- Page 1 Quick Installation Guide EtherFast 10/100M Switch Model No.: SP616EB http://www.micronet.info...
-
Page 2: Package Contents
Introduction Micronet SP616EB 10/100M Switch provides powerful, high-performance Ethernet switch, with all 16 ports capable of 10M and 100M auto-negotiation operation. With its intelligent addressing engine, it provides users with a wire-speed filtering and forwarding of the traffic. All ports support auto-uplink detection, so users don't have to worry about the cable type. - Page 3 Features Compliant with IEEE802.3 10Base-T, IEEE802.3u 100Base-TX and IEEE802.3x flow control Supports speed (10/100Mbps) and duplex mode(Half/Full) and auto-detection Supports MDI/MDI-X auto crossover Supports full and half duplex operation on all ports Supports back-pressure ) and flow control (Half/Full (IEEE 802.3x) Supports extensive LED indicators for network diagnostics Wire-speed packet filtering and forwarding rate Store-and-forward architecture filters fragment &...
-
Page 4: Physical Description
Physical Description Please refer to the following table for LED definition. Status POWER On/Green LNK/ACT Blink/Green SP616EB front view Operation Power is on. Power is off. Connection established. Transmitting or receiving data. No link. - Page 5 The system is ready, and you can use all the features. Connect each station to the switch by twisted-pair cable. Plug one of the RJ-45 connectors into a RJ-45 port of the switch, and plug the other RJ-45 connector into the station’s network adapter. Power on the switch and then the system is ready.
-
Page 6: Specifications
Specifications Standard Interface Cable Connections MAC address Buffer Memory NWay Protocol Uplink Filtering/Forwarding Rate Emission Operating Temperature Operating Humidity Dimension (mm) Weight (kg) Power Supply IEEE802.3, IEEE802.3u, IEEE802.3x, compliant 16 * 10/100M RJ-45 ports 10BASE-T: Cat. 3, 4, 5 UTP/STP 100BASE-TX: Cat. - Page 7 CE Mark Warning This equipment complies with the requirements relating to electromagnetic compatibility, the essential protection requirement of Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility. Company has an on-going policy of upgrading its products and it may be possible that information in this document is not up-to-date.
