. Turn the power to the SP3508A off and then on several times. If the problem still persists and you have completed all the preceding diagnoses, contact your... -
Page 46: Appendix D: Vdsl Spectrum
Appendix D: VDSL Spectrum VDSL Technology – Requirements & Definitions Spectral Allocation • Co-exists with legacy Voice and ISDN services • Co-exists with other xDSL technologies Slide 5 • Programmable notch filter to avoid Radio Frequency Interference 06-April-2000 page: 5 ©... -
Page 47: Appendix E: Example Of Vlan Setting
Appendix E: Example of VLAN Setting 7.5.1 Port-Based VLAN Setting 1. Web management Protocol Enable Setting 2. Web management Configuration. Administrator SP3508AS settings VLAN Operation Mode: Select “Port-Based”. Administrator SP3508AS settings VLAN Advanced:... -
Page 48: Tag-Based (Ieee 802.1Q) Vlan Setting
1. Web management Protocol Enable Setting GVRP”. 2. Administrator VLAN Configuration: Select “Port VID” in this stage, users can define each port’s PVID and set traffic rules for each port. Administrator SP3508A settings VLAN Operation Mode: Select “802.1Q without Advanced:... - Page 49 3. VLAN Configuration: Select “Basic”. Highlight default_1 and click <Edit> button to add/remove each port. 4. In default_1 group, add in or remove group members.
- Page 50 5. Click <Next> button to set Tag or Untag for each assigned port. 6. Click <Add> button to create new group.
- Page 51 7. Fill in new group name into VLAN Name. Set the VID number. Add in new group members. Click <Next> button. 8. Set Tag or Untag for group members and click <Apply> button.
- Page 52 9. New group has been created, now users can highlight each group and click <Edit> or <Delete> button to modify or delete VLAN Group.
