Safety information
3.3.7 Hazardous areas
The drive must not be located in a classified hazardous area.
Hot surfaces
Care must be taken when opening the cubicle door as some
components may be hot to the touch even after the
10 minutes discharge time.
WARNING
3.4

Rittal VX25 cubicle fitting kit

The fitting kit for a VX25 Rittal cubicle is shown in Figure 3-4. The part
number is 6772-0009.
Parts supplied with the kit are listed in Table 3-1. The parts
listed in Table 3-2 are required to complete the kit and must
be ordered directly from Rittal.
Figure 3-4 VX25 Rittal cubicle fitting kit
Unidrive M Frame 12 Power Installation Guide
Issue Number: 1
Product information Mechanical installation Electrical Installation
Component IP ratings
The Power Module is rated to IP00. This must be taken into
consideration when the cubicle doors are open.
Table 3-1 Parts supplied with Rittal VX25 cubicle fitting kit
Part ID Description
1 M5 x 12 double SEM torx screw
2 M6 x 16 double SEM torx screw
3 M6 x 20 double SEM torx screw
4 M8 x 16 double SEM torx screw
5 LHS Castor Guide
6 RHS Castor Guide
7 Support rail
8 Castor support
9 Mounting bracket lower front
10 Mounting bracket rear
11 Mounting bracket front
12 Mounting bracket lower
13 LHS terminal guard
NOTE
The torx driver sizes are listed in Table 3-3
Table 3-2 Parts to be ordered from Rittal
Rittal Part no. Description
VX 8617.110 Punched section 23 x 64 mm
VX 8617.720 Punched rail 18 x 39 mm
VX 4165.500 M8 captive nut
TS 880.350 M8 captive nut
SZ 2486.500/600 Multi-tooth screw 5.5 x 13 mm
Technical data
Quantity
5
2
4
14
1
1
1
1
1
1
1
1
1
Quantity
2
2
13
1
27
17
