2. Lift the cover, and then detach the lanyard from the luminaire enclosure to completely
remove the cover.
3. If necessary, repeat these steps to remove the second cover.

Reinstall the Head Covers

Head covers are universal, meaning that you can reinstall them on either side of the head of the
luminaire.
4
1. Align the cover to the luminaire and reattach the safety lanyard to the luminaire.
2. Angle the cover under the rear housing.
3. Slide the front of the cover down.
4. Tuck each long side of the cover behind the enclosure side rails until the cover is flush and
the hardware is aligned.
5. Secure the cover in place by tightening the captured Phillips screws.
6. If necessary, repeat steps 1–5 to reinstall the second head cover.

Clean the Lenses

CAUTION:
covers to be removed and the luminaire powered on for access to the lenses.
To reduce the risk of fire, follow the instructions below.
This procedure should only be performed by a qualified technician.
Clean the Relevé Spot luminaire lenses on a routine basis according to the installation
environment to ensure that optimal light output is maintained for the life of the luminaire.
Relevé Spot luminaire firmware includes lens cleaning access features that move the lenses
together and apart for easier access during cleaning.
Tools and supplies required:
#2 Phillips screwdriver
•
clean, soft, lint-free cloth
•
CAUTION:
Maintenance
2
3
Hazardous energy is present. This procedure requires the head
Never use chemical based cleaners or solvents on the optic lenses.
